turn signal bulb LEXUS IS250 2016 Owners Manual

139
2-1. Driving procedures
2

When driving
Turn signal lever
nTurn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
nIf the indicators flash faster than usual
Check that a light bulb in the turn signal lights has not burned out.
Right turn
Left turn
Move and hold the lever part-
way to signal a lane change
The right hand signal will flash
until you release the lever.
Move and hold the lever part-
way to signal a lane change
The left hand signal will flash
until you release the lever.

363
4-3. Do-it-yourself maintenance
4

Maintenance and care
Light bulbs
You may replace the following bulbs yourself. For more information about
replacing other light bulbs, contact your Lexus dealer.
nPreparing a replacement light bulb
Check the wattage of the light bulb being replaced. (→P. 445)
nRemoving the engine compartment cover
→P. 31 2
nFront bulb locations
nRear bulb locations
Parking light
Headlight
high beam
Rear turn signal lightBack-up light

366
4-3. Do-it-yourself maintenance
Partly remove the trunk panel
cover and turn bulb bases coun-
terclockwise.
Remove the light bulb.
nRear turn signal lights
Open the trunk door and remove
the cover.
Turn the bulb base counterclock-
wise.
STEP2
STEP3
STEP1
STEP2

367
4-3. Do-it-yourself maintenance
4

Maintenance and care
Remove the light bulb.
nBulbs other than the above
If any of the bulbs listed below has burnt out, have your Lexus dealer
replace it.
lHeadlight low beams (halogen bulbs)
lHeadlight high and low beams (discharge bulbs)
lFront fog lights
lFront turn signal lights
lFront side marker lights
lSide turn signal lights
lStop/tail lights
lTail lights
lRear side marker lights
lHigh mounted stoplight
lLicense plate lights
STEP3

368
4-3. Do-it-yourself maintenance
nWhen replacing the front left headlight and parking light bulbs
nCondensation build-up on the inside of the lens
Contact your Lexus dealer for more information in the following situations. Tempo-
rary condensation build-up on the inside of the headlight lens does not indicate a
malfunction.
lLarge drops of water are built up on the inside of the lens.
lWater has built up inside the headlight.
nDischarge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or may
go out temporarily. The discharge bulbs will come on when normal power is
restored.
nLED front side marker lights, side turn signal lights, tail lights, stop/tail lights, high
mounted stoplight, rear side marker lights and license plate lights
The front side marker lights, side turn signal lights, tail lights, stop/tail lights, high
mounted stoplight, rear side marker lights and license plate lights consist of a num-
ber of LEDs. If any of the LEDs burn out, take your vehicle to your Lexus dealer to
have the light replaced.
Remove the securing bolt and move the
washer fluid filler opening to allow easy
access to the light bulbs.
After replacing the bulbs, make sure to
secure the washer fluid filler opening with the
bolt.

445
6-1. Specifications
6

Vehicle specifications
Light bulbs
A: D4S discharge bulbs
B: H11 halogen bulbs
C: Wedge base bulbs (amber)
D: HB3 halogen bulbs
E: Wedge base bulbs (clear)
F: HB4 halogen bulbs
G: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior
Headlights
High beam
Low/high beam (discharge bulbs)
Low beam (halogen bulbs)
9005
D4S
H11
60
35
55
D
A
B
Front turn signal lights⎯21C
Parking lights1685E
Front fog lights900651F
Trunk light⎯5G
Rear turn signal lights74 4 021E
Back-up lights92116E
Outer foot lights⎯5E
Interior
Vanity lights⎯8E
Interior lights
Front
Rear
⎯10
3
E
G
Overhead courtesy lights
Front
Rear
⎯3.8
3
E
G
Front door courtesy light⎯3.8E

481
Alphabetical index
Light bulbs
Replacing............................................... 363
Wattage ................................................. 445
Lights
Door courtesy lights .........................247
Emergency flasher switch ..............372
Fog light switch.....................................159
Hazard light switch............................372
Headlights switch ................................156
Interior light switch............................ 249
Outer foot lights..................................247
Overhead courtesy light ................247
Personal light switch ........................ 249
Replacing light bulbs ....................... 363
Scuff lighting..........................................247
Shift lever lighting ...............................247
Turn signal lever................................... 139
Vanity lights .......................................... 258
Wattage ................................................. 445
Load capacity .......................................... 199
Maintenance
Do-it-yourself maintenance ......... 304
General maintenance .....................300
Maintenance data ............................. 430
Maintenance requirements .......... 298
Manual transmission ............................. 137
Meter
Instrument panel light control ....... 143
Meters ....................................................... 142
Micro dust and pollen filter ................ 214
Mirrors
Inside rear view mirror .......................65
Side mirror heater .............................. 218
Side mirrors .............................................66
Vanity mirrors ..................................... 258
Moon roof ..................................................... 71
MP3 disc .................................................. 235
Multi-information display .....................151
Odometer................................................. 142
Oil
Engine oil................................................. 313
Opener
Fuel filler door ......................................... 74
Hood ........................................................307
Trunk ........................................................... 43
Outer foot lights
Outer foot lights ................................. 247
Wattage ..................................................445
Outside rear view mirrors
Adjusting and folding..........................66
Mirror position memory ....................48
Outside temperature display ........... 152
Overhead console ............................... 253
Overhead courtesy lights
Overhead courtesy lights.............. 247
Wattage ..................................................445
Overheating, Engine........................... 424
L
M
O

482
Alphabetical index
Parking assist sensors ..........................180
Parking brake .......................................... 140
Parking lights
Replacing light bulbs........................ 363
Switch ....................................................... 156
Wattage.................................................. 445
PCS ............................................................. 192
Personal lights
Switch ...................................................... 249
Power outlet............................................265
Power windows ........................................ 69
Pre-collision system.............................. 192
Radar cruise control ............................. 170
Radiator ..................................................... 319
Radio .......................................................... 222
RDS ............................................................ 223
Rear sunshade ....................................... 273
Rear turn signal lights
Replacing light bulbs........................ 363
Wattage.................................................. 445
Rear view mirror
Compass ............................................... 287
Rear window defogger........................ 218
Replacing
Electronic key battery...................... 345
Fuses ........................................................ 347
Light bulbs............................................. 363
Reporting safety defects for
U.S. owners .......................................... 470
Scuff lighting ............................................247
Seat belts
Adjusting the seat belt ........................ 57
Automatic locking retractor ........... 58
Child restraint system
installation ............................................ 104
Cleaning and maintaining
the seat belts .................................... 296
Emergency locking retractor......... 58
How to wear your seat belt ............ 56
How your child should wear
the seat belt.......................................... 59
Pregnant women,
proper seat belt use ........................ 58
Reminder light..................................... 385
Seat belt extenders.............................. 59
Seat belt pretensioners ...................... 57
Seat heaters ................................. 266, 269
Seat position memory............................ 52
Seat ventilators ...................................... 269
Seating capacity......................................199
Seats
Adjustment ...............................................46
Adjustment precautions .................... 47
Child seats/child restraint
system installation............................ 104
Cleaning ................................................ 295
Driver’s seat position memory ...... 48
Front passenger seat position
memory ..................................................52
Head restraint .........................................54
Properly sitting in the seat.................82
Seat heaters ............................. 266, 269
Ventilated seats.................................. 269
Service reminder indicators ............ 148
P
R
S

484
Alphabetical index
Tachometer
Tacho indicator..................................... 142
Tachometer ............................................ 142
Tail lights
Switch ....................................................... 156
Talk switch*
Telephone switch*
Theft deterrent system
Alarm .......................................................... 79
Engine immobilizer system .............. 77
Theft prevention labels ........................... 81
Tire inflation pressure .........................336
Tire information
Glossary................................................. 454
Size .............................................................451
Tire identification number ...............451
Uniform tire quality grading ......... 452
Tires
Chains .....................................................200
Checking ............................................... 325
If you have a flat tire ..........................404
Inflation pressure................................ 336
Inflation pressure sensor................ 327
Information............................................ 449
Replacing ...............................................404
Rotating tires ........................................ 325
Size ........................................................... 439
Snow tires ..............................................200
Tools ...........................................................404
Total load capacity ................................ 199
Towing
Dinghy towing ........................205, 206
Emergency towing ............................373
Trailer towing ...................................... 204
TRAC ......................................................... 186
Traction control...................................... 186
Transmission shift switches.................134
Trip meter ..................................................142
Trunk
Extending a space .............................275
Opener ...................................................... 43
Trunk light
Trunk light ................................................. 44
Wattage ................................................. 445
Turn signal lights
Replacing light bulbs ....................... 363
Switch ........................................................ 139
Wattage ................................................. 445
Vanity lights
Vanity lights.......................................... 258
Wattage ................................................. 445
Vanity mirrors ........................................ 258
VDIM.......................................................... 186
Vehicle dynamics integrated
management ........................................ 186
Vehicle identification number...........431
Vehicle stability control ...................... 186
Ventilators ............................................... 269
VSC ............................................................ 186
T
V
