LEXUS IS250C 2013 Workshop Manual

51
1
1-2. Opening, closing and locking the doors and trunk
Before driving
Tr u n k
Locking the trunk opener feature
Turn the trunk opener main switch
in the glove box off to disable the
trunk opener.On
Off
The trunk lid cannot be opened
even with the wireless remote con-
trol or the entry function.
The trunk can be opened using the trun k opener, entry function or wireless
remote control.
■ Opening the trunk from inside the vehicle
Press the opener switch.
■ Opening the trunk from outside the vehicle
Entry function
 P. 3 3
Wireless remote control
 P. 4 4

52
1-2. Opening, closing and locking the doors and trunk
■Tr u n k l i g h t
When the trunk light switch is set to on, the trunk light turns on when the trunk is
opened.
■Tr u n k h a n d l e
■Internal trunk release lever
■Using the mechanical key
The trunk can be also opened using the mechanical key. ( P. 5 2 8 )
■When the retractable hardtop is operating
The trunk lid cannot be opened. Wait until the retractable hardtop is fully opened or
closed before opening the trunk lid.
On
Off
Use the trunk handle when closing the trunk.
The trunk lid can be open ed by pulling on the
glow-in-the-dark lever located on the inside
of the trunk lid.
The lever will continue to glow for some time
after the trunk lid is closed.

53
1-2. Opening, closing and locking the doors and trunk
1
Before driving
■Which key to the vehicle is to leave with a parking attendant after disabling the
trunk opener main switch
P. 3 0
CAUTION
■Caution while driving
●Keep the trunk lid closed while driving.
If the trunk lid is left open, it may hit near-by objects while driving or luggage in
the trunk may be unexpectedly th rown out, causing an accident.
In addition, exhaust gases may enter th e vehicle, causing death or a serious
health hazard. Make sure to clos e the trunk lid before driving.
●Before driving the vehicle, make sure that the trunk lid is fully closed. If the trunk
lid is not fully closed, it may open unexpe ctedly while driving, causing an accident.
●Never let anyone sit in the trunk. In the ev ent of sudden braking or a collision, they
are susceptible to death or serious injury.
■When children are in the vehicle
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not allow children to enter the trunk.
If a child is accidentally locked in the trunk, they could overheat or suffocate.
●Do not allow a child to open or close the trunk lid.
Doing so may cause the trunk lid to oper ate unexpectedly, or cause the child’s
hands, head, or neck to be caught by the closing trunk lid.

54
1-2. Opening, closing and locking the doors and trunk
CAUTION
■Using the trunk
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in serious injury.
●Remove any heavy loads, such as snow and ice, from the trunk lid before opening
it. Failure to do so may cause the trunk lid to suddenly shut again after it is opened.
●When opening or closing the trunk lid, thoroughly check to make sure the sur-
rounding area is safe.
●If anyone is in the vicinity, make sure they are safe and let them know that the
trunk is about to open or close.
●Use caution when opening or closing the trunk lid in windy weather as it may
move abruptly in strong wind.
●Do not attach any accessories other than genuine Lexus parts to the trunk lid.
Such additional weight on the trunk lid may cause the lid to suddenly shut again
after it is opened.
●The trunk lid may suddenly shut if it is not
opened fully. It is more difficult to open or
close the trunk lid on an incline than on a
level surface, so beware of the trunk lid
unexpectedly opening or closing by
itself. Make sure that the trunk lid is fully
open and secure before using the trunk.
●When closing the trunk lid, take extra
care to prevent your fingers etc. from
being caught.
●When closing the trunk lid, make sure to
press it lightly on its outer surface. If the
trunk handle is used to fully close the
trunk lid, it may result in hands or arms
being caught.

55
1
Before driving
1-3. Adjustable components (seats, mirrors, steering wheel)
Front seats
Seat position switch
Seatback angle switch
Seat cushion (front) angle switch
Vertical height adjustment switch
Lumbar support switch
Seatback fold lever
Entering or exiting the rear seats
Ty p e A
Ty p e B

56
1-3. Adjustable components (seats, mirrors, steering wheel)
Entering/exiting the rear seats
Type A  Switch-operated “Front, Fold & Return” Seat
Moving the front seat forward or ba ckward using the switch enables
passengers to enter or exit the rear seats smoothly and easily.
■ When entering/exiting the rear seats
Press the fold switch once. The
seatback of the front seat will fold
and the seat will move forward.
For safety reasons, the seat will be
stopped at a position slightly
behind the most-forward position.
To move the seat further to the
most-forward position, press and
hold the switch again after the seat
is stopped.

57
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
■Returning the front seats to the or iginal position (auto return func-
tion)
Press the return switch once. The
seatback of the front seat will
return to the upright position and
the seat will move backward.
*
For safety reasons, if the front seat
was originally positioned close to
the rear seat, the seat will be
stopped at a position slightly in
front of the original position. To
return the seat to its original posi-
tion, press the return switch again.
After the seat is returned to the
original position, pressing and
holding the return switch moves
the seat back further.
*: The return function can be set to activate only while the switch is
being pressed. ( P. 3 6 5 )

58
1-3. Adjustable components (seats, mirrors, steering wheel)
Type B  Seat slide switches (passenger’s seat only)
Press and hold the switch to move
the seat forward.
Fold the seatback using either of
the seatback fold levers.
STEP1
STEP2

59
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
■Switch-operated “Front, Fold & Return” Seat
●When the auto return function is on, a buzzer will sound intermittently while the
switch-operated “Front, Fold & Return” seat is in motion.
●If any seat adjustment switch or driving position memory switch is operated
after the seat is moved to the forward and fold position using the “Front, Fold &
Return” seat switch, the seat cannot be returned using the “Front, Fold & Return”
seat switch. Use a switch other than the “Front, Fold & Return” seat switch to
return the seat.
●The switch-operated “Front, Fold & Return” seat cannot operate when:
• A person or item of luggage is on th e seat or the seat belt is fastened.
• The vehicle is moving.
●Operation of the Switch-operated “Front, Fold & Return” Seat will stop if:
• The “Front, Fold & Return” seat switch is pressed again.
• Any seat adjustment swit ch or driving position memory switch is pressed.
• A person enters the seat or an item of luggage is put on the seat (during for- ward movement only).
• The vehicle starts off.
• The seat belt is fastened (during forward movement only).
■When the seatback is fully reclined
Do not use the seatback fold lever to rais e the front seat as this may prevent the
seatback from locking in place.
If the seatback will not lock, press and ho ld the seatback angle switch forward for a
few seconds to change the memorized seat position. Raise the seatback by hand
and check that it locks in position as normal.

60
1-3. Adjustable components (seats, mirrors, steering wheel)
CAUTION
■Seat adjustment
Do not recline the seat more than necessary when the vehicle is in motion to reduce
the risk of sliding under the lap belt.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint
forces directly to the abdomen or your neck may contact the shoulder belt, increas-
ing the risk of death or serious in jury in the event of an accident.
■Retuning the folded seatback to the upright position
Pull the seatback up by hand.
If the seatback angle switch is used to return the seatback, the seat may not be
locked in position, resulting in an accident.
After returning the seat, rock the seat back and forth to ensure that it is securely
locked in position.
■When the vehicle is moving
Do not operate the seatback fold levers.
■Switch-operated “Front, Fold & Return” Seat
●Before operating the switch, ensure that no surrounding passengers or objects
are caught in the seat. Seat operation will not stop automatically, even if some-
thing becomes caught in the seat. This ma y result in death or serious injury.
●Do not operate the switch while the vehicle is moving.
