Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manual s so you will have a better
understanding of your vehicle’ s capabilities and limitations.
1
Air Conditioning System (with navigation system)*
Using the automatic mode ....................................................................................................... .50
Adjusting the temperature ...................................................................................................... .. 50
To turn off the airflow ........................................................................................................ ........... 50
Air Conditioning System (w ithout navigation system)
Using the automatic mode ....................................................................................................... .63
Adjusting the temperature ...................................................................................................... .. 63
To turn off the airflow ........................................................................................................ ........... 63
Audio System (with navigation system)*
Basic operation ................................................................................................................ .............. 46
Radio.......................................................................................................................... ......................... 46
DVD player/CD player........................................................................................................... ....47
Operating an iPod .............................................................................................................. .......... 49
Remote control (steering wheel switches) ......................................................................... 49
Audio System (without navigation system)
Basic operation ................................................................................................................ .............. 57
Radio.......................................................................................................................... ......................... 58
CD player ......................................................................................................................................... 59
Operating an iPod .............................................................................................................. .......... 62
Remote control (steering wheel switches) ......................................................................... 62
Automatic Transmission ...................................................................................................................15
Cruise Control ............................................................................................................................... ......22
Door Locks ............................................................................................................................................ 69
ECT Switch (Automat ic Transmission).................................................................................... 20
Engine (ignition) Switch .................................................................................................................... 14
ETCS Switch (Manual Transmission) ......................................................................................... 21
Fog Lights ............................................................................................................................................... 24
Fuel Tank Cap ............................................................................................................................... ......... 71
Hands-free System For Cellular Phone (with navigation system)* Bluetooth
® phone pairing......................................................................................................... 39
Phonebook transfer ..................................................................................................................... 40
Registering a voice tag ........................................................................................................ ......... 41
Registering a speed dial ....................................................................................................... ...... 42
Calling by name ............................................................................................................................. 43
Calling by speed dial.......................................................................................................... .......... 44
Receiving a call............................................................................................................... ................ 45
Hands-free System For Cellular Phone (without navigation system)*
Bluetooth
® phone pairing...........................................................................................................51
Calling by number .............................................................................................................. .......... 52
Calling by name ............................................................................................................................. 52
Calling by speed dial.......................................................................................................... .......... 53
*: This feature may be operated by Voice command (See P.64)

46
Audio System (with navigation system)
The button positions, shapes and screen may slightly vary depending on the type of the
audio system.
■ Basic operation
Displays the audio control screen
Sound quality modes
Audio sources
Ty p e A
AM•FM: AM radio/FM radio
SAT: Satellite radio
DISC: DVD player (if equipped)
CD: CD player (if equipped)
AUX•USB: Auxiliary audio device/USB
memory/iPod/Bluetooth
®
audio player
Ty p e B
AM: AM radio
FM: FM radio
DISC: DVD player (if equipped)
CD: CD player (if equipped)
AUX: Auxiliary audio device/USB mem-
ory/iPod/Bluetooth
® audio player
Pow e r/ Vo l u m e
■ Radio
Displays the audio control screen
Station presets
Scanning radio stations
Radio tuner
Station select
Seek
1
2
3
4
1
2
3
4
5
6

47
■Entering station presets
Touch the desired station by using the tune, seek or scan function.
Press and hold one of the preset buttons (1-6 ) until you hear a beep, indicating that the
station is set.
■ DVD player/CD player
■
Playing an audio CD
Displays the audio control screen
Disc select
Repeat play
Random playback
Search playback
Disc load
Eject
Track select/rewind/fast-forward
■Playing a CD with MP3/WMA files
Displays the audio control screen
Disc select
Repeat play
Random playback
Search playback
Folder select
File select
Disc load
Eject
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9

48
■Playing a DVD (DVD player only)
Displays the audio control screen
Disc select
DVD operation
Image display (full screen)
Disc load
Eject
Chapter select/rewind/fast-forward
■Loading a disc
Press the “LOAD” button.
When the indicator changes from flashing amber to green, insert a disc after the disc slot
door opens.
■Loading multiple discs
Press and hold the “LOAD” button until you hear a beep.
When the indicator changes from flashing amber to green, insert a disc after the disc slot
door opens.
After inserting a disc, wait until the indicator changes from flashing amber to green, then
insert the next disc after th e disc slot door has opened.
Repeat and until you have inserted all discs.
To cancel the operation, press the “LOAD” button. If you do not insert a disc within 15 sec-
onds, loading will be canceled automatically.
1
2
3
4
5
6
7

57
Audio System (without navigation system)
Owners of models equipped with a navigation system should refer to the “Navigation System
Owner's Manual”.
■Basic operation
Ty p e A
Sound quality modes
Automatic Sound Levelizer (ASL)
Mute
Audio sources
AM
FM: AM radio/FM radio
SAT: Satellite radio
CD•AUX: CD player/Auxiliary audio
device/USB memory/iPod/
Bluetooth
® audio player
Po w e r/ Vo l u m e
Ty p e B Sound quality modes
Automatic Sound Levelizer (ASL)
Mute
Audio sources
AM: AM radio
FM: FM radio
CD: CD player
AUX: Auxiliary audio device/USB mem-
ory/iPod/Bluetooth
® audio player
Po w e r/ Vo l u m e
1
2
3
4
5
1
2
3
4
5

59
■CD player
■
Playing an audio CD
Ty p e A Random playback
Repeat play
Pa u s e / P l a y b a c k
Text information
Disc select
Disc load
Search playback
Playback
Eject
Track select/rewind/fast-forward
Ty p e B Random playback
Repeat play
Pa u s e / P l a y b a c k
Text information
Disc select
Disc load
Playback
Eject
Track select/rewind/fast-forward
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
