Page 1 of 82
Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manual s so you will have a better
understanding of your vehicle’ s capabilities and limitations.
1
Air Conditioning System*
Adjusting the temperature ...................................................................................................... .. 58
Air conditioning control screen .............................................................................................. 59
Using automatic mode........................................................................................................... ..... 60
Adjusting the temperature for driver and passenger seats separately (“DUAL” mode) .................................................................................................................. ....... 60
Audio System (with Lexus Display Audio) *
Display Audio operation buttons............................................................................................ 54
Using the steering whee l switches to change audio sources ..................................... 54
Audio menu screen .............................................................................................................. ........ 55
Operating the audio system using the steering wheel switches ............................... 57
Audio System (with navigation system)*
Audio control screen ................................................................................................................... 44
Remote control (steering wheel switches) ......................................................................... 44
Basic operation ................................................................................................................ .............. 45
Radio.......................................................................................................................... ......................... 46
DVD player/CD player........................................................................................................... ... 46
Operating an iPod .............................................................................................................. .......... 48
Automatic High Beam .......................................................................................................................15
BSM (Blind Spot Monitor) .............................................................................................................. 28
Cruise Control ............................................................................................................................... ....... 21
Dynamic Radar Cruise Control .................................................................................................. 23
Floor Mat Installation ...........................................................................................................................4
Garage Door Opener ..................................................................................................................... 68
*: This feature may be operated by Voice command (See P.62)
Page 2 of 82
2
Hands-free System For Cellular Phone (with Lexus Display Audio)*
How to register a Bluetooth® phone..................................................................................... 51
Registering favorites.......................................................................................................... ............ 51
Dialing........................................................................................................................ .......................... 51
Dialing from the phonebook ..................................................................................................... .51
When the phonebook is empty................................................................................................52
Dialing from favorites ......................................................................................................... ..........52
To answer the phone ............................................................................................................ ........53
To refuse a call ............................................................................................................... .................53
Operating a telephone using the steering whee l switches ..........................................53
Hands-free System For Cellular Phone (with navigation system)*
Bluetooth
® phone pairing .........................................................................................................39
Contacts transfer .............................................................................................................. .............40
Registering the contacts in the favorites list ........................................................................ 41
Calling by name................................................................................................................ .............. 42
Calling by favorites list...................................................................................................... ........... 42
Calling using e-mail/SMS/MMS message ........................................................................ 43
Receiving a call ............................................................................................................... ................ 43
Steering switches ........................................................................................................................... 43
Headlights ............................................................................................................................... ................ 14
Intuitive Parking Assist ..................................................................................................................... 27
LDA (Lane Departure Alert) ........................................................................................................ 26
Lexus Display Audio Controller .................................................................................................. 49
Lexus Enform ............................................................................................................................... ........ 72
Lexus Enform Safety Connect ..................................................................................................... 70
Multi-information Display ............................................................................................................... 12
*: This feature may be operated by Voice command (See P.62)
Page 3 of 82
3
Navigation System*Register home .................................................................................................................. .............. 33
Destination input Search by address ........................................................................ 34
Destination input Search points of interest by name ......................................... 36
Destination input Search points of interest by ca tegory ...................................37
Destination input Search points of interest by telephone number .............. 38
Voice Command System........................................................................................................... 62
Portable Audio Device Ports ....................................................................................................... 68
Remote Touch ............................................................................................................................... ....... 30
Seat Heaters/Seat Ventilators ..................................................................................................... 61
Tire Pressure Warning System .................................................................................................... 29
Turn Signal Lever ................................................................................................................................... 11
Voice Command System *
Basic operation ................................................................................................................ .............. 62
Command list................................................................................................................... ............... 63
Windshield Wipers and Washer ................................................................................................... 17
XM Satellite Radio .............................................................................................................................74
*: This feature may be operated by Voice command (See P.62)
Page 6 of 82
6
Remote Touch screen
Navigation system
Lexus Display Audio system
P.30
P.33
P.49
Emergency flasher switch*
See P.9
Engine switch
*
: If equipped
*: Refer to “OWNER’S MANUAL”.
Trunk opener*
Clock*
Trunk opener main switch*
Audio system P.44, 54
Shift lever*
Hood lock release lever*
Air conditioning system
P.58
Page 8 of 82
8
Meter control switches P.13
Vehicle-to-vehicle distance button P.24
Audio remote control switches
P.44, 57
Cruise control switch
P.21, 23
Horn*1
: If equipped
*1: Refer to “OWNER’S MANUAL”.
*2: For vehicles with a navigation sy stem, refer to “NAVIGATION SYSTEM
OWNER'S MANUAL”.
Tilt and telescopic
steering control switch
*1
Telephone switches
P.43, 53
LDA (Lane Departure Alert)
switch
P.26
Paddle shif t switches*1
Talk switch
P.43, 53
Page 12 of 82
12
Multi-information Display
Drive information
Select to display various drive data.
Navigation system-linked display (if equipped)
Select to display the following navigation system-linked information.
• Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the
meter control switches.
Dynamic radar cruise control operational status
(vehicles with a dynamic radar cruise control)
Select to display the operational status of the dynamic radar cruise control.
( P. 2 3 )
The tab will change to when the vehicle is in constant speed con-
trol mode. ( P. 2 5 )
If LDA (Lane Departure Alert) is activated, the operational status of the LDA sys-
tem will also be displayed. (If equipped)
LDA (Lane Departure Alert) operational status
(vehicles with LDA but without a dynamic radar cruise control)
Select to display the oper ational status of the LDA.
Warning message display
Select to display warning me ssages and measures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display settings.
The multi-information display presents the driver with a variety of vehicle data.
Page 30 of 82
30
Remote Touch (with navigation system)
■Basic operation
“MENU” button
Press to display the “Menu” screen.
“ • ” button
Press to change the scale of the map and to scroll the list screen.
“HOME” button
Press to display the home screen.
Remote Touch knob
Move in the desired direction to select a function, letter and screen button.
Press to enter the selected function, letter or screen button.
■ Menu
Press the “MENU” button on the Remote
Touch to display the “Menu” screen.
“Climate” ( P. 5 8 )
“Nav” ( P. 3 3 )
“LEXUS App Suite”
“Info”
“Radio” ( P. 4 6 )
“Media” ( P. 44)
“Phone” ( P. 3 9 )
“Setup”
“Display”
The Remote Touch can be used to operate the Remote Touch screens.
1
2
3
4
1
2
3
4
5
6
7
8
9
Page 31 of 82
31
■Home
Three-way split screen
Press the “HOME” button on the Remote
Touch to display the home screen.
The home screen can display multiple infor-
mation screens, such as the navigation sys-
tem screen, audio system screen and fuel
consumption screen, simultaneously. When
a screen is selected, the selected screen is
switched to a full-screen display.
Displays the condition of the
Bluetooth
® connection
Select to change the display items/area
and the home screen layout.
Two-way split screen
■
Screen scroll operation
To scroll over the map screen, place the
cursor mark in the desired position and then
press and hold the Remote Touch knob.
Cursor mark
Distance from the current position to
the cursor mark.
Zooms in on the map
Zooms out on the map
Select to return to the current position.
Select to register as a memory point.
Select to set as a destination.
1
2
1
2
3
4
5
6
7
Page 32 of 82
32
■Setting a route
While route guidance is operating, you can change the route using the following method.
Select “Options”.
Select “Edit Route”.
Select the item to be set.Set route preferences
Set detours
Change route type
Start from adjacent road
1
2
3
1
2
3
4
Some functions are unavailable while the vehicle is in motion. Refer to the “NAVIGATION
SYSTEM OWNER’S MANUAL”.
Page 33 of 82
33
Navigation System (if equipped)
■Register home
Press the “MENU” button on the
Remote Touch.
Please refer to page 30 for the
Remote Touch operation.
Select “Setup”.
Select “Navigation”.
Select “Home”.
Select “Set Home Location”.
Select “Address”.
Select “City”.
Enter a city name and select “OK”.
Select the screen button of the desired
city name from the displayed list.
For security reasons, use a point close
to your home instead of your actual
home address.
Enter a street name and select “OK”.
When the desired street name is found,
select the corresponding screen button.
Enter a house number and select “OK”.
Select “OK”.
31
2
3
44
55
6
77
8
9
10
11
12
13
