AIR CONDITIONING
128
CAUTION
Do not use the ºFRONT WINDSHIELDº button during
cooled air operation in extremely humid weather. The
difference between the temperature of the outside air
and that of the windshield could cause the outer surface
of the windshield to fog up blocking your vision.
(c) Air filter
The air filter may clog after long use and reduce air flow. You
can inspect the filter easily.
The air conditioning filter may clog after long use. The filter
may need to be replaced if the air flow of the air conditioner and
heater experiences extreme reductions in operating ef ficiency,
or if the windows become to fog up easily.
When you inspect and replace the air filter, be sure to turn off
the fan.
SS21013
1. Remove the glove box.
Remove belongings stored in the glove box, and remove the
two pins installed on the lower part of the glove box, and
remove the glove box.
2. Remove the cover.

AIR CONDITIONING
129
SS21015
3. Take out the air filter.
If it is dirty, it should be replaced. To maintain the air
conditioning efficiency, replace the air filter according to the
maintenance schedule. (For scheduled maintenance
information, please refer to the ºOwner's Manual Supplement
/ Maintenance Scheduleº.)
NOTICE
Do not drive with the air filter removed, or the efficiency
of air conditioning may be lost.
(d) Operating tips
 To help cool down the interior after parking in the hot sun,
drive for the first few minutes with the windows open. After
the excess heat has blown away, close the windows.
 Make sure the air inlet grilles in front of the windshield are
not blocked by leaves or other obstructions.
 If air flow control is not satisfactory, check the dashboard
vents. (See ºCenter ventsº and ºSide ventsº.)
 On humid days, do not blow cold air on the windshield. The
windshield could fog up because of the difference in air
temperature on the inside and outside of the windshield.
 Keep the area under the front seats clear to allow air to
circulate throughout the vehicle.
 On cold days, push the fan speed selector to adjust the fan
speed high for a minute to help clear the intake ducts of
snow or moisture. This can reduce the amount of fogging
on the windows.
 When driving on dusty roads, close all windows. If dust
thrown up by the vehicle is still drawn into the vehicle after
closing the windows, it is recommended that the air intake
control button be left to the OUTSIDE AIR mode and the fan
speed control dial be turned to anywhere except the ºOFFº
button.
 If following another vehicle on a dusty road, or driving in
windy and dusty conditions, it is recommended that the air
intake control button be temporarily pressed in to the
RECIRCULATED AIR mode, which will close off the outside
passage and prevent outside air and dust from entering the
vehicle interior.

AIR CONDITIONING
130Heating
For best results, set controls to:
For automatic operation ±
Set the air flow control dial and the fan speed control
dial to ºAUTOº position.
Temperature ± To the desired temperature
Air intake ± OUTSIDE AIR
For manual operation ±Fan speed ± To the desired fan speed
Temperature ± Towards WARM (to the right)
Air intake ± OUTSIDE AIR
Air flow ± FLOOR
 For quick heating, select RECIRCULATED AIR for a few
minutes. To keep the windows from fogging, select
OUTSIDE AIR after the vehicle interior has been warmed.
 Push the ºA/Cº button on for dehumidified heating.
 Choose floor/windshield air flow to heat the vehicle interior
while defrosting or defogging the windshield. Air conditioning
For best results, set controls to:
For automatic operation ±
Set the air flow control dial and the fan speed control
dial to ºAUTOº position.
Temperature ± To the desired temperature
Air intake ± OUTSIDE AIR
For manual operation ±Fan speed ± To the desired fan speed
Temperature ± Towards COLD (to the left)
Air intake ± OUTSIDE AIR
Air flow ± PANEL
 For quick cooling, select RECIRCULATED AIR for a few
minutes.
Ventilation
For best results, set controls to:
For automatic operation ±
Set the air flow control dial and the fan speed control
dial to ºAUTOº position.
Temperature ± Towards low temperature
Air intake ± OUTSIDE AIR

AIR CONDITIONING
131
For manual operation ±
Fan speed ± To the desired fan speed
Temperature ± Towards COLD (to the left)
Air intake ± OUTSIDE AIR
Air flow ± PANEL
Defogging and defrosting
± The inside of the windshield
For best results, set controls to:
For automatic operation ±
Temperature ± Towards high temperature to heat; low temperature to cool
Air intake ± OUTSIDE AIR
AIR FLOW ± WINDSHIELD
For manual operation ±
Fan speed ± To the desired fan speed
Temperature ± Towards WARM (to the right) to heat;
COLD (to the left) to cool
Air intake ± OUTSIDE AIR
Air flow ± WINDSHIELD
Set the air flow control dial to the windshield or floor/windshield
position turns on the defogging function with the purpose of
clearing the front view. When turning the air flow selector to windshield position, the
air intake selects FRESH automatically.
This is to clean up the
front view more quickly.
If you want to return the setting to RECIRCULATE mode, press
the air intake selector button once again.
Press the ºA/Cº button for dehumidified heating or cooling. This
setting clears the front view more quickly.
 On humid days, do not blow cold air on the windshield ± the
difference between the outside and inside temperatures
could make the fogging worse.
± The outside of the windshield
For best results, set controls to:
For automatic operation ±
Temperature ± Towards high temperature
Air intake ± OUTSIDE AIR
Air flow ± WINDSHIELD

AIR CONDITIONING
132For manual operation ±
Fan speed ± To the desired fan speed
Temperature ± Towards WARM (to the right)
Air intake ± OUTSIDE AIR
Air flow ± WINDSHIELD
Set the air flow control dial to the windshield or floor/windshield
position turns on the defrosting function with the purpose of
clearing the front view.
When turning the air flow selector to windshield position, the
air intake selects FRESH automatically. This is to clean up the
front view more quickly.
If you want to return the setting to RECIRCULATE mode, press
the air intake selector button once again.
Press the ºA/Cº button for dehumidified heating or cooling. This
setting clears the front view more quickly.
 To heat the vehicle interior while defrosting the windshield,
choose floor/windshield air flow.
Center vents
SS21017
The center vents may be opened or closed as shown.
Side vents
SS21019
The side vents may be opened or closed as shown.

AIR CONDITIONING
133

SECTION 2 ± 2
134
AIR CONDITIONING AND AUDIO
Audio
Audio system135
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .

AUDIO
135
AUDIO SYSTEM
Quick reference for your audio system
SV22030

You can adjust the brightness of the display. See ºInstrument panel light controlº on page 46 for details.

AUDIO
136
1Turning the system on and adjusting volume
(See page 137 for details.)
2Compact disc slot
(See page 150 for details.)
3Ejecting a compact disc
(See page 150 for details.)
4Radio data system/Traffic announcement/
Program type
(See page 143 for details.)
5Compact disc pre±load button
(See page 150 for details.)
6Audio control knob/Frequency tuning
(See page 138 for details.)
7Mode selectors
(See page 137 for details.)
8Message
(See page 146 for details.)
9Function buttons
1 ± 6: Station selector buttons
(See page 141 for details.)
:Disc selection
(See page 152 for details.)
RPT: Automatic repeat
(See page 149 or 154 for details.) RAND:
Random access
(See page 154 for details.)
SKIP: Automatic skip of blank portions of tape
(See page 149 for details.)
 :Rewinding or reversing
(See page 148 or 153 for details.)


:Fast forwarding
(See page 148 or 153 for details.)
:


: Side change
(See page 148 for details.)
DOLBY NR button
(See page 148 for details.)
10Cassette tape slot
(See page 147 for details.)
11Ejecting a cassette tape
(See page 147 for details.)
12Radio mode: Frequency tuning
(See page 140 for details.)
TAPE mode: Direct access to a desired program
(See page 149 for details.)
CD mode: Direct access to a desired program
(See page 153 for details.)
13Scan tuning button
(See page 142 for details.)

AUDIO
137
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some information may not pertain to your
system.
Your audio system works when the ignition key is in the ºACCº
or ºONº position.
NOTICE
To prevent the battery from being discharged, do not leave the car audio on longer than necessary when theengine is not running.
(a) Turning the system on and off
SV22002
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.
SV22003
Push ºAMº, ºFMº, ºT APEº or ºDISCº to turn on that mode.
The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or disc is not set, the cassette player or compact disc
player does not turn on.
You can turn off the cassette player by ejecting the cassette
tape. If the audio system was previously off, then the entire
audio system will be turned off when you eject the cassette
tape. If another function was previously playing, it will come on
again.
