AIR CONDITIONING
188
SV21015
2. Remove the cover and take out the air filter
If it is dirty, it should be replaced. To maintain the air
conditioning efficiency, replace the air filter according to the
maintenance schedule. (For scheduled maintenance
information, please refer to the ºOwner's Manual Supplement
/ Scheduled Maintenanceº.)
INFORMATION
The air filter should be installed properly in position.The use of air conditioning with the air filter removedmay cause deteriorated dustproof performance andthen affect air conditioning performance.
(d) Operating tips
 To help cool down the interior after parking in the hot sun,
drive for the first few minutes with the windows open. After
the excess heat has blown away, close the windows.
 Make sure the air inlet grilles in front of the windshield are
not blocked by leaves or other obstructions.
 If air flow control is not satisfactory, check the dashboard
vents. (See ºCenter ventsº and ºSide ventsº.)
 On humid days, do not blow cold air on the windshield. The
windshield could fog up because of the difference in air
temperature on the inside and outside of the windshield.
 Keep the area under the front seats clear to allow air to
circulate throughout the vehicle.
 On cold days, set the fan speed selector to adjust the fan
speed high for a minute to help clear the intake ducts of
snow or moisture. This can reduce the amount of fogging
on the windows.
 When driving on dusty roads, close all windows. If dust
thrown up by the vehicle is still drawn into the vehicle after
closing the windows, it is recommended that the air intake
control button be left to the OUTSIDE AIR mode and the fan
speed control dial be turned to anywhere except the ºOFFº
button.
 If following another vehicle on a dusty road, or driving in
windy and dusty conditions, it is recommended that the air
intake control button be temporarily pressed in to the
RECIRCULATED AIR m ode, which will close off the outside
passage and prevent outside air and dust from entering the
vehicle interior.
2003 IS300 from Aug. '02 Prod. (OM53439U)

AIR CONDITIONING
189
Heating
For best results, set controls to:
For automatic operation ±
Set the air flow control dial and the fan speed control
dial to ºAUTOº position.
Temperature ± To the desired temperature
Air intake ± OUTSIDE AIR
For manual operation ±Fan speed ± To the desired fan speed
Temperature ± Towards WARM (to the right)
Air intake ± OUTSIDE AIR
Air flow ± FLOOR
 For quick heating, select RECIRCULATED AIR for a few
minutes. To keep the windows from fogging, select
OUTSIDE AIR after the vehicle interior has been warmed.
 Push the ºA/Cº button on for dehumidified heating.
 Choose floor/windshield air flow to heat the vehicle interior
while defrosting or defogging the windshield. Air conditioning
For best results, set controls to:
For automatic operation ±
Set the air flow control dial and the fan speed control
dial to ºAUTOº position.
Temperature ± To the desired temperature
Air intake ± OUTSIDE AIR
For manual operation ±Fan speed ± To the desired fan speed
Temperature ± Towards COLD (to the left)
Air intake ± OUTSIDE AIR
Air flow ± PANEL
 For quick cooling, select RECIRCULATED AIR for a few
minutes.
Ventilation
For best results, set controls to:
For automatic operation ±
Set the air flow control dial and the fan speed control
dial to ºAUTOº position.
Temperature ± Towards low temperature
Air intake ± OUTSIDE AIR
2003 IS300 from Aug. '02 Prod. (OM53439U)

AIR CONDITIONING
190For manual operation ±
Fan speed ± To the desired fan speed
Temperature ± Towards COLD (to the left)
Air intake ± OUTSIDE AIR
Air flow ± PANEL
Defogging and defrosting
± The inside of the windshield
For best results, set controls to:
For automatic operation ±
Temperature ± Towards high temperature to heat; low temperature to cool
Air intake ± OUTSIDE AIR
AIR FLOW ± WINDSHIELD
For manual operation ±
Fan speed ± To the desired fan speed
Temperature ± Towards WARM (to the right) to heat;
COLD (to the left) to cool
Air intake ± OUTSIDE AIR
Air flow ± WINDSHIELD
Set the air flow control dial to the windshield or floor/windshield
position turns on the defogging function with the purpose of
clearing the front view. When turning the air flow selector to windshield position, the
air intake selects FRESH automatically.
This is to clean up the
front view more quickly.
If you want to return the setting to RECIRCULATE mode, press
the air intake selector button once again.
Press the ºA/Cº button for dehumidified heating or cooling. This
setting clears the front view more quickly.
 On humid days, do not blow cold air on the windshield ± the
difference between the outside and inside temperatures
could make the fogging worse.
± The outside of the windshield
For best results, set controls to:
For automatic operation ±
Temperature ± Towards high temperature
Air intake ± OUTSIDE AIR
Air flow ± WINDSHIELD
2003 IS300 from Aug. '02 Prod. (OM53439U)

AIR CONDITIONING
191
For manual operation ±
Fan speed ± To the desired fan speed
Temperature ± Towards WARM (to the right)
Air intake ± OUTSIDE AIR
Air flow ± WINDSHIELD
Set the air flow control dial to the windshield or floor/windshield
position turns on the defrosting function with the purpose of
clearing the front view.
When turning the air flow selector to windshield position, the
air intake selects FRESH automatically. This is to clean up the
front view more quickly.
If you want to return the setting to RECIRCULATE mode, press
the air intake selector button once again.
Press the ºA/Cº button for dehumidified heating or cooling. This
setting clears the front view more quickly.
 To heat the vehicle interior while defrosting the windshield,
choose floor/windshield air flow.
Center vents
SV21026
The center vents may be opened or closed as shown.
Side vents
SS21019
The side vents may be opened or closed as shown.
2003 IS300 from Aug. '02 Prod. (OM53439U)

AIR CONDITIONING
192
2003 IS300 from Aug. '02 Prod. (OM53439U)

SECTION 2 ± 2
193
AIR CONDITIONING AND AUDIO
Audio
Audio system194
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
2003 IS300 from Aug. '02 Prod. (OM53439U)

AUDIO
194
AUDIO SYSTEM
Quick reference for your audio system (Type A)
SV22049

You can adjust the brightness of the display. See ºInstrument panel light controlº on page 53 for details.
2003 IS300 from Aug. '02 Prod. (OM53439U)

AUDIO
195
1Turning the system on and adjusting the volume
(See page 198 for details.)
2Compact disc slot
(See page 211 for details.)
3Ejecting a compact disc
(See page 212 for details.)
4Radio data system/Traffic announcement/
Program type
(See page 204 for details.)
5Compact disc pre±load button
(See page 211 for details.)
6Audio control knob/Frequency tuning
(See page 199 for details.)
7Mode selectors
(See page 198 for details.)
8Message
(See page 207 for details.)
9Function buttons
1 ± 6: Station selector buttons
(See page 202 for details.)
:Disc selection
(See page 214 for details.)
RPT: Automatic repeat
(See page 210 or 216 for details.) RAND:
Random access
(See page 216 for details.)
SKIP: Automatic skip of blank portions of tape
(See page 210 for details.)
 :Rewinding or reversing
(See page 209 or 216 for details.)


:Fast forwarding
(See page 209 or 216 for details.)
:


: Side change
(See page 209 for details.)
DOLBY NR button(See page 209 for details.)
10Cassette tape slot
(See page 208 for details.)
11Ejecting a cassette tape
(See page 208 for details.)
12Radio mode: Frequency tuning
(See page 202 for details.)
TAPE mode: Direct access to a desired program
(See page 210 for details.)
CD mode: Direct access to a desired program
(See page 216 for details.)
13Scan tuning button
(See page 203 for details.)
2003 IS300 from Aug. '02 Prod. (OM53439U)

AUDIO
196
Quick reference for your audio system (Type B)
SV22045

You can adjust the brightness of the display. See ºInstrument panel light controlº on page 53 for details.
2003 IS300 from Aug. '02 Prod. (OM53439U)

AUDIO
197
1Turning the system on and adjusting the volume
(See page 198 for details.)
2Compact disc slot
(See page 213 for details.)
3Ejecting a compact disc
(See page 213 for details.)
4Audio control knob/Frequency tuning
(See page 199 for details.)
5Mode selectors
(See page 198 for details.)
6Cassette tape slot
(See page 208 for details.)
7Function buttons
1 ± 6: Station selector buttons
(See page 202 for details.)
:Disc selection
(See page 214 for details.)
RPT: Automatic repeat
(See page 210 or 216 for details.)
RAND: Random access
(See page 216 for details.)
SKIP: Automatic skip of blank portions of tape
(See page 210 for details.)
:Rewinding or reversing
(See page 209 or 216 for details.)


:Fast forwarding
(See page 209 or 216 for details.)
:


: Side change
(See page 209 for details.)
DOLBY NR button
(See page 209 for details.)
8Ejecting a cassette tape
(See page 208 for details.)
9Radio mode: Frequency tuning
(See page 202 for details.)
TAPE mode: Direct access to a desired program
(See page 210 for details.)
CD mode: Direct access to a desired program
(See page 216 for details.)
10Scan tuning button
(See page 203 for details.)
