Page 381 of 389
BODY
368
NOTICE
Dirt or sand adhered to the leather may damage thetreated surface and cause it to wear earlier. Removedirt or sand using a vacuum cleaner.
If a stain should fail to come out with a neutraldetergent, apply a cleaner that does not contain anorganic solvent.
Never use organic substances such as benzine,alcohol or gasoline, or alkaline or acid solutions forcleaning the leather as these could causediscoloring.
Use of a nylon brush or synthetic fiber cloth, etc. mayscratch the fine grained surface of the leather.
Mildew may develop on soiled leather upholstery. Beespecially careful to avoid oil spots. Try to keep your
upholstery always clean.
Long exposure to direct sunlight may cause the leather surface to harden and shrink. Keep your
vehicle in a shaded area, especially in the summer.
The interior of your vehicle is apt to heat up on hotsummer days, so avoid placing on the upholsteryitems made of vinyl or plastic or containing wax asthese tend to stick to leather when warm.
Improper cleaning of the leather upholstery couldresult in discoloration or staining.
If you have any questions about the cleaning of your
Lexus, your local Lexus dealer will be pleased to answer
them.
Carpets, Windows and Seat Belts
Begin by vacuuming thoroughly to remove as much dirt as
possible. Several types of foam cleaners are available; some
are in aerosol cans and others are powders or liquids which
you mix with water to produce a foam. To shampoo the
carpets, use a sponge or brush to apply the foam. Rub in
overlapping circles. Do not apply water ± the best results are
obtained by keeping the carpet as dry as possible. Read the
shampoo instructions and follow them closely.
The seat belts may be cleaned with mild soap and water
or with lukewarm water.
Use a cloth or sponge. As you are cleaning, check the belts
for excessive wear, fraying or cuts.
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 382 of 389
BODY
369
NOTICE
Use a good foam±type shampoo to clean the carpets.
Do not use dye or bleach on the belts ± it may weakenthem.
Do not use the belts until they become dry.
The windows may be cleaned with any household
window cleaner.
When cleaning the inside of the rear window, becareful not to scratch or damage the heater wires orconnectors.
Air Conditioning Control Panel, Car Audio,
Instrument Panel, Console Panel, and
Switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or lukewarm water then lightly
wipe off any dirt.
NOTICE
Do not use organic substances (solvents, kerosene,
alcohol, gasoline, etc.) or alkaline or acidic solutions.
These chemicals can cause discoloring, staining or peeling of the surface.
If you use cleaners or polishing agents, make suretheir ingredients do not include the substancesmentioned above.
If you use a liquid car freshener, do not spill the liquidonto the vehicle's interior surfaces. It may containthe ingredients mentioned above. Immediately cleanany spill using the method mentioned above.
If you have any questions about the cleaning of your
Lexus, your local Lexus dealer will be pleased to answer
them.
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 383 of 389
BODY
370
RAIN CLEARING MIRRORS
The rear view mirrors have been coated to produce a ºrain
clearingº effect. This coating causes the raindrops to
spread, clearing the driver's rear view when it rains.
It is sufficient to wash the mirrors with water for day to day care.
The rain clearing effect is reduced in drizzle and light rain.
In the following cases, the rain clearing effect will be reduced
temporarily, but will gradually recover.
After wiping dirt off the mirrors
When the mirrors fog up
After waxing your vehicle in an automatic car wash
After your vehicle has been parked for a long period in
underground parking lots, etc. where there is no direct
sunlight.
If you would like to restore the rain clearing effect to its normal
level immediately in the above cases, wash the mirrors with
neutral detergent, then rinse thoroughly.
NOTICE
To maintain the rain clearing ability, and prevent the mirrors from being scratched, observe the followingprecautions.
Do not use any glass cleaners that containcompounds.
If ice should jam the mirror, do not scrape the mirror.Use a spray deicer to free the mirror.
Wash off any wax stuck to the mirrors with neutraldetergent and rinse thoroughly as any wax on thesurface of the mirrors can cause the rain clearingeffect to be lost.
Do not use any water repellents as they can destroythe rain clearing effect. If any repellent gets stuck onthe surface of the mirrors, wash it off with neutraldetergent, then rinse thoroughly.
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 384 of 389
SECTION 7
371
REPORTING SAFETY DEFECTS
FOR U.S. OWNERS
Reporting safety defects for U.S. owners
Reporting safety defects for U.S. owners372
. . . . . . . . . . . . . . . . . . . .
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 385 of 389
REPORTING SAFETY DEFECTS FOR U.S. OWNERS
372
REPORTING SAFETY DEFECTSFOR U.S. OWNERS
If you believe that your vehicle has a defect which
could cause a crash or could cause injury or death,
you should immediately inform the National
Highway Traffic Safety Administration (NHTSA) in
addition to notifying Toyota Motor Sales, U.S.A.,
Inc. (Toll±free: 1±800±25±LEXUS).
If NHTSA receives similar complaints, it may open
an investigation, and if it finds that a safety defect
exists in a group of vehicles, it may order a recall
and remedy campaign. However, NHTSA cannot
become involved in individual problems between
you, your dealer, or Toyota Motor Sales, U.S.A.,
Inc.
To contact NHTSA, you may either call the Auto
Safety Hotline toll±free at 1±800±424±9393 (or
366±0123 in Washington, D.C. area) or write to:
NHTSA, U.S. Department of Transportation,
Washington, D.C. 20590. You can also obtain
other information about motor vehicle safety from
the Hotline.
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 386 of 389
WE REALLY CARE ABOUT YOU - PLEASE BUCKLE UP
Lexus has made a special effort to encourage use of seat belts.
Lexus belts are:
Comfortable
Easy to use
Convenient
We encourage you to use your belts every time you drive.
2
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 387 of 389
3
GAS STATION INFORMATION
Fuel selection:
Select premium unleaded gasoline with an Octane Rat-
ing of 91 (Research Octane Number 96) or higher for
optimum engine performance. However, if such pre-
mium type cannot be obtained, you may temporarily use
unleaded gasoline with an Octane Rating as low as 87
(Research Octane Number 91).
Fuel tank capacity:
66 L (17.5 gal., 14.5 lmp.gal.)
Engine oil:
ºToyota Genuine Motor Oilº or equivalent
Oil grade: API grade SL ºEnergy±Conservingº or ILSAC
multigrade engine oil.
Recommend oil viscosity ± SAE 5W±30 if normal
temperatures are below 38 C (100F)
Oil capacity: L (qt., lmp.qt.)
Drain and refill with filter 5.4 (5.7, 4.8)
without filter 5.1 (5.4, 4.5)
See page 315 for detailed information.
Engine coolant:
Capacity: 7.5 L (7.9 qt., 6.6 lmp.qt.)
Coolant type ± ºToyota Genuine Long Life Coolantº or
equivalent
With ethylene±glycol type coolant for a proper corrosion
protection of aluminum components For checking the engine coolant, see page 319.
Do not use alcohol type antifreeze or plain water alone.
Automatic transmission:
Fluid type ± Toyota Genuine ATF Type T±IV
See page 324 for detailed information.
Tire information:
See page 331 through 341 for detailed information.
Tire pressure:
Tire size: 225/45ZR17, 215/45ZR17 or P205/55R16 89V
Tire pressure: cold tires
kPa (kgf/cm
2 or bar, psi)
Ti
re sizeFrontRear
225/45ZR17 ± 240 (2.4, 35)
215/45ZR17 230 (2.3, 33) 230 (2.3, 33)
P205/55R16 89V 230 (2.3, 33) 230 (2.3, 33)
For sustained high speeds above 160 km/h (100 mph), in
countries where such speeds are permitted by law, add the
tire pressure given below to the front tires and rear tires, but
never exceed the maximum cold tire pressure molded on the
tire sidewall.
225/45ZR17 70kPa (0.8 kgf/cm
2, 0.7 bar, 10 psi)
215/45ZR17 70kPa (0.8 kgf/cm2, 0.7 bar, 10 psi)
P205/55R16 89V
Sedan 70kPa (0.8 kgf/cm
2, 0.7 bar, 10 psi)
SportCross Front: 70kPa (0.8 kgf/cm2, 0.7 bar, 10 psi)
Rear: 90kPa (0.9 kgf/cm2, 0.9 bar, 15 psi)
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 388 of 389
1.
You should know as much about the quality and
importance of proper maintenance of your new
vehicle as the people who built it.
The Lexus authorized Repair Manual tells you
how to maintain your vehicle and enables you to
correctly perform your own maintenance.
The best way to keep your new vehicle in top running
order is to maintain it properly from the moment you
drive it off the showroom floor.
The Lexus authorized Repair Manual is packed with
literally everything you need to know to perform your
own maintenance in virtually every area of your new
vehicle.
2003 IS300 from Aug. '02 Prod. (OM53439U)
Page 389 of 389
2.
Maintenance procedures for the engine, chassis,
body, electrical system, and more, are clearly
explained and illustrated.
Periodic maintenance and tune±up
Periodic maintenance and tune±up helps to prevent small
problems from growing into larger ones later on. The repair
manual outlines exactly what maintenance is required and
clearly explains how to do the work yourself step±by±step.
Areas covered include such things as spark plug replacement,
valve clearance adjustment and engine oil and filter
replacement.
Where to obtain theRepair Manual
The repair manual for IS300 written in English, may be
purchased as applicable from any Lexus dealer.
Pub. Name: 2003 IS300 Repair Manual
Pub. No.: Vol.1 RM980U1 Vol.2 RM980U2
2003 IS300 from Aug. '02 Prod. (OM53439U)
