recommended oil Lexus IS250 2007 Using the audio system / LEXUS 2007 IS350/250 OWNER'S MANUAL (OM53578U)

259
4-2. Maintenance
4
Maintenance and care
General maintenance
Engine compartment
ItemsCheck points
BatteryMaintenance-free. (P. 2 7 9 )
Brake fluidAt the correct level? (P. 2 7 8 )
Engine coolantAt the correct level? (P. 2 76 )
Engine oilAt the correct level? (P. 2 7 2 )
Exhaust systemNo fumes or strange sounds?
Radiator/condenser/hosesNot blocked with foreign matter?
(P. 2 7 8 )
Wa s h e r f l u i dAt the correct level? (P. 2 8 2 )
Listed below are the general maintenance items that should be performed
at the intervals specified in the “Warranty and Services Guide” or “Owners
Manual Supplement”. It is recommended that any problem you notice
should be brought to the attention of your Lexus dealer or qualified service
shop for advice.

274
4-3. Do-it-yourself maintenance
■Recommended viscosity
SAE 5W-30 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 5W-30 is not available, SAE
10W-30 may be used. However, it
should be replaced with SAE 5W-
30 at the next oil change.
■How to read oil container labels
Some oil containers are labeled with ILSAC certification marks that
help you to select the proper oil.
Temperature range anticipated before
next oil change.

384
6-1. Specifications
Lubrication system
*: 5W-30 is an oil that provides optimal levels of fuel efficiency.
Oil viscosity
●The 5W portion of the oil viscosity rating indicates the characteristic of
the oil which allows cold startability. Oils with a lower value before the W
allow for easier starting of the engine in cold weather.
●The 30 in 5W-30 indicates the oil viscosity when the oil is at its operating
temperature. An oil with a higher viscosity may be better suited if the
vehicle is operated at high speeds, or under extreme load condition.
IS250IS350
Oil capacity
(drain and refill)
with filter
2WD models
AWD models
6.6 qt. (6.3 L, 5.5 lmp.qt.)
6.8 qt. (6.4 L, 5.7 lmp.qt.)6.6 qt. (6.3 L, 5.5 lmp.qt.)

without filter
2WD models
AWD models
6.2 qt. (5.9 L, 5.2 lmp.qt.)
6.3 qt. (6.0 L, 5.3 lmp.qt.)6.2 qt. (5.9 L, 5.2 lmp.qt.)

Oil gradeILSAC multi-grade engine oil
Recommended oil
viscosity
Use Lexus approved "Toyota Genuine Motor Oil" or
equivalent to satisfy the above grade and viscosity.
Temperature range anticipated before
next oil change

387
6-1. Specifications
6
Vehicle specifications
Automatic Transmission
Manual transmission
Clutch
IS350IS250 (2WD)IS250 (AWD)
Fluid capacity
Drain and refill1.9 qt.
(1.8 L, 1.6 lmp.qt.)1.9 qt.
(1.8 L, 1.6 lmp.qt.)3.0 qt.
(2.8 L, 2.5 lmp.qt.)
Fluid typeTo y o t a G e n u i n e AT F W S
NOTICE
Using automatic transmission fluid other than "Toyota Genuine ATF WS" may cause
deterioration in shift quality, locking up of your transmission accompanied by vibra-
tion, and ultimately damage the automatic transmission of your vehicle.
Gear oil capacity1.9 qt. (1.8 L, 1.6 Imp.qt.)
Gear oil typeAPI GL-5
Recommended gear oil viscositySAE75W-90
NOTICE
Using manual transmission gear oil other than "TOYOTA Genuine Manual Transmis-
sion Gear Oil API GL-5" may cause occurrence of gear noise or other deterioration.
Clutch free play0. 2  0.6 in. (5  15 mm)
Fluid typeSAE J1703 or FMVSS No.116 DOT 3

427
GAS STATION INFORMATION
Auxiliary catch lever
P. 2 6 6Trunk opener
P. 2 3Fuel filler door
P. 5 1
Hood lock release lever
P. 2 6 6Fuel filler door opener
P. 5 1Tire inflation pressure
P. 3 8 9
Fuel tank capacity17.2 gal. (65L, 14.3 lmp.gal.)
Fuel typeUnleaded gasoline only P. 52, 383
Cold tire inflation
pressureP. 3 8 9
Engine oil capacity
(Drain and refill)
qt. (L, Imp.qt.)
IS250 IS250
(2WD models) (AWD models) IS350
With filler 6.6 (6.3, 5.5) 6.8 (6.4, 5.7) 6.6 (6.3, 5.5)
Without filler 6.2 (5.9
, 5.2)6.3 (6.0, 5.3) 6.2 (5.9, 5.2)
Engine oil type
Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 384
Recommended oil viscosity: SAE-5W-30
