SECTION 4
265
IN CASE OF AN EMERGENCY
In case of an emergency
If your engine stalls while driving266
. . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot increase the engine speed 266
. . . . . . . . . . . . . . . . . . . .
If your vehicle will not start 267
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 271
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 272
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
If your vehicle becomes stuck 283
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 284
. . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot shift automatic transmission selector lever 289
. . . . . . .
If you lose your keys or lock yourself out 290
. . . . . . . . . . . . . . . . . . . .
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
266
IF YOUR ENGINE STALLS WHILEDRIVING
If your engine stalls while driving . . . .
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Try starting the engine again.
If the engine will not start, see ºIf your vehicle will not startº\
.
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work, so steering and
braking will be much harder than usual.
IF YOU CANNOT INCREASE THEENGINE SPEED
If the engine speed does not increase with the accelerator
pedal depressed down to about the middle position, there
may be a problem somewhere in your electronic throttle
control system.
At this time, if you depress the accelerator pedal more firmly
and slowly, you can drive you vehicle at low speeds. Have your
vehicle checked by your Lexus dealer as soon as possible.
Even if the abnorma lity of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ºACCº or ºLOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
267
IF YOUR VEHICLE WILL NOTSTART
(a) Simple checks
Before making these checks, make sure you have followed the
correct starting procedure instructions in ºHow to start the
engineº on page 229 and that you have sufficient fuel. Since
your vehicle is equipped with the engine immobiliser system,
also check whether the other keys will start the engine. If they
work, your key may be broken. Have the key checked at your
Lexus dealer. If none of your keys work, the system is possibly
broken. Call your Lexus dealer. See ºKeysº on page 8.
If the engine is not turning over or is turning over too
slowly ±
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is
cranked, the battery is discharged. You may try jump starting.
See º(c) Jump startingº for further instruction.
If the light is O.K., but the engine still will not start, it needs
adjustment or repair. Call a Lexus dealer, Roadside
Assistance or Customer Service Assistance. (See
ºForewordº.)
NOTICE
Do not pull± or push±start the vehicle. It may damage
the vehicle or cause a collision when the engine starts.Also the three±way catalytic converter may overheatand become a fire hazard.
If the engine turns over at its normal speed but will not
start ±
1. The engine may be flooded because of repeated cranking.
See º(b) Starting a flooded engineº for further instructions.
2. If the engine still will not start, it needs adjustment or repair.
Call a Lexus dealer, Roadside Assistance or Customer
Service Assistance. (See ºForewordº.)
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
268
(b) Starting a flooded engine
If the engine will not start, your engine may be flooded
because of repeated cranking.
If this happens, turn the key to ºSTARTº with the accelerator
pedal held down. Continue this operation for 30 seconds and
then stop cranking. Then try starting the engine with your foot
off the accelerator pedal.
If the engine does not start after 30 seconds of cranking,
release the key, wait a few minutes and try again.
If the engine still will not start, it needs adjustment or repair.
Call a Lexus dealer, Roadside Assistance or Customer
Service Assistance. (See ºForewordº.)
NOTICE
Do not crank for more than 30 seconds at a time. This
may overheat the starter and wiring systems.
(c) Jump starting
To avoid serious personal injury and damage to your
vehicle which might result from battery explosion, acid
burns, electrical burns, or damaged electronic
components, these instructions must be followed
precisely.
If you are unsure about how to follow this procedure, we
strongly recommend that you seek help from your Lexus
dealer, Roadside Assistance or Customer Service Assistance.
(See ºForewordº.)
CAUTION
 Batteries contain sulfuric acid which is poisonous
and corrosive. Wear protective safety glasses when
jump starting, and avoid spilling acid on your skin,
clothing, or vehicle.
 If you should accidentally get acid on yourself or in
your eyes, remove any contaminated clothing and
flush the affected area with water immediately. Then
get immediate medical attention. If possible,
continue to apply water with a sponge or cloth while
en route to the medical office.
 The gas normally produced by a battery will explode
if a flame or spark is brought near. Use only
standardized jumper cables and do not smoke or
light a match while jump starting.
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
285

From rear
SS41016b
Place the ignition key in the ºACCº position.
NOTICE
Do not tow with the key removed or in the ºLOCKº
position, as the steering lock mechanism is notstrong enough to hold the front wheels straight.
When lifting wheels, take care to ensure adequateground clearance for towing at the opposite end ofthe raised vehicle. Otherwise, the bumper and/orunderbody of the towed vehicle will be damagedduring towing.
(b) Using a flat bed truck
SS41017
 Tie down points
40E014
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
288
(d) Emergency towing
SV41032
If towing is necessary, we recommend you to have it done
by your Lexus dealer or a commercial tow truck service.
If towing service is not available in an emergency, your
vehicle may be temporarily towed by a cable or chain
secured to the emergency towing eyelet. Use extreme
caution when towing the vehicle.
NOTICE
Only use specified towing eyelet; otherwise yourvehicle may be damaged.
A driver must be in the vehicle to steer it and operate the
brakes. Towing in this manner may be done only on hard±surfaced
roads
for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing eyelet
and towing cable or chain. The eyelet and towing cable
or chain may break and cause serious injury or damage.
NOTICE
Use only a cable or chain specifically intended for use in towing vehicles. Securely fasten the cable or chainto the towing eyelet provided.
Before towing, release the parking brake and put the
transmission in neutral (manual) or ºNº (automatic). The
ignition key must be in ºACCº (engine off) or ºONº (engine
running).
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
289
IF YOU CANNOT SHIFT
AUTOMATIC TRANSMISSION SELECTOR LEVER
SV04012
If you cannot shift the selector lever, use the shift lock
button as follows:
1Turn the ignition key to ºLOCKº or ºACCº. Make sure the
parking brake is applied. Pry up the cover with a
flat±bladed screwdriver or equivalent.
SV04013
2Insert your finger, the screwdriver or equivalent into the
hole to push down the shift lock override button. You can
shift the selector lever while pushing the button.
For your safety, keep the brake pedal depressed.
Be sure to have the system checked by your Lexus dealer as
soon as possible.
2003 IS300 from Aug. '02 Prod. (OM53439U)

IN CASE OF AN EMERGENCY
290
IF YOU LOSE YOUR KEYS ORLOCK YOURSELF OUT
You can purchase a new key at your Lexus dealer if you
can give them the key number and master key.
Even if you lose only one key, contact your Lexus dealer to
make a new key. If you lose all your master keys, you cannot
make new keys; the whole engine immobiliser system must be
replaced.
See the suggestion given in ºKeysº on page 8.
You can use the wireless remote control system with the new
key. Contact your Lexus dealer for detailed information.
If your keys are locked in the vehicle and you cannot get a
duplicate, many Lexus dealers can still open the door for you,
using their special tools. If you must break a window to get in,
we suggest breaking the smallest side window because it is the
least expensive to replace. Be extremely cautious to avoid
cuts from the glass.
2003 IS300 from Aug. '02 Prod. (OM53439U)

ENGINE
310± COOLING SYSTEM
Capacity
7.5 L (7.9 qt., 6.6 lmp.qt.)
Coolant typeºToyota Genuine Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper corrosion protection o\
f
aluminum components
Do not use alcohol type antifreeze or plain water alone.
NOTE:
ºToyota Genuine Long Life Coolantº is filled in your Lexus vehicle. In order \
to avoid technical problems, we strongly recommend using
ºToyota Genuine Long Life Coolantº or equivalent. Please contact your \
Lexus dealer for further details.
± FUEL
Fuel type
Only UNLEADED
Octane rating91 (Research octane number 96) or higher
± IGNITION SYSTEMSpark plug ± Make DENSO ± Gap
SK16R±P11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery ± Open voltage at 20 C (68F):
Charging rates
12.7 V Fully charged
12.3 V Half charged
11.9 V Discharged
[Voltage that is checked 20 minutes after the key is removed with all the
lights turned off]
5A max.
