display Lexus IS250 2011 Opening, Closing And Locking The Doors And Trunk / LEXUS 2011 IS250/IS350 OWNERS MANUAL QUICK GUIDE (OM53A38U)

2
Hands-free System For Cellular Phone (without navigation system)
Bluetooth® phone pairing ........................................................................................................ 38
Calling by number .........................................................................................................................39
Calling by name..............................................................................................................................39
Calling by speed dial ....................................................................................................................40
Phonebook transfer ....................................................................................................................... 41
Changing the registered name................................................................................................ 42
Registering a speed dial.............................................................................................................. 43
Head Restraints ..................................................................................................................................... 12
Headlight Cleaner ...............................................................................................................................30
Headlights ............................................................................................................................................... 26
Hood.......................................................................................................................................................... 66
Instrument Panel Light Control......................................................................................................30
Interior Lights ......................................................................................................................................... 57
Intuitive Parking Assist....................................................................................................................... 24
Keys .............................................................................................................................................................. 6
Lexus Enform with Safety Connect ...............................................................................................61
Luggage Mat..........................................................................................................................................53
Manual Transmission........................................................................................................................... 19
Moon Roof .............................................................................................................................................. 64
Multi-information Display .................................................................................................................20
Outside Rear View Mirrors.............................................................................................................. 13
Parking Brake ......................................................................................................................................... 19
Power Windows ................................................................................................................................... 64
Rear Sunshade ...................................................................................................................................... 57
Rear Window and Outside Rear View Mirror Defoggers ................................................30
Safety Connect .....................................................................................................................................59
Satellite Switches................................................................................................................................... 21
Seat Belts .................................................................................................................................................. 12
Seat Heaters / Seat Heaters and Ventilators ..........................................................................54
Seats (Manual) ......................................................................................................................................... 9
Seats (Power) ......................................................................................................................................... 10
Smart Access System with Push-button Start ............................................................................ 7
Steering Wheel ...................................................................................................................................... 14
Theft Deterrent System ........................................................................................................................8
Trunk.......................................................................................................................................................... 67
Trunk Storage Extension ................................................................................................................. 58
Turn Signal Lever ................................................................................................................................. 22
Windshield Wipers and Washer ...................................................................................................28

3
OverviewInstrument Panel
Shift paddle switch (automatic transmission)
P.17, 18
Headlight switch
Turn signal lever Fog light switch P.26
P.22
P.27
Headlight cleaner switch P.30
Rear sunshade switch P.57
Inside lock button P.63
Fuel filler door opener P.65
Driving position
memory switches
P.11
Power window switches P.64
Window lock switch P.64
Outside rear view
mirror switches
P.13
Trunk opener P.67
Hood release lever P.66
Parking brake pedal
(automatic transmission)
P.19
Satellite switches P.21
Tilt and telescopic steering lock release lever
 P.14Tilt and telesc opic steering
control switch
 P.14
Multi-information
display
P.20
Door lock switches P.63

8
Theft Deterrent System
■Engine immobilizer system
The engine immobilizer system prevents the
engine from being started in the event that an
attempt is made to start the vehicle using an
unregistered key.
The security indicator light flashes to indicate that
the system is set.
■Alarm
The system sounds the alarm and flashes lights when forcible entry is detected.
To set the alarm: lock all the doors from outside the vehicle. The security indicator light
comes on to indicate that the alarm is in its preparation state. When the indicator light
begins to flash, the system is armed.
To deactivate or stop the alarm: turn the “ENGINE START STOP” switch to ACCESSORY
or IGNITION ON mode, start the engine or unlock the doors or trunk.
■Steering lock
The steering wheel locks when the “ENGINE
START STOP” switch is OFF.
When the steering lock cannot be released, the
green indicator light on the “ENGINE START
STOP” switch will flash and a message will be
shown on the multi-information display. To release
it, gently turn the wheel left or right while pressing
the “ENGINE START STOP” switch.
The theft deterrent system includes the following features to help protect your vehicle from
theft.

20
Multi-information Display
■Display information
●Trip information
Outside temperature
Driving range
Average fuel consumption
Average fuel consumption after refueling
Current fuel consumption
Average vehicle speed
Gear position display (automatic transmis-
sion only)
●Satellite switch mode display
●Intuitive parking assist display
(if equipped)
●Wa r n i n g m e s s a g e s
■Changing the display of trip information
Trip information items can be switched by press-
ing the DISP switch.
The multi-information display shows information about your vehicle, including the items
shown below.
Ty p e ATy p e B
■When using intuitive parking assist, the appropriate display is shown on the screen.
■In the event that a problem is detected in any of the vehicle's systems, a warning message is
shown on the multi-information display.

21
Satellite Switches
The satellite switches can be used to change the
settings of the following items.
●Intuitive parking assist (if equipped)
●Tire pressure warning system initialization
●ID code selection for the tire pressure warning
system
●Vehicle speed indicator
●Tacho indicator
■Changing the ON/OFF settings
To cycle through the functions, press either the
left or right selector switch.
To change the settings, press the ON/OFF
button.
The satellite switches can be used to change the settings of various functions. Settings
are shown on the multi-information display.
For detailed information of changing the settings, see the Owner’s Manual.

24
Intuitive Parking Assist (If Equipped)
Owners of models equipped with a navigation system should refer to the “Navigation System
Owner's Manual”.
■Turning the system on and off
The system can be turned on and off using the satellite switch. (P. 2 1 )
■Multi-information display
Sensors are used to detect obstacles near the
vehicle. The distance to a detected obstacle is
shown by the number of indicator bars.
Indicates obstacles detected by the corner
sensors
Indicates obstacles detected by the back sen-
sors
The system uses a screen display and buzzer to inform the driver of obstacles near the
vehicle when parking or driving at low speed.
1
2

31
Hands-free System For Cellular Phone
(with navigation system)
■Bluetooth® phone pairing
Compatible Bluetooth®-equipped phones can be connected to the vehicle, enabling
hands-free operation. Please refer to the cellular phone manufacturer's user guide for pair-
ing procedures, or go to “www.lexus.com/bluetooth” for more phone information.
To use a Bluetooth
® phone, it is necessary to first
register it in the system.
Push the button on the side of the touch
screen.
To u c h .
To u c h .
Touch to display the screen for
connecting Bluetooth.
Enter the passcode displayed on the screen
into the phone.
Refer to the cellular phone user's manual for
cellular phone operation.
When the connection is completed,
will appear
and push the button.
STEP3
STEP2
STEP5

38
Hands-free System For Cellular Phone
(without navigation system)
■Bluetooth® phone pairing
Compatible Bluetooth®-equipped phones can be connected to the vehicle, enabling
hands-free operation. Please refer to the cellular phone manufacturer's user guide for pair-
ing procedures, or go to“www.lexus.com/bluetooth” for more phone information.
To use a Bluetooth
® phone, it is necessary to first
register it in the system.
Press or .
Press and say “Pair phone”.
Press and say a name*.
*: This name will be used to identify your
phone in the case that more than one
phone has been registered to the system.
Press and say “Confirm” to display the
passkey.
Enter the passkey shown on the display into
the phone.
Refer to the cellular phone user's manual for
cellular phone operation.
Once the voice guidance for registration com-
pletion is finished, press .STEP1
: Pressing this switch turns the speech command system on. Say a command after
the beep.

41
■Phonebook transfer
Press .
Press and say “Phone book”.
Press and say “Add entry”.
Press and say “By phone”.
Press and say “Confirm”.
Transfer the phonebook data to the system
using the cellular phone.
Refer to the cellular phone user’s manual for
cellular phone operation.
Press and say “Previous” or “Next” until
the desired data is displayed.
Press and say “Confirm”.
Press and say the desired name.
Press and say “Confirm”.
Press and say “Confirm” again.STEP1
10
11
Phonebook transfer may not be possible depending on phone model.
: Pressing this switch turns the speech command system on. Say a command after
the beep.

48
■Loading a CD
Press the “LOAD” button.
“WAIT” is shown on the display.
Insert a CD when the indicators on the slot turn from amber to green.
The display changes from “WAIT” to “LOAD”.
■Loading multiple CDs
Press and hold the “LOAD” button until you hear a beep.
“WAIT” is shown on the display.
Insert a CD when the indicators on the slot turn from amber to green.
The display changes from “WAIT” to “LOAD”.
The indicators on the slot turn to amber when the CD is inserted.
Insert the next CD when the indicators on the slot turn from amber to green again.
Repeat the procedure for the remaining CDs.
To cancel the operation, press the “LOAD” button. If you do not insert a CD within 15
seconds, loading will cancelled automatically.
