512
6-1. Specifications
Lubrication systemIS250
■ Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the follow-
ing grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced with
SAE 0W-20 at the next oil
change.
Oil capacity
(Drain and refill 
reference)
without filter
2WD models
AWD models
6.2 qt. (5.9 L, 5.2 Imp. qt.)
6.3 qt. (6.0 L, 5.3 Imp. qt.)
with filter
2WD models
AWD models
6.6 qt. (6.3 L, 5.5 Imp. qt.)
6.7 qt. (6.4 L, 5.6 Imp. qt.)
Outside temperature

516
6-1. Specifications
Electrical system
DifferentialFront
Rear
*: “Toyota Genuine Differential Gear Oil” is put in your Lexus vehicle at the fac- tory. Use Lexus approved “T oyota Genuine Differential Gear Oil” or an equiv-
alent of matching quality to satisfy the above specification. Please contact your
Lexus dealer for further details.
Battery
Open voltage* at
68 F (20 C):12.6 12.8 V Fully charged
12.2 
12.4 V Half charged
11.8 
12.0 V Discharged
(*: Voltage checked 20 minutes after
the engine and all the lights are turned
off)
Charging rates5 A max.
Oil capacity0.74 qt. (0.70 L, 0.61 Imp. qt.)
Oil typeHypoid gear oil API GL-5
Oil viscosityAbove 0 F (-18 C): SAE90
Below 0 F (-18 C): SAE80W or SAE80W-90
Oil capacity
IS350:
1.42 qt. (1.35 L, 1.19 Imp. qt.)
IS250: 1.20 qt. (1.15 L, 1.01 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential Gear Oil LT 75W-85
GL-5 or equivalent

533
6-1. Specifications
6
Vehicle specifications
■Temperature A, B, C
The temperature grades are A (the hi ghest), B, and C, representing
the tire's resistance to the generation of heat and its ability to dissipate
heat when tested under controlled conditions on a specified indoor
laboratory test wheel.
Sustained high temperature can cause the material of the tire to degenerate
and reduce tire life, and excessive temperature can lead to sudden tire fail-
ure.
The grade C corresponds to a level of performance which all passenger car
tires must meet under the Federal Mo tor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory
test wheel than the minimum required by law.
Warning: The temperature grades for this tire are established for a tire that
is properly inflated and not overloaded.
Excessive speed, underinflation, or excess ive loading, either separately or in
combination, can cause heat build up and possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipped, air conditioning and
additional weight optional engine

567
Alphabetical index
Engine compartment cover............. 388
Engine coolantCapacity...................................................515
Checking ............................................... 392
Preparing and checking before winter ......................................195
Engine coolant temperature gauge ........................................................ 151
Engine immobilizer system ................. 85
Engine oil Capacity................................................... 512
Checking ............................................... 389
Preparing and checking before winter ......................................195
Engine oil maintenance data ............. 391
EPS...............................................................185
Event data recorder............................ 459
First-aid kit storage belt......................347
Floor mat.................................................. 346
Fluid Brake ....................................................... 394
Washer ................................................... 399
Fog lights Switch ........................................................168
Wattage ................................................. 524
Footwell lights.......................................... 315
Front fog lights Switch ........................................................168
Wattage ................................................. 524 Front passenger occupant
classification system .......................... 104
Front passenger's seat belt reminder light...................................... 463
Front seats Adjustment .................................................51
Driving position memory .................. 53
Front turn signal lights Switch.........................................................147
Wattage ..................................................524
Fuel Capacity .................................................... 511
Fuel gauge................................................ 151
Fuel pump shut off system............ 458
Gas station information ..................576
Information ............................................525
Refueling.................................................... 82
Fuel door ..................................................... 82
Fuel filler door ........................................... 82
Fuel pump shut off system .................458
Fuses .......................................................... 423
Garage door opener ......................... 350
Gas station information...................... 576
Gauges ........................................................151
Glove box ................................................320
Glove box light ......................................320
F
G

569
Alphabetical index
Light bulbsReplacing............................................... 439
Wattage ................................................. 524
Lights Door courtesy lights .......................... 315
Emergency flasher switch ............. 450
Fog light switch.....................................168
Hazard light switch........................... 450
Headlights switch ................................165
Interior light switch.............................. 317
Outer foot lights................................... 315
Overhead courtesy light ................. 315
Personal light switch .......................... 317
Replacing light bulbs ....................... 439
Scuff lights ............................................... 315
Shift lever light ....................................... 315
Turn signal lever................................... 147
Vanity lights ...........................................327
Wattage ................................................. 524
Load capacity .......................................... 194
Maintenance Do-it-yourself maintenance .........380
General maintenance ..................... 376
Maintenance data ............................ 508
Maintenance requirements ...........374
Manual transmission ............................. 145
Meter Instrument panel light control ....... 152
Meters .........................................................151
Micro dust and pollen filter ................ 210 Mirrors
Inside rear view mirror ....................... 70
Side mirror heater ...............................214
Side mirrors ............................................. 72
Vanity mirrors ...................................... 327
Moon roof ................................................... 78
MP3 disc .................................................. 234
Multi-information display ................... 160
Noise from under vehicle...................... 19
Odometer...................................................151
Oil Engine oil............................................... 389
Opener Fuel filler door ......................................... 82
Hood ....................................................... 383
Trunk ........................................................... 47
Outer foot lights Outer foot lights .................................. 315
Wattage ..................................................524
Outside rear view mirrors Adjusting and folding.......................... 72
Mirror position memory ....................53
Outside temperature display ............. 161
Overhead console ............................... 322
Overhead courtesy lights Overhead courtesy lights............... 315
Wattage ..................................................524
Overheating, Engine............................ 501L
M
N
O

573
Alphabetical index
Warning buzzersBrake system ......................................... 461
Open door .......................................... 463
Seat belt reminder ............................ 463
Warning lights Anti-lock brake system .................. 462
Brake assist system .......................... 462
Brake system ......................................... 461
Charging system ............................... 462
Electric power steering warning light ..................................... 462
Low fuel level....................................... 463
Malfunction indicator lamp .......... 462
Master warning light ........................ 463
Open door ........................................... 463
Pretensioners ...................................... 462
Seat belt reminder light .................. 463
SRS airbags .......................................... 462
Tire pressure warning light........................................................ 463
Warning messages AWD system ......................................... 471
Engine oil level .....................................473
Engine oil maintenance...................473
Engine oil pressure........................... 470
Hood ........................................................473
Intuitive parking assist ........... 471, 473
Moon roof ..............................................473
Open door ............................................473
Parking brake .......................................473 Smart access system with
push-button start ............................ 477
Steering lock...........................................471
Tire pressure warning system...................... 471, 473
Trunk ........................................................ 473
Washer fluid ......................................... 473
Washer Checking .............................................. 399
Preparing and checking before winter ..................................... 195
Switch........................................................ 169
Washing and waxing ...........................368
Weight Cargo capacity ...................................... 191
Load limits .............................................. 194
Weight.................................................... 508
Wheels ....................................................... 416
Window glasses ...................................... 75
Window lock switch ............................... 75
Windows Power windows ..................................... 75
Rear window defogger.....................214
Washer .................................................... 169
Windshield wipers................................. 169
Windshield wiper de-icer................... 215
Wireless remote control key Replacing the battery.........................421
WMA disc ............................................... 234W

576
GAS STATION INFORMATION
Auxiliary catch leverP. 3 8 3Trunk openerP. 4 7Fuel filler door P. 8 2
Hood lock release lever P. 3 8 3Fuel filler door openerP. 8 2Tire inflation pressureP. 5 1 9
Fuel tank capacity
(Reference)17.2 gal. (65 L, 14.3 Imp. gal.)
Fuel typeUnleaded gasoline only P. 83, 511
Cold tire inflation
pressureP. 5 1 9
Engine oil capacity
(Drain and refill 
reference)qt. (L, Imp. qt.)
(2WD models) (AWD models)
Without filter 6.2 (5.9
, 5.2)6.3 (6.0, 5.3)
With filter 6.6 (6.3, 5.5) 6.7 (6.4, 5.6)
Engine oil typeToyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 512
