Lexus IS220d 2011 Owner's Manual

5
535
5-2. Steps to take in an emergency
When trouble arises
IS250/220d/200d_EE
CAUTION
If the engine has to be turned off while driving
Power assist for the brakes and steering wheel will be lost, making the brake
pedal harder to depress and the steering wheel heavier to turn. Decelerate as
much as possible before turning off the engine.

536
5-2. Steps to take in an emergency
IS250/220d/200d_EE

6Vehicle specifications
533
6-1. Specifications
Maintenance data
(fuel, oil level, etc.)........ 534
Fuel information .............. 553
6-2. Customization
Customizable features...... 556

534
IS250/220d/200d_EE
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
Overall length4585 mm (180.5 in.)
Overall width1800 mm (70.9 in.)
Overall height*1
IS250
1425 mm (56.1 in.)
*2
1440 mm (56.7 in.)*3
IS220d and IS200d
1425 mm (56.1 in.)
*4
1440 mm (56.7 in.)*5
Wheelbase2730 mm (107.4 in.)
Tread
Front1535 mm (60.4 in.)
Rear1525 mm (60 in.)*4
1535 mm (60.4 in.) *5
Gross vehicle mass
IS250
2045 kg (4508 lb.)
IS220d and IS200d
2075 kg (4575 lb.)
Maximum permis-
sible axle capacityFront
IS250
1070 kg (2359 lb.)
IS220d and IS200d
1090 kg (2403 lb.)
Rear1150 kg (2535 lb.)
Drawbar load70 kg (154.4 lb.)
Towing capacity
with
brake1500 kg (3307 lb.)
without
brake560 kg (1235 lb.)

535
6-1. Specifications
6
Vehicle specifica-
IS250/220d/200d_EE
*1:Unladen vehicle
*2:Except in Turkey, Ukraine, Kazakhstan and Belarus (except 18-inch
tires)
*3:In Turkey, Ukraine, Kazakhstan and Belarus (18-inch tires)
*4:Models with 18-inch tires
*5:Models with 16-inch or 17-inch tires
Vehicle identification
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for
your vehicle. This is the primary identification number for your
Lexus. It is used in registering the ownership of your vehicle.
This number is stamped on the top left of the instrument panel or in
the engine compartment.
This number is also on the man-
ufacturer’s label.

536
6-1. Specifications
IS250/220d/200d_EEEngine number
The engine number is stamped on the engine block as shown.
IS250
IS220d and IS200d

537
6-1. Specifications
6
Vehicle specifica-
IS250/220d/200d_EE
Engine
Model4GR-FSE2AD-FHV, 2AD-FTV
Ty p e6-cylinder V type,
4-cycle, gasoline4 cylinder in line, 4
cycle, diesel
(with turbocharger)
Bore and stroke83.0  77.0 mm
(3.27 3.03 in.)86.0  96.0 mm
(3.39 3.78 in.)
Displacement2500 cm3
(152.5 cu.in.)2231 cm3
(136.1 cu.in.)
Drive belt tensionAutomatic adjustment

538
6-1. Specifications
IS250/220d/200d_EE
Fuel
IS250
IS220d and IS200d
Fuel type
EU area:
Unleaded gasoline conforming to European stan-
dard EN228 only
Except EU area:
Unleaded gasoline only
Research octane num-
ber95 or higher
Fuel tank capacity
(Reference)65 L (17.2 gal., 14.3 Imp. gal.)
Fuel type
EU area:
Diesel fuel conforming to European standard
EN590
Except EU area:
Diesel fuel that contains 50 ppm or less of sulfur
Cetane number48 or higher
Fuel tank capacity
(Reference)65 L (17.2 gal., 14.3 Imp. gal.)

539
6-1. Specifications
6
Vehicle specifica-
IS250/220d/200d_EE
Lubrication system
IS250
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up and turn off the engine, wait more than 5 min-
utes, and check the oil level on the dipstick.
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Lexus
recommends the use of approved “Toyota Genuine Motor Oil”.
Another motor oil of matching quality can also be used.
Oil grade:
0W-20, 5W-20, 5W-30 and 10W-30:
API grade SL “Energy-Conserving”, SM “Energy-Conserving”,
SN “Resource-Conserving” or ILSAC multigrade engine oil
15W-40 and 20W-50:
API grade SL, SM or SN multigrade engine oil
Oil capacity
(Drain and refill 
reference*)
With filter
Without filter
6.3 L (6.6 qt., 5.5 Imp. qt.)
5.9 L (6.2 qt., 5.2 Imp. qt.)

540
6-1. Specifications
IS250/220d/200d_EERecommended viscosity (SAE):
SAE 0W-20 is filled into your
Lexus vehicle at manufactur-
ing, and the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 oil is not avail-
able, SAE 5W-30 oil may be
used. However, it should be
replaced with SAE 0W-20 at
the next oil change.
If you use SAE 10W-30 or a
higher viscosity engine oil in
extremely low temperatures,
the engine may become diffi-
cult to start, so SAE 5W-30 or
lower viscosity engine oil is
recommended.
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which
allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil
when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is oper-
ated at high speeds, or under extreme load conditions.
Temperature range anticipated
before next oil change.
Preferred
