4688-2. Steps to take in an emergency
IS350/250_U (OM53758U)
Indicates a malfunction in the tire pressure warning sys-
tem
 Stop the vehicle in a safe place and turn the engine
switch off then on again.
If the tire pressure warning indicator flashes for 1
minute then illuminates, there is a malfunction in the
system. Have the vehicle inspected at your Lexus
dealer.
Indicates that the tire position information cannot be rec-
ognized
Drive for a short while an d check if the display
updates.
If the radio wave conditions improve, the display
may return to normal. If th e tire pressure is still not
displayed after driving for several minutes, stop the
vehicle in a safe place, turn the engine switch off
then on again, and start driving.
If the tire pressure is still not displayed even after
repeating this process several times, have the vehi-
cle inspected at your Lexus dealer.
Indicates that the wash er fluid level is low
 Add washer fluid.
Indicates that remaining fuel is approximately 2.6 gal.
(10 L, 2.2 Imp. gal.) or less
 Refuel the vehicle.
Indicates that the TRAC (Tra ction Control) system has
been deactivated
 Tu r n t h e T R A C o n . ( P. 2 3 6 )
(U.S.A. only)
Indicates that all maintenance according to the driven
distance on the maintenance schedule
* should be per-
formed soon.
Comes on approximately 4500 miles (7200 km) after
the maintenance data has been reset.
 If necessary, perform maintenance.
Wa r n i n g m e s s a g eDetails/Actions

4748-2. Steps to take in an emergency
IS350/250_U (OM53758U)
*: The engine may not be restarted depending on the vehicle condition.
■Wa r n i n g m e s s a g e s
P. 4 7 0
■Warning buzzer
P. 4 5 8

Power was turned off due to the
automatic power off function.
 Next time when starting the
engine, increase the engine
speed slightly and maintain that
level for approximately 5 min-
utes to recharge the battery.
Con-
tinuous
Indicates that the engine was
stopped in an emer gency while driv-
ing
 To restart the engine, shift the
shift lever to N and turn the
engine switch to IGNITION
ON mode.
*
Once
Indicates that the engine switch has
been pressed while driving
Except when emergency stop-
ping of the vehicle is needed,
immediately release the engine
switch.
Interior
buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Flashes)

4898-2. Steps to take in an emergency
8
When trouble arises
IS350/250_U (OM53758U)
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the engine switch.
When the electronic key is detected, a
buzzer sounds and the engine switch
will turn to IGNITION ON mode.
When the smart access system with
push-button start is deactivated in cus-
tomization setting, the engine switch will
turn to ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on the multi-
information display.
Press the engine switch.
In the event that the engine still cannot be started, contact your Lexus dealer.
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when stopping
the engine.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the electronic
key battery be replaced immediatel y when the battery is depleted. (P. 4 2 7 )
■Changing engine switch modes
Release the brake pedal and press the engine switch in step above.
The engine does not start and modes will be changed each time the switch is pressed.
( P. 1 6 0 )
■When the electronic key does not work properly
●Make sure that the smart access system wi th push-button start has not been deacti-
vated in the custom ization setting. If it is off, turn the function on.
(Customizable features P. 5 2 5 )
●Check if battery-saving mo de is set. If it is set, cancel the function. ( P. 115)
Starting the engine
1
2
3
4
3

4958-2. Steps to take in an emergency
8
When trouble arises
IS350/250_U (OM53758U)
The coolant level is satisfactory if it is
between the “FULL” and “LOW”
lines on the reservoir.Reservoir
“FULL”
“LOW”
Add coolant if necessary.
Water can be used in an emergency if
coolant is unavailable.
Start the engine and turn the air conditioning system on to check that the radi-
ator cooling fan operates and to check for coolant leaks from the radiator or
hoses.
The fan operates when the air conditioning system is turned on immediately after a
cold start. Confirm that the fan is operating by checking the fan sound and air flow. If it
is difficult to check these, turn the air conditioning system on and off repeatedly.
(The fan may not operate in freezing temperatures.)
If the fan is not operating:
Stop the engine immediately and contact your Lexus dealer.
If the fan is operating:
Have the vehicle inspected at the nearest Lexus dealer.
4
1
2
3
5
6
7

4978-2. Steps to take in an emergency
8
When trouble arises
IS350/250_U (OM53758U)
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the rear wheels.
Place wood, stones or some other material under the rear wheels to help pro-
vide traction.
Restart the engine.
Shift the shift lever to D or R and release the parking brake. Then, while exer-
cising caution, depress the accelerator pedal.
■When it is difficult to free the vehicle
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle becomes
stuck in mud, dirt or snow:
Press to turn off TRAC.
1
2
3
4
5

5339-2. Customization
9
Vehicle specifications
IS350/250_U (OM53758U)
■Vehicle customization
●When the smart access system with push-button start is off, the entry unlock function
cannot be customized.
●When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the
operation buzzer volume and operational si gnal (Emergency flashers) function set-
tings.
■When customizing using the Remote Touch or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent battery discharge, leave the engi ne running while customizing the features.
CAUTION
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

549What to do if... (Troubleshooting)
IS350/250_U (OM53758U)
●Did you press the engine switch while firmly depressing the brake pedal?
(P. 1 5 9 )
●Is the shift lever in P? ( P. 161)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 1 1 4 )
●Is the steering wheel unlocked? ( P. 161)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. (P. 4 8 9 )
●Is the battery discharged? ( P. 4 9 0 )
●Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( P. 4 8 7 )
●It is locked automatically to prevent theft of the vehicle. ( P. 1 6 1 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be operated
if the window lock switch is pressed. ( P. 1 3 7 )
●The auto power off function will be oper ated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( P. 161)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress the brake
pedal
The steering wheel cannot be turned after the engine is stopped
The windows do not open or close by operating the power window
switches
The engine switch is turned off automatically

550What to do if... (Troubleshooting)
IS350/250_U (OM53758U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 4 5 6 )
●The parking brake indicator is on
Is the parking brake released? ( P. 1 7 2 )
Depending on the situation, other type s of warning buzzer may also sound.
( P. 4 5 5 , 4 6 1 )

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 7 1 )
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. ( P. 4 6 1 )
●When a warning light turns on or a warning message is displayed, refer to
P. 4 5 5 , 4 6 1 . A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

557Alphabetical index
IS350/250_U (OM53758U)
E-mail...........................................................319
Eco drive mode .......................................231
Eco Driving Indicator............................. 90
Eco Driving Indicator Light ................. 88
EDR (Event data recorder) ...................10
Elapsed time .............................................. 87
Electric Power Steering (EPS) ....... 235Function ..................................................235
Warning light ...................................... 455
Electronic key ........................................... 98 Battery-saving function ...................... 115
If the electronic key does not operate properly............................ 488
Replacing the battery ....................... 427 Emergency, in case of
If the electronic key does not operate properly ....... 488
If the engine will not start ...............485
If the shift lever cannot be shifted from P ............ 487
If the vehicle battery is discharged.........................................490
If the warning buzzer sounds .................................................455
If the warning light turns on ..........455
If the warning message is displayed ..........................................461
If you have a flat tire .......................... 475
If you think something is wrong .............................................. 453
If your vehicle becomes stuck...................................................... 497
If your vehicle has to be stopped in an emergency.......... 447
If your vehicle needs to be towed ....................................... 448
If your vehicle overheats ................ 494
E

566Alphabetical index
IS350/250_U (OM53758U)
Shift lever ...................................................164Automatic transmission ................... 164
If the shift lever cannot be shifted from P ............487
Shift lock system.................................... 487
Shift position and gear position ...........81
Side airbags ............................................... 37
Side marker lights................................... 173 Light switch .............................................173
Replacing light bulbs ........................ 442
Side mirrors ..............................................134 Adjusting and folding........................ 134
Blind Spot Monitor............................246
Linked mirror function when reversing ................................. 135
Mirror position memory ...................123
Side turn signal lights ............................170 Replacing light bulbs ........................ 442
Turn signal lever .................................. 170
Slip indicator........................................... 456
Smart access system with push-button start ........................ 114 Antenna location ................................... 114
Entry functions ........................... 103, 109
Starting the engine ............................. 159 SMS (Short message service) .......... 319
Snow mode............................................... 165
Snow tires ................................................ 256
Spare tire ..................................................475
Inflation pressure................................ 507
Storage location ................................. 476
Spark plug ............................................... 504
Specifications......................................... 500
Speedometer .............................................. 81
Speed indicator........................................ 88
Steering lock ............................................. 161 Column lock release .......................... 161
Steering wheel ........................................130 Adjustment............................................. 130
Audio switches ................................... 265
Heated steering wheel ................... 354
Power easy access system ............. 124
Steering wheel position memory .............................. 123
Stop lights Replacing light bulbs ....................... 442
Storage feature ..................................... 358
Stuck If the vehicle becomes stuck........ 497
Sun visors................................................. 365
