5
When trouble arises
473
5-2. Steps to take in an emergency
If a warning message is displayed
Stop the vehicle immediately.A buzzer sounds and a warning message is shown on the multi-informa-
tion display. The following warning indicates the possibility of damage to
the vehicle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Lexus dealer.
Wa r n i n g m e s s a g eDetails
(for U.S.A.)
(for Canada) (Flashing)Indicates an abnormal engine oil pressure.The warning light may turn on if the engine oil pres-
sure is too low.
If a warning is shown on the multi-information display, stay calm and per-
form the following actions:
Master warning light
The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.
Multi-information display
If any of the warning lights turns on again after performing the follow-
ing actions, contact your Lexus dealer.

480
5-2. Steps to take in an emergency
Follow the correction procedures.After taking the specified steps to co rrect the suspected problem, check
that the warning light turns off.
Interior
buzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
Once
(Comes on for 10 seconds.)
(Flashing)
Indicates that an
attempt was made
to start the engine
without the elec-
tronic key being
present, or the
electronic key was
not functioning
normally.
Start the engine
with the elec-
tronic key
present.
*
Once3 times
(Flashing)
Indicates that a
door other than
the driver’s door
has been opened
or closed with the
“ENGINE START
STOP” switch in
any mode other
than OFF and the
electronic key
outside of the
detection area.
Confirm the loca-
tion of the elec-
tronic key.

488
5-2. Steps to take in an emergency
■When using the compact spare tire
As the compact spare tire is not equipped with the tire pressure warning valve and
transmitter, low inflation pressure of the spare tire will not be indicated. Also, if you
replace the compact spare tire after the tire pressure warning light comes on, the
light remains on.
■If you have a flat rear tire on a road covered with snow or ice
Install the compact spare tire on the front of the vehicle. Perform the following steps
and fit tire chains to the rear tires.
Replace a front tire with the compact spare tire.
Replace the flat rear tire with the tire removed from the front of the vehi-
cle.
Fit tire chains to the rear tires.
■After completing the tire change
The tire pressure warning system must be reset. ( P. 4 0 8 )
CAUTION
■Using the tire jack
Improper use of the tire jack may lead to death or serious injuries due to the vehicle
suddenly falling off the jack.
●Do not use the tire jack for any purpose other than replacing tires or installing and
removing tire chains.
●Only use the tire jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, and do no t use other tire jacks for replacing tires
on this vehicle.
●Always check that the tire jack is securely set to the jack point.
●Do not put any part of your body under the vehicle while it is supported by a jack.
●Do not start or run the engine while your vehicle is supported by the jack.
●Do not raise the vehicle while someone is in it.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a height greate r than that required to replace the tire.
STEP1
STEP2
STEP3

566
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONSMEANING
2WDTwo Wheel Drive
ABSAnti-lock Brake System
AI-SHIFTArtificial Intelligence Shift
ALRAutomatic Locking Retractor
AW DAll Wheel Drive
CRSChild Restraint System
DISPDisplay
ECTElectronic Controlled Transmission
ECUElectronic Control Unit
EDREvent Data Recorder
ELREmergency Locking Retractor
EPSElectric Power Steering
GAWRGross Axle Weight Rating
I/MEmission inspection and maintenance
LATCHLower Anchors and Tethers for Children
LEDLight Emitting Diode
MMTMethylcyclopentadienyl Manganese Tricarbonyl
M + SMud and Snow
MTBEMethyl Tertiary Butyl Ether
OBDOn Board Diagnostics
SRSSupplemental Restraint System
TINTire Identification Number
TPMSTire Pressure Warning System
TRACTraction Control
VDIMVehicle Dynamics Integrated Management

568
Alphabetical index
Alphabetical index
A/C* ........................................................... 210
ABS................................................................191
Air conditioning filter .......................... 424
Air conditioning systemAir conditioning filter ....................... 424
Automatic air conditioning system*..................................................210
Airbags Airbag operating conditions..........102
Airbag precautions for your child........................................................ 105
Airbag warning light ........................ 464
Curtain shield airbag operating conditions.............................................102
Curtain shield airbag
precautions ........................................ 105
Front passenger occupant classification system......................... 110
General airbag precautions ......... 105
Locations of airbags............................ 99
Modification and disposal of airbags .................................................. 109
Proper driving po sture ............97, 105
Side airbag operating conditions.............................................102
Side airbag precautions .................. 105
SRS airbags ............................................. 99
Alarm ............................................................ 93
Antenna* ..................................................228 Anti-lock brake system ......................... 191
Armrest .................................................... 343
Ashtrays.................................................... 336
Assist grips .............................................. 348
Audio input* ........................................... 265
Audio system*
Antenna.................................................. 228
AUX port .............................................. 265
Bluetooth
® audio ..............................270
CD player/changer ........................... 231
iPod ...........................................................246
MP3/WMA disc............................... 238
Optimal use ..........................................263
Portable music player ..................... 265
Radio ........................................................ 223
Steering wheel audio switch.........267
USB memory ...................................... 254
USB port ............................................... 254
Automatic air conditioning system* ................................................... 210
Automatic headlight leveling system ......................................................170
Automatic light control system......... 167
Automatic transmission Automatic transmission ................... 144
If the shift lever cannot be shifted from P................................... 494
S mode ..................................................... 147
AUX port* .............................................. 265
Auxiliary box .......................................... 329
A

571
Alphabetical index
Daytime running light system............ 169
Defogger*Rear window.......................................... 218
Side mirror .............................................. 218
Dimension .................................................510
Dinghy towing ....................................... 206
Display Satellite switch mode....................... 333
Trip information .................................... 163
Warning message .............................473
Do-it-yourself maintenance............. 385
Door courtesy lights Door courtesy lights .......................... 319
Wattage ................................................. 525
Door pockets ......................................... 329
Doors Door lock ............................... 33, 45, 48
Door windows ......................................... 81
Side mirrors............................................. 78
Driver's seat belt reminder light .... 465
Driving Correct posture .....................................97
Procedures .............................................130
Driving position memory ..................... 59 Electric power steering .........................191
Electronic key
If the electronic key does not operate properly ........................... 496
Emergency, in case of If a warning message is displayed............................................. 473
If the electronic key does not operate properly ........................... 496
If the engine will not start................ 492
If the shift lever cannot be shifted from P ...................................494
If the vehicle has a discharged battery ................................................. 500
If the warning buzzer sounds ......463
If the warning light turns on...........463
If you have a flat tire ........................ 483
If you lose your keys ........................ 495
If you think something is wrong .................................................... 461
If your vehicle becomes stuck .... 507
If your vehicle has to be stopped in an emergency ............................ 508
If your vehicle needs to be towed................................................... 455
If your vehicle overheats ............... 504D
*: For vehicles with a navigation system, refe r to the “Navigation System Owner’s Manual”.
E

580
Alphabetical index
USB port*.................................................... 254
Vanity lights Vanity lights ............................................331
Wattage.................................................. 525
Vanity mirrors ......................................... 331
VDIM ............................................................191
Vehicle data recordings .........................21
Vehicle dynamics integrated management ..........................................191
Vehicle identification number ............511
Vehicle stability control.........................191
Ventilators ................................................ 341
Voice command switch* ................... 292
VSC ...............................................................191 Warning buzzers
Brake system ....................................... 463
Open door .......................................... 465
Seat belt reminder ............................ 465
Warning lights Anti-lock brake system .................. 464
Brake assist system .......................... 464
Brake system ....................................... 463
Charging system ............................... 464
Electric power steering warning light..................................... 464
Low fuel level....................................... 465
Malfunction indicator lamp .......... 464
Master warning light........................ 465
Open door ........................................... 465
Pretensioners ...................................... 464
Seat belt reminder light .................. 465
SRS airbags .......................................... 464
Tire pressure warning light........................................................ 465U
V
W

583
What to do if...
A warning light or indicator
light comes onP. 4 6 3If a warning light turns on or a warning
buzzer sounds...
■Warning lights
or or
P. 4 6 3P. 4 6 4
P. 4 6 5
or
P. 4 6 4P. 4 6 5
P. 4 6 5P. 4 6 5
P. 4 6 4P. 4 6 4
P. 4 6 5P. 4 6 5
P. 4 6 4P. 4 6 4
Brake system warning lightMalfunction indicator lamp
ABS warning lightDriver’s seat belt reminder
light
Front passenger’s seat belt
reminder light
Low fuel level warning lightMaster warning light
SRS warning lightElectric power steering system
warning light
Open door warning lightTire pressure warning light
Charging system warning
lightSlip indicator
A warning message is dis-
playedP. 4 7 3If a warning message is displayed
