Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manual s so you will have a better
understanding of your vehicle’ s capabilities and limitations.
1
Air Conditioning System (with navigation system)*
Using the automatic mode ....................................................................................................... .50
Adjusting the temperature ...................................................................................................... .. 50
To turn off the airflow ........................................................................................................ ........... 50
Air Conditioning System (w ithout navigation system)
Using the automatic mode ....................................................................................................... .63
Adjusting the temperature ...................................................................................................... .. 63
To turn off the airflow ........................................................................................................ ........... 63
Audio System (with navigation system)*
Basic operation ................................................................................................................ .............. 46
Radio.......................................................................................................................... ......................... 46
DVD player/CD player........................................................................................................... ....47
Operating an iPod .............................................................................................................. .......... 49
Remote control (steering wheel switches) ......................................................................... 49
Audio System (without navigation system)
Basic operation ................................................................................................................ .............. 57
Radio.......................................................................................................................... ......................... 58
CD player ......................................................................................................................................... 59
Operating an iPod .............................................................................................................. .......... 62
Remote control (steering wheel switches) ......................................................................... 62
Automatic Transmission ...................................................................................................................15
Cruise Control ............................................................................................................................... ......22
Door Locks ............................................................................................................................................ 69
ECT Switch (Automat ic Transmission).................................................................................... 20
Engine (ignition) Switch .................................................................................................................... 14
ETCS Switch (Manual Transmission) ......................................................................................... 21
Fog Lights ............................................................................................................................................... 24
Fuel Tank Cap ............................................................................................................................... ......... 71
Hands-free System For Cellular Phone (with navigation system)* Bluetooth
® phone pairing......................................................................................................... 39
Phonebook transfer ..................................................................................................................... 40
Registering a voice tag ........................................................................................................ ......... 41
Registering a speed dial ....................................................................................................... ...... 42
Calling by name ............................................................................................................................. 43
Calling by speed dial.......................................................................................................... .......... 44
Receiving a call............................................................................................................... ................ 45
Hands-free System For Cellular Phone (without navigation system)*
Bluetooth
® phone pairing...........................................................................................................51
Calling by number .............................................................................................................. .......... 52
Calling by name ............................................................................................................................. 52
Calling by speed dial.......................................................................................................... .......... 53
*: This feature may be operated by Voice command (See P.64)

3
OverviewInstrument Panel
Shift paddle switch (automatic transmission)
P.15
Headlight switch
Turn signal lever Fog light switch P.23
P.20
P.24
Inside lock button P.69
Fuel filler door opener P.71
Power window switches P.70
Window lock switch P.70
Trunk opener P.72
Satellite switches P.19
Multi-information
display
P.18
Door lock switches P.69
Audio remote control switches
P.49, 62

8
Keys
■Electronic key
Smart access system with push-button start
( P.9 , 1 4 )
*: If equipped
■ Mechanical key
● Locks and unlocks the doors
● Opens the trunk
● Locks and unlocks the glove box
The mechanical key is stored inside the electronic
key. To extract the key, release the latch and pull,
or if equipped with a card key, press the button
and pull.
■ Wireless remote control
Locks all doors
Unlocks all doors
Unlocks the trunk (press and hold)
Sounds alarm (press and hold)
(Use the alarm to attract attention to the vehi-
cle in order to help deter break-ins. To stop the
alarm, press any button on the wireless remote
control.)
Card key*
1
2
3
4

9
Smart Access System with Push-button Start
■Entering the vehicle
To unlock the vehicle, simply grasp either of the
front door handles.
■Exiting the vehicle
To lock the vehicle, press the lock button on either
of the front door handles.
■Opening the trunk
To open the trunk, press and hold the trunk
release button.
The smart access system with push-button start allows you to enter and exit the vehicle
or start the engine by simply carrying th e electronic key in your pocket or bag.
For details on starting the engine, see page 14.
For details on what to do when the electronic key does not operate properly, see page 75.

10
Theft Deterrent System
■Engine immobilizer system
The engine immobilizer system prevents the
engine from being started in the event that an
attempt is made to start the vehicle using an
unregistered key.
The security indicator ligh t flashes to indicate that
the system is set.
■ Alarm
The system sounds the alarm and flashes lights when forcible entry is detected.
To set the alarm: lock all the doors from outside the vehicle. The security indicator light
comes on to indicate that the alarm is in its preparation state. When the indicator light
begins to flash, the system is armed.
To deactivate or stop the alarm: turn the “ENGINE START STOP” switch to ACCESSORY
or IGNITION ON mode, start the engine by pressing the “ENGINE START STOP” switch,
or unlock the doors or trunk.
■ Steering lock
The steering wheel locks when the “ENGINE
START STOP” switch is OFF.
When the steering lock cannot be released, the
green indicator light on the “ENGINE START
STOP” switch will flash and a message will be
shown on the multi-information display. To release
it, gently turn the wheel left or right while pressing
the “ENGINE START STOP” switch.
The theft deterrent system includes the followi ng features to help protect your vehicle from
theft.

13
Head Restraints
■Vertical adjustment
To r a i s e : push the head restraint upward.
To lower (front and center rear seats) : push the
head restraint down while pressing the lock
release button.
To lower (outside rear seats) : push the head
restraint down.
■ Folding (outside rear seats only)
Pull the head restraint up while pressing the lock
release button.
Seat Belts
■Adjusting shoulder belt height (front seats only)
To r a i s e : pull the anchor upward.
To l o w e r : depress the button and push the anchor
down.
■ Seat belt comfort guides (outside rear seats only)
If the shoulder belt sits close to the neck, slide the
comfort guide forward.
Lock
release
button
Lock release button

30
Touch Screen (with navigation system)
By touching the screen with your finger, you can control the audio system and air condition-
ing system, and adjust the screen display etc. For details, refer to the “Navigation System
Owner's Manual”.
■ Basic operation
The button positions, shapes and screen may slightly vary depending on the type of the
touch screen.
Press the button to display the screen. The “Set up” screen shown in the above illustration is
displayed when the “SET UP” button is pressed.
“CLIMATE”: Air conditioning operation screen
“A U D I O ” : A u d i o c o n t r o l s c r e e n
“DISP”: Adjust picture quality
“INFO PHONE”: Information screen
“General”: General settings screen
“Clock”: Clock settings screen
“Voice”: Voice settings screen
“Navi.”: Navigation settings screen
“MAP VOICE”: Vehicle's current position
“DEST”: Destination screen
“SET UP”: Setup screen
“Other”: Other settings screen
“Vehicle”: Vehicle settings screen
“Audio”: Audio settings screen
“Phone”: Phone settings screen
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

69
Door Locks
■Locking the vehicle from inside
Inside lock button
Locks
Unlocks
Door lock switch
Operates all door locks.
Locks
Unlocks
■ Locking the vehicle from outside
Using the entry function or wireless remote control (  P. 8 , 9 )
■Rear door child-protector lock
Setting the switch to the LOCK position prevents
the rear doors from being opened from the inside.
Always set the child protector locks when chil-
dren are seated in the rear seat.
1
2
1
2

70
Powe r Wi n d ows
Powe r w i n d ow s w i t c h e sTo o p e n : press the switch.
To c l o s e : pull the switch up.
Fully pulling up and releasing the switches
causes the windows to close fully. Fully
pressing down and releasing the switches
causes the windows to open fully.
Window lock switch The window lock switch disables the opera-
tion of passenger window switches.
Moon Roof (If Equipped)
■Opening and closing
Open
The moon roof stops slightly before the fully
opened position.
To fully open, press the switch again.
Close
■Tilt up and down
Tilt up
Tilt down
1
2
1
2
1
2

71
Fuel Tank Cap
Press the fuel filler door opener.
Slowly remove the cap by turning it counter-
clockwise.
After the cap is removed, it can be hung on the
inside of the fuel filler door.
