windshield wipers Lexus IS220d 2012 User Guide

193
2-3. Operating the lights and windshield wipers
2
When driving
IS250/220d/200d_EE
Rain-sensing windshield wipers
When is selected, the wipers will operate automatically
when the sensor detects falling rain. The system automatically
adjusts wiper timing according to rain volume and vehicle
speed.
The wiper operation is selected as follows by turning the switch
ring. When is selected, the sensor sensitivity can be also
adjusted:
Off
Rain-sensing wind-
shield wiper opera-
tion
Low speed wind-
shield wiper opera-
tion
High speed wind-
shield wiper opera-
tion
Temporary opera-
tion
Releasing the lever returns to

194
2-3. Operating the lights and windshield wipers
IS250/220d/200d_EE
Sensor sensitivity (high)
Sensor sensitivity (low)
Washer/wiper operation
Wipers operate automati-
cally. (After operating several
times, the wipers operate one
more time after a short delay
to prevent dripping.)

195
2-3. Operating the lights and windshield wipers
2
When driving
IS250/220d/200d_EE
The windshield wipers and washer can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
Effects of vehicle speed on wiper operation
Vehicle speed affects the following even when the wipers are not in
“AUTO” mode.
Intermittent wiper interval
Wiper operation when the washer is being used (delay until drip preven-
tion wiper sweep occurs)
Low speed wiper operation selected, wiper operation will be switched from
low speed to intermittent wiper operation only when the vehicle is station-
ary.
(However, the mode cannot be switched when the adjustment dial for the
intermittent wiper interval is set to the lowest setting.)
Raindrop sensor (vehicles with rain-sensing windshield wipers)
If the wiper switch is turned to “AUTO” position while the “ENGINE
START STOP” switch is in IGNITION ON mode, the wiper will operate
once to show that auto mode is activated.
If the temperature of the raindrop sensor is 90C (194F) or higher, or -
30C (-22F) or lower, automatic operation may not occur. In this case,
operate the wipers in any mode other than “AUTO”.
Outside rear view mirror defogger activation linked to windshield wiper
operation
The outside rear view mirror defogger automatically turns on when you
operate the windshield wipers.
The sensor judges the amount of rain-
drops.

196
2-3. Operating the lights and windshield wipers
IS250/220d/200d_EE
If no windshield washer fluid sprays
If there is washer fluid in the windshield washer fluid reservoir and no
washer fluid sprays, the nozzle may be blocked. In this case, contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional, and have your Lexus inspected.
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
Settings (e.g. drip prevention function) can be changed.
(Customizable features P. 556)
CAUTION
Caution regarding the use of windshield wipers in “AUTO” mode (vehicles
with rain-sensing windshield wipers)
The windshield wipers may operate unexpectedly if the sensor is touched or
the windshield is subject to vibration in “AUTO” mode. Take care that your
fingers or anything else do not become caught in the windshield wipers.
Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windscreen and cause low visibility. This
may lead to an accident, resulting in death or serious injury.
NOTICE
When the windshield is dry
Do not use the wipers, as they may damage the windshield.
When a nozzle becomes blocked
Do not try to clear it with a pin or other object. The nozzle will be damaged.
When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled
toward you and held continually.

197
2-3. Operating the lights and windshield wipers
2
When driving
IS250/220d/200d_EE
Headlight cleaner switch
The headlight cleaner can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode and the
headlight switch is turned on.
Windshield washer linked operation
Only for the first time when the windshield washer is operated after the
“ENGINE START STOP” switch is turned to IGNITION ON mode with the
headlights on, the headlight cleaners will also operate once. (P. 191)
When using the headlight cleaner
The washer fluid will spray out into the surrounding area and may get on
clothes, items etc. Therefore, check the surrounding area before using the
headlight cleaner.
NOTICE
When the washer fluid tank is empty
Do not use this function when the washer fluid tank is empty. This may
cause the washer fluid pump to overheat.
Washer fluid can be sprayed on the headlights.
Press the switch to clean the
headlights.
: If equipped

210
2-4. Using other driving systems
IS250/220d/200d_EE
Adjusting the speed setting:
P. 2 0 4
Canceling and resuming the
speed setting: P. 206
Dynamic radar cruise control can be set when
The shift lever is in the D or range 4 or higher of S has been selected.
Range 4 or higher has been selected by using the paddle shift.
(vehicles with paddle shift switch)
Vehicle speed is above approximately 50 km/h (30 mph).
Accelerating after setting the vehicle speed
The vehicle can accelerate normally. After acceleration, the set speed
resumes. However, during vehicle-to-vehicle distance control mode, the
vehicle speed may decrease below the set speed in order to maintain the dis-
tance to the vehicle ahead.
Automatic cancelation of vehicle-to-vehicle distance control
Vehicle-to-vehicle distance control driving is automatically canceled in the
following situations:
Actual vehicle speed falls below approximately 40 km/h (25 mph).
VSC is activated.
The sensor cannot operate correctly because it is covered in some way.
The windshield wipers are operating at high speed (when the wiper
switch is set to the “AUTO” mode or the high speed wiper operation
position).
When snow mode is set. (IS250 only)
If vehicle-to-vehicle distance control driving is automatically canceled for
any other reason, there may be a malfunction in the system. Contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.

389
4-1. Maintenance and care
4
Maintenance and care
IS250/220d/200d_EE
Aluminum wheels
Remove any dirt immediately by using a neutral detergent. Do not use
hard brushes or abrasive cleaners. Do not use strong or harsh chemical
cleaners.
Use the same mild detergent and wax as used on the paint.
Do not use detergent on the wheels when they are hot, for example after
driving for long distance in the hot weather.
Wash detergent from the wheels immediately after use.
Bumpers
Do not scrub with abrasive cleaners.
Outside rear view mirror rain-clearing coating (if equipped)
Observe the following precautions in order to retain the rain-clearing prop-
erties of the mirror.
Clean the mirrors using car shampoo or glass cleaner that does not con-
tain silicone or an abrasive compound, and rinse thoroughly with water.
Allow the mirrors to be exposed to direct sunlight for 1 to 2 days.
CAUTION
When cleaning the windshield (vehicles with rain-sensing windshield wip-
ers)
When the upper part of the windshield where the raindrop sensor is
located is touched by hand
When a wet rag or similar is held close to the raindrop sensor
If something bumps against the windshield
If you directly touch the raindrop sensor body or if something bumps into
the raindrop sensor
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the
wipers may operate unexpectedly in the
following situations, and may result in
hands being caught or other serious inju-
ries and cause damage to the wiper
blades.Off

390
4-1. Maintenance and care
IS250/220d/200d_EE
CAUTION
Caution about the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has
cooled sufficiently, as touching a hot exhaust pipe can cause burns.
NOTICE
To prevent paint deterioration and corrosion on the body and components
(aluminum wheels etc.)
Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If you see coal tar or tree sap on the paint surface
• If you see dead insects, insect droppings or bird droppings on the paint
• After driving in an area contaminated with soot, oily smoke, mine
dust, iron powder or chemical substances
• If the vehicle becomes heavily soiled in dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface
If the paint is chipped or scratched, have it repaired immediately.
To prevent the wheels from corroding, remove any dirt and store in a
place with low humidity when storing the wheels.
Cleaning the exterior lights
Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.
Do not apply wax on the surfaces of the lights.
Wax may cause damage to the lenses.
To prevent damage to the windshield wiper arms
When lifting the wiper arms away from the windshield, pull the driver side
wiper arm upward first, and repeat for the passenger side. When returning
the wipers to their original position, do so from the passenger side first.

391
4-1. Maintenance and care
4
Maintenance and care
IS250/220d/200d_EE
NOTICE
When using an automatic car wash (vehicles with rain-sensing windshield
wipers only)
Set the wiper switch to the off position.
If the wiper switch is in “AUTO”, the wipers may operate and the wiper
blades may be damaged.

449
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EE
15FR DOOR LH20 APower windows, outside rear view
mirror
16SECURITY7.5 ASmart entry & start system
17H-LP LVL7.5 AAutomatic headlight leveling sys-
tem
18LH-IG10 A
Charging system, headlight
cleaner, rear window defogger,
electric cooling fans, emergency
flashers, turn signal lights, back-up
lights, stop lights, outside rear
view mirror defoggers, seat belts,
Lexus parking assist-sensor, cruise
control, PTC heater, rear sunshade,
exhaust system
19FR WIP30 AWindshield wipers
FuseAmpereCircuit
