IS250/220d/200d_EE
5
3-7. Other interior features
Sun visors ........................... 362
Vanity mirrors .................... 363
Clock .................................. 364
Satellite switches ................ 365
Ashtrays ............................. 368
Cigarette lighter.................. 369
Power outlet ....................... 370
Seat heaters ........................ 371
Seat heaters and ventilators 374
Armrest............................... 377
Rear sunshade .................... 378
Trunk storage extension ..... 380
Coat hooks.......................... 381
Floor mat ............................ 382
Trunk features .................... 383
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior........... 388
Cleaning and protecting
the vehicle interior ........... 392
4-2. Maintenance
Maintenance requirements . 3954-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ....................... 398
Hood ................................... 401
Positioning a floor jack ...... 402
Engine compartment .......... 404
Tires ................................... 420
Tire inflation pressure ........ 424
Wheels................................ 426
Air conditioning filter ........ 428
Electronic key battery ........ 431
Checking and replacing
fuses ................................. 433
Light bulbs ......................... 448
5-1. Essential information
Emergency flashers ............ 458
If your vehicle needs to
be towed ........................... 459
If you think something is
wrong ............................... 465
Fuel pump shut off system . 466
4Maintenance and care
5When trouble arises

146
2-1. Driving procedures
IS250/220d/200d_EE
CAUTION
When starting the vehicle
With automatic transmission vehicles, always keep your foot on the brake
pedal while stopped with the engine running. This prevents the vehicle from
creeping.
When driving the vehicle
Do not drive if you are unfamiliar with the location of the brake and accel-
erator pedals to avoid depressing the wrong pedal.
• Accidentally depressing the accelerator pedal instead of the brake
pedal will result in sudden acceleration that may lead to an accident
that could result in death or serious injury.
• When backing up, you may twist your body around, leading to a diffi-
culty in operating the pedals. Make sure to operate the pedals properly.
• Make sure to keep a correct driving posture even when moving the
vehicle only slightly, allowing you to depress the brake and accelerator
pedals properly.
• Depress the brake pedal using your right foot. Depressing the brake
pedal using your left foot may delay response in an emergency, result-
ing in an accident.
Do not drive the vehicle over or stop the vehicle near flammable materi-
als.
With automatic transmission vehicles, do not let the vehicle roll back-
wards while the shift lever is in a driving position, or roll forward while
the shift lever is in R.
Doing so may cause the engine to stall or lead to poor brake and steering
performance, resulting in an accident or damage to the vehicle.
If the smell of exhaust is noticed inside the vehicle, open the windows and
check that the trunk is closed. Large amounts of exhaust in the vehicle can
cause driver drowsiness and an accident, resulting in death or a serious
health hazard. Have the vehicle inspected by any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional, immedi-
ately.

150
2-1. Driving procedures
IS250/220d/200d_EE
When driving on slippery road surfaces
Sudden braking, acceleration and steering may cause tire slippage and
reduce your ability to control the vehicle, resulting in an accident.
Sudden changes in engine speed, such as engine braking caused by up-
shifting or down-shifting, may cause the vehicle to skid, resulting in an
accident.
After driving through a puddle, lightly depress the brake pedal to make
sure that the brakes are functioning properly. Wet brake pads may prevent
the brakes from functioning properly. If the brakes on only one side are
wet and not functioning properly, steering control may be affected, result-
ing in an accident.
When shifting the shift lever
With automatic transmission vehicles, be careful not to shift the shift lever
with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may
cause an accident and result in death or serious injury.
If you hear a squealing or scraping noise (brake pad wear indicators)
Have the brake pads checked and replaced by any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional, as soon as
possible.
Rotor damage can result if the pads are not replaced when needed.
Front brake only: Moderate levels of brake pad and disc wear allow
enhanced front braking power. As a result, the discs may wear more quickly
than conventional brake discs. Therefore, when replacing the brake pads,
Lexus recommends that you also have the thickness of the discs measured.
It is dangerous to drive the vehicle when the wear limits of the brake pads
and/or those of the brake discs are exceeded.
When the vehicle is stopped
Do not race the engine.
If the vehicle is in any gear other than P (vehicles with an automatic trans-
mission only) or N the vehicle may accelerate suddenly and unexpectedly,
and may cause an accident.
Do not leave the vehicle with the engine running for a long time.
If such a situation cannot be avoided, park the vehicle in an open space
and check that exhaust fumes do not enter the vehicle interior.

157
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Manual transmission
Check that the parking brake is set.
Check that the shift lever is set in N.
Firmly depress the clutch pedal.
The “ENGINE START STOP” switch indicator turns green.
Press the “ENGINE START
STOP” switch.
indicator turns on. The
engine begins starting after
the indicator light goes out.
The engine will crank until it
starts or for up to 30 seconds,
whichever is less.
Continue depressing the
clutch pedal until the engine
is completely started.
The engine can be started
from any “ENGINE START
STOP” switch mode.
STEP1
STEP2
STEP3
STEP4

170
2-1. Driving procedures
IS250/220d/200d_EE
Turn signal lever
Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Right turn
Left turn
Move and hold the lever
partway to signal a lane
change
The right hand signal will
flash until you release the
lever.
Move and hold the lever
partway to signal a lane
change
The left hand signal will flash
until you release the lever.

179
2-2. Instrument cluster
2
When driving
IS250/220d/200d_EE
*1:These lights turn on when the “ENGINE START STOP” switch is
turned to IGNITION ON mode to indicate that a system check is
being performed. They will turn off after the engine is started, or
after a few seconds. There may be a malfunction in a system if a
light does not come on, or if the lights do not turn off. Have the
vehicle inspected by any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional, for details.
*2:The light flashes to indicate that the system is operating
(if
equipped)
Daytime running light
system off indicator
(P. 188)SRS airbag on-off indi-
cator (P. 140)
(vehicles
with a man-
ual trans-
mission)Engine preheating indi-
cator (P. 156)
*1

180
2-2. Instrument cluster
IS250/220d/200d_EE
CAUTION
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional, immedi-
ately if this occurs.
Warning lights
Warning lights inform the driver of malfunctions in any of the
vehicle’s systems. (P. 467)
*:These lights turn on when the “ENGINE START STOP” switch is
turned to IGNITION ON mode to indicate that a system check is
being performed. They will turn off after the engine is started, or
after a few seconds. There may be a malfunction in a system if a
light does not come on, or if the lights do not turn off. Have the
vehicle inspected by any authorized Lexus dealer or repairer, or
(vehicles
with a
manual
transmis-
sion)
(if equipped)(for
driver)(for front
passen-
ger)
*****
*****

197
2-3. Operating the lights and windshield wipers
2
When driving
IS250/220d/200d_EE
Headlight cleaner switch
The headlight cleaner can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode and the
headlight switch is turned on.
Windshield washer linked operation
Only for the first time when the windshield washer is operated after the
“ENGINE START STOP” switch is turned to IGNITION ON mode with the
headlights on, the headlight cleaners will also operate once. (P. 191)
When using the headlight cleaner
The washer fluid will spray out into the surrounding area and may get on
clothes, items etc. Therefore, check the surrounding area before using the
headlight cleaner.
NOTICE
When the washer fluid tank is empty
Do not use this function when the washer fluid tank is empty. This may
cause the washer fluid pump to overheat.
Washer fluid can be sprayed on the headlights.
Press the switch to clean the
headlights.
: If equipped

4Maintenance and care
387
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 388
Cleaning and protecting
the vehicle interior ......... 392
4-2. Maintenance
Maintenance
requirements .................. 395
4-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions..................... 398
Hood ................................ 401
Positioning a floor jack .... 402
Engine compartment ........ 404
Tires ................................. 420
Tire inflation pressure ...... 424
Wheels ............................. 426
Air conditioning filter ...... 428
Electronic key battery ...... 431
Checking and replacing
fuses ............................... 433
Light bulbs ....................... 448

453
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EE
Light bulbs
You may replace the following bulbs yourself. For more information
about replacing other light bulbs, contact any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional.
Preparing a replacement light bulb
Check the wattage of the light bulb being replaced. (P. 552)
Removing the engine compartment cover
P. 407
Front bulb locations
Headlight low beam
(halogen bulb)Front position
Headlight high
