170
2-1. Driving procedures
IS250/220d/200d_EE
Turn signal lever
Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Right turn
Left turn
Move and hold the lever
partway to signal a lane
change
The right hand signal will
flash until you release the
lever.
Move and hold the lever
partway to signal a lane
change
The left hand signal will flash
until you release the lever.

176
2-2. Instrument cluster
IS250/220d/200d_EE
Speed indicator display conditions and vehicle speed setting range
Vehicle speed setting range:
Right-hand drive vehicles:
Approximately 50 to 160 km/h
(Approximately 30 to 100 mph)
Left-hand drive vehicles:
Approximately 50 to 200 km/h
(Approximately 30 to 125 mph)
When the maximum speed is selected, the speed indicator comes on in red.
Tacho indicator display conditions and engine speed setting range
Engine rpm setting range:
IS250: Approximately 2000 to 6500 rpm (r/min)
IS220d and IS200d: Approximately 2000 to 5100 rpm (r/min)
When the maximum rpm is selected, the tacho indicator comes on in red.
NOTICE
To prevent damage to the engine and its components
Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
The engine may be overheating if the temperature gauge is in the red zone
(H). In this case, immediately stop the vehicle in a safe place, and check
the engine after it has cooled completely. (
P. 525)

179
2-2. Instrument cluster
2
When driving
IS250/220d/200d_EE
*1:These lights turn on when the “ENGINE START STOP” switch is
turned to IGNITION ON mode to indicate that a system check is
being performed. They will turn off after the engine is started, or
after a few seconds. There may be a malfunction in a system if a
light does not come on, or if the lights do not turn off. Have the
vehicle inspected by any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional, for details.
*2:The light flashes to indicate that the system is operating
(if
equipped)
Daytime running light
system off indicator
(P. 188)SRS airbag on-off indi-
cator (P. 140)
(vehicles
with a man-
ual trans-
mission)Engine preheating indi-
cator (P. 156)
*1

180
2-2. Instrument cluster
IS250/220d/200d_EE
CAUTION
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional, immedi-
ately if this occurs.
Warning lights
Warning lights inform the driver of malfunctions in any of the
vehicle’s systems. (P. 467)
*:These lights turn on when the “ENGINE START STOP” switch is
turned to IGNITION ON mode to indicate that a system check is
being performed. They will turn off after the engine is started, or
after a few seconds. There may be a malfunction in a system if a
light does not come on, or if the lights do not turn off. Have the
vehicle inspected by any authorized Lexus dealer or repairer, or
(vehicles
with a
manual
transmis-
sion)
(if equipped)(for
driver)(for front
passen-
ger)
*****
*****

184
2-2. Instrument cluster
IS250/220d/200d_EEGear position display
(vehicles with an automatic transmission only)
Indicates the current gear, and the range of gears
that is available when the shift lever is in the D
or S position. The gear range is shown by the
number of dots () and the current gear is shown
as a number. The transmission automatically
selects the gears within the driver selected gear
range.
In the illustration to the left, a range of 6 available
gears (1 through 6) has been selected by the driver.
(The shift lever is in the D or S position with 6
ranges enabled.) It is possible for the transmission
to automatically select between all 6 of the gears.
In this case, the transmission has selected third
gear.
System check display
After switching the “ENGINE START STOP” switch to IGNITION ON
mode, “CHECK” is displayed while system operation is checked. When the
system check is complete, “COMPLETED” is displayed before returning to
the normal screen.
Outside temperature display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
When stopped, or driving at low speeds (less than 20 km/h [12 mph])
When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)

197
2-3. Operating the lights and windshield wipers
2
When driving
IS250/220d/200d_EE
Headlight cleaner switch
The headlight cleaner can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode and the
headlight switch is turned on.
Windshield washer linked operation
Only for the first time when the windshield washer is operated after the
“ENGINE START STOP” switch is turned to IGNITION ON mode with the
headlights on, the headlight cleaners will also operate once. (P. 191)
When using the headlight cleaner
The washer fluid will spray out into the surrounding area and may get on
clothes, items etc. Therefore, check the surrounding area before using the
headlight cleaner.
NOTICE
When the washer fluid tank is empty
Do not use this function when the washer fluid tank is empty. This may
cause the washer fluid pump to overheat.
Washer fluid can be sprayed on the headlights.
Press the switch to clean the
headlights.
: If equipped

249
2-5. Driving information
2
When driving
IS250/220d/200d_EEImportant points regarding turning
The wheels of the trailer will travel closer to the inside of the
curve than the wheels of the vehicle. To make allowance for this,
take the turns wider than you would normally.
Important points regarding stability
Vehicle movement resulting from uneven road surfaces and
strong crosswinds will affect handling. The vehicle may also be
rocked by passing buses or large trucks. Frequently check
behind when moving alongside such vehicles. As soon as such
vehicle movement occurs, immediately start to decelerate
smoothly by slowly applying the brakes. Always steer the vehi-
cle straight ahead while braking.
Passing other vehicles
Consider the total combined length of your vehicle and trailer
and ensure that the vehicle-to-vehicle distance is sufficient
before executing lane changes.
Transmission information
Refrain from driving in 6 (manual transmission) or 4 range in S
mode (automatic transmission) to maintain the effectiveness of
the engine brake and the charge performance of electrical com-
ponents.
If the engine overheats...
Towing a loaded trailer up a long steep incline in temperatures
exceeding 30C (85F) may result in the engine overheating. If
the engine coolant temperature gauge indicates that the engine is
overheating, turn the air conditioning off immediately, leave the
road and stop the vehicle in a safe place. (P. 525)
When parking the vehicle
Always place wheel chocks under the wheels of both the vehicle
and trailer. Firmly set the parking brake and shift the shift lever
to P for automatic transmissions, and 1 or R for manual trans-
missions.

264
3-1. Using the air conditioning system and defogger
IS250/220d/200d_EE
CAUTION
To prevent burns or damage on your vehicle
NOTICE
To prevent damage to your vehicle
Do not turn the heater on and off repeatedly in 5 minute intervals as this
can shorten the life of the heater components. If the engine must be turned
on and off repeatedly within short intervals (such as when the vehicle is
being used for delivery purposes), turn the heater off.
Do not modify or open the heater without consulting any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional. This may cause a heater malfunction or even a fire.
Be careful not to splash water or spill liquid directly on the heater or on
the heater fuel pump. This may cause the heater to malfunction.
Keep the intake and exhaust pipes of the heater free from water, snow, ice,
mud, etc. If the pipes become clogged, this can cause the heater to mal-
function.
If you notice anything unusual, such as a fluid leak, smoke or poor opera-
tion, turn off the heater and have your vehicle checked by any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional.
Do not touch the heater or its exhaust
pipe as they are hot. You may burn
yourself.
Keep flammable items such as fuel
away from the heater and its exhaust
pipe, as this may cause a fire.

383
3-7. Other interior features
3
Interior features
IS250/220d/200d_EE
CAUTION
Observe the following precautions.
Failure to do so may cause the driver's floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it
may become difficult to stop the vehicle, leading to a serious accident.
When installing the driver's floor mat
Do not use floor mats designed for other models or different model year
vehicles, even if they are Lexus Genuine floor mats.
Only use floor mats designed for the driver's seat.
Always install the floor mat securely using the retaining hooks (clips) pro-
vided.
Do not use two or more floor mats on top of each other.
Do not place the floor mat bottom-side up or upside-down.
Before driving
Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks (clips). Be
especially careful to perform this check
after cleaning the floor.
With the engine stopped and the shift
lever in P (automatic transmission) or
N (manual transmission), fully depress
each pedal to the floor to make sure it
does not interfere with the floor mat.

4Maintenance and care
387
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 388
Cleaning and protecting
the vehicle interior ......... 392
4-2. Maintenance
Maintenance
requirements .................. 395
4-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions..................... 398
Hood ................................ 401
Positioning a floor jack .... 402
Engine compartment ........ 404
Tires ................................. 420
Tire inflation pressure ...... 424
Wheels ............................. 426
Air conditioning filter ...... 428
Electronic key battery ...... 431
Checking and replacing
fuses ............................... 433
Light bulbs ....................... 448
