2-1. Driving procedures
IS250/220d/200d_EE
Turn signal lever
Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Right turn
Left turn
Move and hold the lever
partway to signal a lane
change
The right hand signal will
flash until you release the
lever.
Move and hold the lever
partway to signal a lane
change
The left hand signal will flash
until you release the lever.

178
2-2. Instrument cluster
IS250/220d/200d_EE
Indicators
The indicators inform the driver of the operating state of the
vehicle’s various systems.
Turn signal indicator
(P. 170)(vehicles
with an
automatic
transmis-
sion)
“ECT SNOW” indica-
tor
(P. 162)
Headlight high beam
indicator (P. 186)(vehicles
with an
automatic
transmis-
sion)“ECT PWR” indicator
(P. 162)
Tail light indicator
(P. 186)
(if
equipped)
Cruise control indicator
(P. 198, 202)
Front fog light indicator
(P. 190)
(if
equipped)
Lexus parking assist-
sensor indicator (P.
217)
Rear fog light indicator
(P. 190)Slip indicator
(P. 224)
(vehicles with an automatic
VSC off indicator
(P. 224)
*1, 2
*1

246
2-5. Driving information
IS250/220d/200d_EE1110 mm (43.7 in.)
681 mm (26.8 in.)
360 mm (14.2 in.)
IS250:
Vehicles with
badges* 377 mm (14.8 in.)
Vehicles without
badges* 367 mm (14.4 in.)
Vehicles sold in Turkey,
Ukraine, Kazakhstan and
Belarus . 379 mm (14.9 in.)
IS220d and IS200d:
379 mm (14.9 in.)
10 mm (0.4 in.)
8 mm (0.3 in.)
*: Except Turkey, Ukraine,
Kazakhstan and Belarus
Tire information
Increase the tire inflation pressure to 20.0 kPa (0.2 kgf/cm2 or bar, 3 psi)
greater than the recommended value when towing. (P. 548)
Increase the air pressure of the trailer tires in accordance with the total
trailer weight and according to the values recommended by the manufac-
turer of your trailer.
Trailer lights
Check that the turn signal lights and stoplights are operating correctly every
time you hitch up the trailer. Directly wiring up to your vehicle may damage
the electrical system and stop the lights from functioning correctly.

271
3-2. Using the audio system
3
Interior features
IS250/220d/200d_EESpecifying program type
Press
.
Each time is pressed, the program type changes in the order of
“NEWS”“SPORTS”“TALK”“POP”“CLASSICS”.
Traffic information
Press .
TP mode: The system automatically switches to traffic informa-
tion when a broadcast with a traffic information signal
is received.
The station returns to the previous one when the traffic
information ends.
TA mode: Traffic information can be heard only when a signal is
received. The system switches to the mute mode when
a signal is not received. In the CD or MP3/WMA
mode, the system automatically switches to traffic
information when a signal is received.
The audio system returns to mute, CD or MP3/WMA
mode when the traffic information ends.
The audio system mode changes as follows each time is
pressed.
FM modes: “TP”“TA”off
Modes other than the radio modes: “TA”off
Emergency broadcast reception mode
“ALARM” appears in the display in the event that an emergency
broadcast is received, and the emergency broadcast is aired.

442
4-3. Do-it-yourself maintenance
IS250/220d/200d_EE
Fuse layout and amperage ratings
Engine compartment (type A fuse box)
Left-hand drive vehicles
Right-hand drive vehicles
FuseAmpereCircuit
1PWR HTR25 APower heater
2TURN-HAZ15 AEmergency flashers, turn signals
3IG2 MAIN20 AIG2, IGN, GAUGE
4RAD NO.230 AAudio
5D/C CUT20 ADOME, MPX-B
6RAD NO.130 A

449
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EE
15FR DOOR LH20 APower windows, outside rear view
mirror
16SECURITY7.5 ASmart entry & start system
17H-LP LVL7.5 AAutomatic headlight leveling sys-
tem
18LH-IG10 A
Charging system, headlight
cleaner, rear window defogger,
electric cooling fans, emergency
flashers, turn signal lights, back-up
lights, stop lights, outside rear
view mirror defoggers, seat belts,
Lexus parking assist-sensor, cruise
control, PTC heater, rear sunshade,
exhaust system
19FR WIP30 AWindshield wipers
FuseAmpereCircuit

454
4-3. Do-it-yourself maintenance
IS250/220d/200d_EE
Replacing light bulbs
Headlight low beams (vehicles with halogen bulbs)
Release the lock and remove
the cover.
Turn the bulb base counter-
clockwise.
Rear bulb locations
Rear fog lightRear turn signal
Back-up light
STEP1
STEP2

458
4-3. Do-it-yourself maintenance
IS250/220d/200d_EEBack-up lights and rear fog lights
Open the trunk door and
remove the trunk panel cover
clips.
Partly remove the trunk panel
cover and turn the bulb bases
counterclockwise.
Rear fog light
Back-up light
Remove the light bulb.
Rear fog light
Back-up light
Rear turn signal lights
Open the trunk door and
remove the cover.
STEP1
STEP2
STEP3
STEP1

459
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EETurn the bulb base counter-
clockwise.
Remove the light bulb.
Bulbs other than the above
If any of the bulbs listed below has burnt out, have it replaced by
any authorized Lexus dealer or repairer, or another duly quali-
fied and equipped professional.
Headlight high and low beams (discharge bulbs)
Front fog lights
Front turn signal lights
Side turn signal lights
Stop/tail lights
Tail lights
High mounted stoplight
License plate lights
Daytime running lights
Front position lights (vehicles with discharge headlights)
STEP2
STEP3

460
4-3. Do-it-yourself maintenance
IS250/220d/200d_EE
When replacing the front left headlight and front position light bulbs
Condensation build-up on the inside of the lens
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional, for more information in the following situations.
Temporary condensation build-up on the inside of the headlight lens does
not indicate a malfunction.
Large drops of water are built up on the inside of the lens.
Water has built up inside the headlight.
Discharge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on,
or may go out temporarily. The discharge bulbs will come on when normal
power is restored.
LED side turn signal lights, tail lights, stop/tail lights, high mounted stop-
light, license plate lights and front position lights (vehicles with discharge
headlights)
The side turn signal lights, tail lights, stop/tail lights, high mounted stop-
light, license plate lights and front position lights (vehicles with discharge
headlights) consist of a number of LEDs. If any of the LEDs burn out, take
your vehicle to any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional to have the light replaced.
Remove the securing bolt and move the
washer fluid filler opening to allow easy
access to the light bulbs.
After replacing the bulbs, make sure to
secure the washer fluid filler opening
with the bolt.
