4-3. Do-it-yourself maintenance
Light bulbs
You may replace the following bulbs yourself. For more information about
replacing other light bulbs, contact your Lexus dealer.
■Preparing a replacement light bulb
Check the wattage of the light bulb being replaced. ( P. 547)
■ Removing the engine compartment cover
 P. 4 0 0
■ Front bulb locations
■ Rear bulb locations
Parking light
Headlight high
beam
Rear turn signal light Back-up light

474
5-2. Steps to take in an emergency
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such as natural air
leaks or tire inflation pressure changes caused by temperature. In this case, adjust-
ing the tire inflation pressure will turn off the warning light (after a few minutes).
■When a tires is replaced with a spare tire (vehicles with a spare tire)
The compact spare tire is not equipped wi th the tire pressure warning valve and
transmitter. If a tire goes flat, the tire pressure warning light will not turn off even
though the flat tire is replaced with the spare tire. Replace the spare tire with the
repaired tire and adjust the proper tire inflation pressure. The tire pressure warning
light will turn off after a few minutes.
■If the tire pressure warning system is inoperative
The tire pressure warning system will be disabled in the following conditions:
(When the condition becomes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmitters are used
●If the ID code on the tire pressure warning valves and transmitters is not regis-
tered in the tire pressure warning computer
●If a different set of tires has been selected using the satellite switch.
●If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm2 or bar) or higher
The tire pressure warning system may be disabled in the following conditions:
(When the condition becomes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies are nearby
●If a radio set at similar frequencies is in use in the vehicle
●If there is a lot of snow or ice on the vehicle, in particular around the wheels or
wheel housings
●If non-genuine Lexus wheels are used (Even if you use Lexus wheels, the tire
pressure warning system may not work properly with some types of tires.)
●If tire chains are used
■If the tire pressure warning light comes on after blinking for 1 minute frequently
If the tire pressure warning light comes on after blinking for 1 minute frequently
when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have
it checked by your Lexus dealer.

488
5-2. Steps to take in an emergency
Follow the correction procedures.After taking the specified steps to co rrect the suspected problem, check
that the warning light turns off.
Interior
buzzerExterior buzzerMessageDetailsCorrection
procedure
Once
(Comes on for 10 seconds.)
(Flashing)
Indicates that an
attempt was made
to start the engine
without the elec-
tronic key being
present, or the
electronic key was
not functioning
normally.
Start the engine
with the elec-
tronic key
present.
*
Once3 times
(Flashing)
Indicates that a
door other than
the driver’s door
has been opened
or closed with the
“ENGINE START
STOP” switch in
any mode other
than OFF and the
electronic key
outside of the
detection area.
Confirm the loca-
tion of the elec-
tronic key.

5
When trouble arises
513
5-2. Steps to take in an emergency
■Avoiding a discharged battery
●Turn off the headlights and the audio system while the engine is off.
●Turn off any unnecessary electrical components when the vehicle is running at a
low speed for an extended period, such as in heavy traffic, etc.
CAUTION
■Avoiding battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flammable
gas that may be emitted from the battery.
●Make sure the jumper cable is connected to the correct terminal and that it is not
unintentionally in contact with any pa rt other than the intended terminal.
●Do not allow the jumper cables to come into contact with the “+” and “-” termi-
nals.
●Do not allow open flame or use matches, cigarette lighters or smoke near the
battery.
Maintain the engine speed of th e second vehicle and turn the
“ENGINE START STOP” switch to IGNITION ON mode,
then start the vehicle’s engine.
Once the vehicle’s engine ha s started, remove the jumper
cables in the exact reverse ord er in which they were con-
nected.
Once the engine starts, have the ve hicle checked at your Lexus dealer
as soon as possible.STEP5
STEP6

538
6-1. Specifications
Ignition system
Electrical system
Spark plug
Make
GapDENSO FK20HBR11
0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Battery
Open voltage* at
68 F (20 C):12.6 12.8 V Fully charged
12.2 
12.4 V Half charged
11.8 
12.0 V Discharged
(*: Voltage checked 20 minutes after
the engine and all the lights are turned
off)
Charging rates5 A max.

581
Alphabetical index
Back-up lightsWattage ................................................. 547
Battery Checking ...............................................408
If the vehicle has a discharged battery.................................................... 512
Preparing and checking before winter .................................... 220
Bluetooth
® audio ................................ 289
Bluetooth® phone ............................... 307
Brake Fluid .......................................................... 406
Parking brake ........................................ 157
Brake assist ............................................. 204
Care Exterior ...................................................380
Interior..................................................... 383
Seat belts ............................................... 384
Cargo capacity ....................................... 216
Cargo hooks .......................................... 359
CD changer ........................................... 250
CD player................................................ 250
Chains ....................................................... 220
Child restraint system Booster seats, definition.....................116
Booster seats, installation ................ 123
Convertible seats, definition ............116
Convertible seats, installation ....... 123
Front passenger occupant classification system ...........................111
Infant seats, definition ..........................116
Infant seats, installation...................... 123
Installing CRS with LATCH anchors ................................................... 121
Installing CRS with seat belts ........ 123 Installing CRS with top straps........126
Child safety Airbag precautions ............................ 106
Battery precautions .................410, 514
Child restraint system ......................... 116
How your child should wear the seat belt ..........................................68
Installing child restraints................... 120
Power window lock switch .............. 78
Power window precautions ........... 80
Removed electronic key battery precautions........................................ 432
Seat belt guide........................................66
Seat belt extender precautions...... 70
Seat belt precautions ..........................69
Seat heater precautions..................357
Trunk precautions................................. 49
Cigarette lighter....................................353
Cleaning Exterior................................................... 380
Interior .................................................... 383
Seat belts ............................................... 384
Clock .........................................................348
Compass ..................................................368
Condenser ..............................................406
Console box ............................................ 341
Cooling system Engine overheating............................ 515
Cornering assist sensors .................... 198
B
C

583
Alphabetical index
EngineCompartment ..................................... 398
Engine switch ........................................ 142
Hood ....................................................... 395
How to start the engine.................... 142
Identification number....................... 533
If the engine will not start ...............503
Ignition switch........................................ 142
Overheating...........................................515
Engine compartment cover............. 400
Engine coolant Capacity................................................. 537
Checking ............................................... 404
Preparing and checking before winter .................................... 220
Engine coolant temperature gauge .......................................................160
Engine immobilizer system ..................93
Engine oil Capacity................................................. 536
Checking .................................................401
Preparing and checking before winter .................................... 220
Engine oil maintenance data ........... 403
EPS............................................................. 204
Event data recorder............................. 467 Floor mat ................................................. 358
Fluid
Brake ....................................................... 406
Washer ...................................................... 411
Fog lights Switch......................................................... 177
Wattage .................................................. 547
Foot well lights ...................................... 338
Front fog lights Switch......................................................... 177
Wattage .................................................. 547
Front passenger occupant classification system ............................. 111
Front passenger's seat belt reminder light........................................471
Front seats Adjustment .................................................51
Driving position memory ..................56
Seat position memory ........................60
Front turn signal lights Switch........................................................ 156
Wattage .................................................. 547
Fuel Capacity ................................................ 535
Fuel gauge.............................................. 160
Fuel pump shut off system............ 466
Information ........................................... 548
Refueling....................................................90
Fuel door .....................................................90
Fuel filler door ...........................................90
Fuel pump shut off system ................. 466
Fuses .......................................................... 433F

588
Alphabetical index
TachometerTacho indicator.................................... 160
Tachometer ........................................... 160
Tail lights Switch ........................................................ 174
Talk switch ..................................................311
Telephone switch .....................................311
Theft deterrent system Alarm .......................................................... 95
Engine immobilizer system ............. 93
Theft prevention labels .......................... 97
Tire inflation pressure ......................... 422
Tire information Glossary................................................. 557
Size ...........................................................554
Tire identification number .............553
Uniform tire quality grading ........ 555
Tires Chains ..................................................... 220
Checking ................................................. 412
If you have a flat tire .......................... 492
Inflation pressure................................ 422
Inflation pressure sensor.................. 413
Information............................................. 551
Replacing ............................................... 492
Rotating tires .......................................... 412
Run-flat tire............................................. 501
Size ........................................................... 542
Snow tires .............................................. 220
Spare tire................................................ 492
Tools ........................................................... 492
Total load capacity ................................ 219 Towing
Dinghy towing .........................225, 226
Emergency towing ........................... 459
Trailer towing ....................................... 224
TRAC ........................................................ 204
Traction control..................................... 204
Transmission shift switches........ 149, 151
Trip meter ................................................. 160
Trunk Opener ...................................................... 47
Trunk light Trunk light ................................................ 48
Wattage ..................................................547
Turn signal lights Replacing light bulbs ....................... 450
Switch ........................................................ 156
Wattage ..................................................547
Vanity lights Vanity lights...........................................347
Wattage ..................................................547
Vanity mirrors ........................................ 347
VDIM......................................................... 204
Vehicle dynamics integrated management ....................................... 204
Vehicle identification number......... 533
Vehicle stability control ..................... 204
Ventilators ............................................... 355
Voice command switch .......................312
VSC ........................................................... 204T
V

589
Alphabetical index
Warning buzzersBrake system ....................................... 469
Open door ............................................ 471
Seat belt reminder .............................. 471
Warning lights Anti-lock brake system .................. 470
Brake assist system .......................... 470
Brake system ....................................... 469
Charging system ............................... 469
Electric power steering warning light ..................................... 470
Low fuel level......................................... 471
Malfunction indicator lamp .......... 470
Master warning light .......................... 471
Open door ............................................. 471
Pre-collision system ......................... 470
Pretensioners ...................................... 470
Seat belt reminder light .................... 471
SRS airbags .......................................... 470
Tire pressure warning light.......................................................... 471
Warning messages Dynamic radar cruise control .........................479, 481
Engine oil level ......................................481
Engine oil maintenance....................481
Engine oil pressure........................... 478
Hood .........................................................481
Intuitive parking assist ...........479, 481
Open door .............................................481
Parking brake ........................................481
Pre-collision system ...............479, 481
Retractable hardtop ...............479, 481 Smart access system with
push-button start ........................... 488
Steering lock......................................... 479
Tire pressure warning system..................... 479, 481
Trunk ......................................................... 481
Washer fluid .......................................... 481
Washer Checking .................................................. 411
Preparing and checking before winter ....................................220
Switch........................................................ 178
Washing and waxing .......................... 380
Weight Cargo capacity .....................................216
Load limits ...............................................219
Weight.....................................................532
Wheels ...................................................... 426
Window glasses ...................................... 78
Window lock switch ............................... 78
Windows Power windows ..................................... 78
Rear window defogger...................238
Washer .................................................... 178
Windshield wipers................................. 178
Wireless remote control key Replacing the battery........................ 431
WMA disc ............................................... 257W
