1
2
3
4
5
6
7
3
2-1. Driving proceduresDriving the vehicle ........................ 130
Engine (ignition) switch .............. 140
Automatic transmission.............. 144
Turn signal lever ............................ 150
Parking brake ................................... 151
Horn.................................................... 152
2-2. Instrument cluster Gauges and meters ..................... 153
Indicators and warning lights................................................. 159
Multi-information display........... 162
2-3. Operating the lights and windshield wipers
Headlight switch ............................ 167
Fog light switch ................................ 171
Windshield wipers and washer............................................. 173
Headlight cleaner switch ........... 180 2-4. Using other driving systems
Cruise control ................................. 181
Intuitive parking assist ................. 185
Driving assist systems.................... 191
2-5. Driving information Cargo and luggage ...................... 197
Vehicle load limits ....................... 200
Winter driving tips ........................ 201
Trailer towing ................................ 205
Dinghy towing ............................... 206
2When driving

TABLE OF CONTENTSIndex
6
5-1. Essential informationEmergency flashe rs..................... 454
If your vehicle needs to be towed ...................................... 455
If you think something is wrong .............................................. 461
Fuel pump shut off system ........ 462
5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer
sounds... ........................................ 463
If a warning message is displayed ....................................... 473
If you have a flat tire.................... 483
If the engine will not start .......... 492
If the shift lever cannot be shifted from P .............................. 494
If you lose your keys .................... 495
If the electronic key does not operate properly ............... 496
If the vehicle battery is discharged .................................. 500
If your vehicle overheats .......... 504
If the vehicle becomes stuck................................................ 507
If your vehicle has to be stopped in an
emergency .................................. 508 6-1. Specifications
Maintenance data (fuel, oil level, etc.)...................... 510
Fuel information ............................ 526
Tire information............................ 530
6-2. Customization Customizable features............... 542
6-3. Initialization Items to initialize ........................... 547
Reporting safety defects for U.S. owners.......................... 550
Seat belt instructions for Canadian owners
(in French) ..................................... 551
SRS airbag instructions for Canadian owners
(in French) ................................... 553
Headlight aim instructions for Canadian owners
(in French) .................................... 562
5When trouble arises6Vehicle specifications
7For owners

14
Pictorial indexInstrument panel
Headlight switch Turn signal lever Fog light switch P. 167
P. 150
P. 171
Shift paddle switches P. 145, 147
Gauges and meters P. 153
Multi-information display P. 162
Windshield wiper and washer switch P. 173
Engine (ignition) switch P. 140
Trunk opener main switch P. 53
Glove box P. 323
Tilt and telescopic steering lock release lever  P. 73
Tilt and telescopic steering control switch  P. 74
Parking brake pedal P. 151
Audio remote control switches P. 267
Horn P. 152
Hood release lever P. 388

37
1-2. Opening, closing and locking the doors and trunk
1
Before driving
■Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors have
been locked/unlocked. (Locked: Once; Unlocked: Twice)
■Conditions affecting operation
The smart access system with push-button start uses weak radio waves. In the fol-
lowing situations, the communication between the electronic key and the vehicle
may be affected, preventing the smart access system with push-button start from
operating properly:
(Ways of coping: P. 4 9 6 )
●When the electronic key battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large display,
airport or other facility that generates strong radio waves or electrical noise
●When carrying a portable radio, cellular phone, cordless phone or other wire-
less communication devices
●When the electronic key is in contact wi th, or is covered by the following metal-
lic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When multiple electronic keys are in the vicinity
●When another wireless key (that emits radio waves) is being used nearby
●When carrying or using the electronic key together with the following devices
that emit radio waves
• Another vehicle's electronic key or a wireless key that emits radio waves
• Personal computer or personal digital assistant (PDA)
• Digital audio player
• Portable game system
●If window tint with a metallic content or metallic objects are attached to the rear
window

38
1-2. Opening, closing and locking the doors and trunk
■Switching the door unlock function
It is possible to set which doors the entry function unlocks. Turn the “ENGINE START STOP” switch OFF.
When the indicator on the key surface is turned off, push and
hold , or for approximately 5 seconds while pushingon the key.
The setting changes each time an operatio n is performed, as shown below. (When
changing the setting continuously, release the buttons, wait for at least 5 seconds,
and repeat step 2.)
To prevent unintended triggering of the alarm, unlock the doors using the electronic
key and open and close a door once after the settings have been changed. (If a
door is not opened within 60 seconds af ter is pressed, the doors will be locked
again and the alarm will automatically be set.)
In case that the alarm is triggere d, immediately stop the alarm. (P. 9 3 )
STEP1
STEP2
Multi-information
displayUnlocking doorsBeep
Hold the driver's door handle
to unlock only the driver's
door.
Exterior: Beeps three
times
Interior: Pings once
Hold the front passenger’s
door handle to unlock all
doors.
Hold either front door handle
to unlock all doors.Exterior: Beeps twice
Interior: Pings once

41
1-2. Opening, closing and locking the doors and trunk
1
Before driving
■When the vehicle is not driven for extended periods
To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of
the vehicle.
■Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the anti-theft system automatically locks the vehicle again.
■Alarms and warning indicators
A combination of exterior and interior alarms as well as warnings displayed on the
multi-information display is used to prevent theft of the vehicle and unforeseeable
accidents resulting from erroneous operation. Take appropriate measures in
response to any warning indications on the multi-information display. ( P. 4 7 3 )
The following table describes circumstances and correction procedures when only
alarms are sounded.
AlarmSituationCorrection procedure
Exterior alarm
sounds once for 2
seconds
Tried to lock the doors using
the entry function while the
electronic key is still inside
the passenger compartmentRetrieve the electronic
key from the passenger
compartment and lock
the doors again.
Closed the trunk while the
electronic key is still inside
and all doors are lockedRetrieve the electronic
key from the trunk and
close the trunk lid.
Exterior alarm
sounds once for 60
seconds
Tried to exit the vehicle with
the electronic key and lock
the doors without first turning
the “ENGINE START STOP”
switch OFFTu r n t h e “ E N G I N E
START STOP” switch
OFF and lock the doors
again.
Exterior alarm
sounds once for 10
secondsTried to lock the vehicle using
the entry function while a
door is openClose all of the doors
and lock the doors
again.
Interior alarm
sounds continu-
ouslyTried to open the door and
exit the vehicle without shift-
ing the shift lever to P
Shift the shift lever to P.

85
1-4. Opening and closing the windows and moon roof
1
Before driving
■The moon roof can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the
instrument panel when the “ENGINE STAR T STOP” switch is turned OFF and the
driver's door is opened with the moon roof open.
■Door lock linked moon roof operation
The moon roof can be opened and closed using the mechanical key. ( P. 4 9 6 )
■Operating the moon roof after turning the “ENGINE START STOP” switch OFF
The moon roof can be operated for ap proximately 45 seconds even after the
“ENGINE START STOP” switch is switched to ACCESSORY mode or turned
OFF. It cannot, however, be operated once either front door is opened.
■Jam protection function
If an object is detected between the moon roof and the frame while closing or tilting
down, travel is stopped and the moon roof opens slightly.
■To reduce moon roof wind noise
When the moon roof is opened automatically, it will stop slightly before the fully
open position. Driving with the moon roof in this position can help reduce wind
noise.
■Sunshade
The sunshade can be opened and closed manually. However, the sunshade will
open automatically when the moon roof is opened.

119
1
1-7. Safety information
Before driving
Installing child restraints
Follow the child restraint system manufacturer's instructions. Firmly
secure child restraints to the rear seats using the LATCH anchors or a seat
belt. Attach the top tether strap when installing a child restraint.
The lap/shoulder belt can be used if your child restraint system is not com-
patible with the LATCH (Lower Anchor s and Tethers for Children) system.
Child restraint LATCH anchors
LATCH anchors are provided
for the outside rear seats. (But-
tons displaying the location of
the anchors are attached to the
seats.)
Seat belts equipped with a child
restraint locking mechanism
(ALR/ELR belts except driver’s
seat belt) (P. 66)
Anchor bracket (for top tether
strap)
Anchor brackets are provided
for all rear seats.

When driving2
129
2-1. Driving proceduresDriving the vehicle.................. 130
Engine (ignition) switch ......... 140
Automatic transmission ........ 144
Turn signal lever ....................... 150
Parking brake ............................ 151
Horn ............................................ 152
2-2. Instrument cluster Gauges and meters ................ 153
Indicators and warning lights ......................................... 159
Multi-information display ..... 162
2-3. Operating the lights and windshield wipers
Headlight switch...................... 167
Fog light switch ......................... 171
Windshield wipers and washer ..................................... 173
Headlight cleaner switch..... 180 2-4. Using other driving
systems
Cruise control........................... 181
Intuitive parking assist ........... 185
Driving assist systems ............. 191
2-5. Driving information Cargo and luggage ................. 197
Vehicle load limits .................. 200
Winter driving tips .................. 201
Trailer towing .......................... 205
Dinghy towing ......................... 206

142
2-1. Driving procedures
■If the engine does not start
The engine immobilizer system may not have been deactivated. (P. 9 1 )
■When the steering lock cannot be released
■When the “ENGINE START STOP” switch indicator flashes in amber
The system may be malfunctioning. Have the vehicle inspected by your Lexus
dealer immediately.
■Auto power off function
If the vehicle is left in ACCESSORY mode for more than 20 minutes with the shift
lever in P, the “ENGINE START STOP” switch will automatically turn OFF.
■Electronic key battery depletion
 P. 3 9
■When the electronic key battery is fully discharged
P. 4 2 6
■Conditions affecting operation
P. 3 7
■Note for the entry function
P. 4 0
The “ENGINE START STOP” switch indica-
tor will flash in green and a message will be
shown on the multi-information display. Press
the “ENGINE START STOP” switch again
while turning the steering wheel left and right.
