phone Lexus IS250 2012 Using the Bluetooth audio system / 2012 IS250,IS350 OWNERS MANUAL QUICK GUIDE (OM53A98U)

Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manual s so you will have a better
understanding of your vehicle’ s capabilities and limitations.
1
Air Conditioning System (with navigation system)*
Using the automatic mode ....................................................................................................... .50
Adjusting the temperature ...................................................................................................... .. 50
To turn off the airflow ........................................................................................................ ........... 50
Air Conditioning System (w ithout navigation system)
Using the automatic mode ....................................................................................................... .63
Adjusting the temperature ...................................................................................................... .. 63
To turn off the airflow ........................................................................................................ ........... 63
Audio System (with navigation system)*
Basic operation ................................................................................................................ .............. 46
Radio.......................................................................................................................... ......................... 46
DVD player/CD player........................................................................................................... ....47
Operating an iPod .............................................................................................................. .......... 49
Remote control (steering wheel switches) ......................................................................... 49
Audio System (without navigation system)
Basic operation ................................................................................................................ .............. 57
Radio.......................................................................................................................... ......................... 58
CD player ......................................................................................................................................... 59
Operating an iPod .............................................................................................................. .......... 62
Remote control (steering wheel switches) ......................................................................... 62
Automatic Transmission ...................................................................................................................15
Cruise Control ............................................................................................................................... ......22
Door Locks ............................................................................................................................................ 69
ECT Switch (Automat ic Transmission).................................................................................... 20
Engine (ignition) Switch .................................................................................................................... 14
ETCS Switch (Manual Transmission) ......................................................................................... 21
Fog Lights ............................................................................................................................................... 24
Fuel Tank Cap ............................................................................................................................... ......... 71
Hands-free System For Cellular Phone (with navigation system)* Bluetooth
® phone pairing......................................................................................................... 39
Phonebook transfer ..................................................................................................................... 40
Registering a voice tag ........................................................................................................ ......... 41
Registering a speed dial ....................................................................................................... ...... 42
Calling by name ............................................................................................................................. 43
Calling by speed dial.......................................................................................................... .......... 44
Receiving a call............................................................................................................... ................ 45
Hands-free System For Cellular Phone (without navigation system)*
Bluetooth
® phone pairing...........................................................................................................51
Calling by number .............................................................................................................. .......... 52
Calling by name ............................................................................................................................. 52
Calling by speed dial.......................................................................................................... .......... 53
*: This feature may be operated by Voice command (See P.64)

2
Phonebook transfer ......................................................................................................................54
Changing the registered name............................. ...................................................................55
Registering a speed dial....................................................................................................... .......56
Head Restraints ............................................................................................................................... ..... 13
Headlights .............................................................................................................................................. 23
Instrument Panel Light Control ................................................................................................... 29
Intuitive Parking Assist ...................................................................................................................... 21
Keys ..............................................................................................................................................................8
Lexus Enform with Safety Connect ............................................................................................ 67
Manual Transmission ..........................................................................................................................17
Moon Roof ............................................................................................................................................. 70
Multi-information Display ............................................................................................................... 18
Navigation System* Register home .................................................................................................................. ...............33
Destination input  Search by address ........................................................................ 34
Destination input  Search points of interest by name ..........................................36
Destination input Search points of interest by category................................... 37
Destination input Search points of interest by telephone number .............. 38
Voice Command System ........................................................................................................... 64
Power Windows .................................................................................................................................. 70
Rear Window and Outside Rear View Mirror Defoggers ............................................. 29
Safety Connect ....................................................................................................................................65
Satellite Switches ............................................................................................................................... .. 19
Seat Belts ............................................................................................................................... .................. 13
Seats (Manual) ........................................................................................................................................11
Seats (Power) ............................................................................................................................... .......... 12
Smart Access System wi th Push-button Start......................................................................... 9
Theft Deterrent System .................................................................................................................... 10
Touch Screen (with navigation system) Basic operation................................................................................................................ ...............30
Display ........................................................................................................................ ......................... 31
Screen scroll operation ........................................................................................................ ....... 32
Setting a route ................................................................................................................ ................. 32
Trunk ......................................................................................................................................................... 72
Turn Signal Lever ............................................................................................................................... .20
Voice Command System* Basic operation................................................................................................................ ............... 64
Windshield Wipers and Washer ..................................................................................................25
*: This feature may be operated by Voice command (See P.64)

7
OverviewInstrument Panel
Cruise control switchP.22
Telephone switch P.39, 51
“DISP” switch P.18
Talk switch P.64

30
Touch Screen (with navigation system)
By touching the screen with your finger, you can control the audio system and air condition-
ing system, and adjust the screen display etc. For details, refer to the “Navigation System
Owner's Manual”.
■ Basic operation
The button positions, shapes and screen may slightly vary depending on the type of the
touch screen.
Press the button to display the screen. The “Set up” screen shown in the above illustration is
displayed when the “SET UP” button is pressed.
“CLIMATE”: Air conditioning operation screen
“A U D I O ” : A u d i o c o n t r o l s c r e e n
“DISP”: Adjust picture quality
“INFO PHONE”: Information screen
“General”: General settings screen
“Clock”: Clock settings screen
“Voice”: Voice settings screen
“Navi.”: Navigation settings screen
“MAP VOICE”: Vehicle's current position
“DEST”: Destination screen
“SET UP”: Setup screen
“Other”: Other settings screen
“Vehicle”: Vehicle settings screen
“Audio”: Audio settings screen
“Phone”: Phone settings screen
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

38
■Destination input Search points of interest by telephone number
Push the button on the side of the touch
screen. ( P. 3 0 )
To u c h .
To u c h .
Input a telephone number and touch .
To u c h .
To u c h .STEP2
STEP3
STEP4

39
Hands-free System For Cellular Phone
(with navigation system)
■Bluetooth® phone pairing
Compatible Bluetooth®-equipped phones can be connected to the vehicle, enabling
hands-free operation. Please refer to the cell ular phone manufacturer's user guide for pair-
ing procedures, or go to “www.lexus.com/bluetooth” for more phone information.
To use a Bluetooth
® phone, it is necessary to first
register it in the system.
Push the button on the side of the touch
screen. ( P. 3 0 )
To u c h .
To u c h .
Touch to display the screen for
connecting Bluetooth
®.
Enter the passcode displayed on the screen
into the phone.
Refer to the cellular phone user's manual for
cellular phone operation.
When the connection is completed, will appear
and push the button.
STEP2
STEP3
STEP5

40
■Phonebook transfer
Push the button on the side of the touch
screen. ( P. 3 0 )
To u c h .
To u c h .
To u c h .
To u c h .
Transfer the phonebook data to the system
using the cellular phone.
Refer to the cellular phone user’s manual for
cellular phone operation.STEP2
STEP3
STEP4
Phonebook transfer may not be po ssible depending on phone model.

42
■Registering a speed dial
Push the button on the side of the touch
screen. ( P. 3 0 )
To u c h .
To u c h .
To u c h .
To u c h .
Touch the data you want to register.
Touch the desired phone number.
Touch the button you want to register in.
The registration completion message is dis-
played on the screen.STEP2
STEP3
STEP6

43
■Calling by name
You can call by saying a voice tag registered in the phonebook. For setting the voice recog-
nition, refer to the “Navigation System Owner' s Manual”. Only when English is selected as
the system language can you call by saying a name registered in the phonebook without
registering any voice tags beforehand. (Names in the phonebook work as voice tags.)
Press .
Follow the voice guidance and say “Phone”.
Follow the voice guidance and say “Dial by
name”.
Follow the voice guidance and say a contact
name.
Follow the voice guidance and say the type of
phone number (home, mobile, work, other).
Follow the voice guidance and say “Dial”.
STEP1
STEP2
STEP4
: Pressing this switch turns the voice command system on. Say a command after the
beep.

45
■Receiving a call
When a call is received, this screen is dis-
played with a sound.
Push on the steering wheel to talk on
the phone.
To ignore the call, push on the steering
wheel.STEP1
STEP2
