2.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
ii
IMPORTANT INFORMATION ABOUTYOUR LEXUS
Occupant restraint systems
Lexus encourages you and your family to take the time to read
Section 1-6 of this Owner's Manual carefully. In terms of
helping you understand how you can receive the maximum
benefit of the occupant restraint systems this vehicle provides,
Section 1-6 of this Owner's Manual is the most important
section for you and your family to read.
Section 1-6 describes the function and operation concerning
seats, seat belts, SRS airbags and child restraint systems of
this vehicle and some potential hazards you should be aware
of. These systems work together along with the overall
structure of this vehicle in order to provide occupant restraint
in the event of a crash. The effect of each system is enhanced
when it is used properly and together with other systems. No
single occupant restraint system can, by itself, provide you or
your family with the equal level of restraint which these
systems can provide when used together. That is why it is
important for you and your family to understand the purpose
and proper use of each of these systems and how they relate
to each other. The purpose of all occupant restraint systems is to help reduce
the possibility of death or serious injury in the event of a
collision. None of these systems, either individually or
together, can ensure that there is no injury in the event of
collision. However, the more you know about these systems
and how to use them properly, the greater your chances
become of surviving an accident without death or serious
injury.
Seat belts provide the primary restraint to all occupants of the
vehicle, and every occupant of the vehicle should wear seat
belts
properly at all times. Children should always be secured
in child restraint systems that are appropriate for their age and
size. SRS (Supplemental Restraint System) airbags are, as
their names imply, designed to work with, and be supplemental
to, seat belts and are not substitutes for them. SRS airbags
can be very effective in reducing the risk of head and chest
injuries by preventing contact of the head and chest with
interior portions of the vehicle.
In order to be effective, the SRS airbags must deploy with
tremendous speed. The rapid deployment of the SRS airbags
makes the SRS airbags themselves potential sources of
serious injury if an occupant is too close to an airbag, or if an
object or some part of his or her body has been placed between
the occupant and the airbag at the time of deployment. This
is just one example of how the instructions in Section 1-6 of
this Owner's Manual will help ensure proper use of the
occupant restraint systems, and increase the safety they can
provide to you and your family in the event of an accident.
Lexus recommends you to read the provisions in Section 1-6
carefully and refer to them as needed during your time of
ownership of this vehicle.
03 07.09

4.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
ivThis vehicle should not be modified with non-genuine Lexus
products. Modification with non-genuine Lexus products
could af
fect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance pro blems resulting from the modification may not
be covered under warranty.
Spark ignition system of your Lexus
The spark ignition system in your Lexus meets all
requirements of the Canadian Interference-Causing
Equipment Standard.
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti-lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Tires and loading on your Lexus
Underinflated or overinflated tire pressure and the
excess load may result in the deterioration of steering
ability and braking ability, leading to an accident. Check
the tire inflation pressure periodically and be sure to
keep the load limits given in this Owner's Manual. For
details about tire inflation pressure and load limits, see
pages 349 and 274.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.
03 07.09

8.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
viii
Page
1Power door lock switch and power window switches 22, 37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Power rear view mirror control switches 181 . . . . . .
3Rear fog light switch 33
. . . . . . . . . . . . . . . . . . . . . . . . .
4Headlight cleaner switch 36
. . . . . . . . . . . . . . . . . . . . .
5Driving position memory switches 176
. . . . . . . . . . .
6Headlight, turn signal and fog light
switches 30, 32, 33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Transmission shift switches 242
. . . . . . . . . . . . . . . . .
8Instrument panel light control 58
. . . . . . . . . . . . . . . . .
9Cruise control switch 249
. . . . . . . . . . . . . . . . . . . . . . .
10Wiper and washer switches 34
. . . . . . . . . . . . . . . . . . .
11Ignition switch 235
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Emergency flasher switch 40
. . . . . . . . . . . . . . . . . . . .
13Auxiliary box 73
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14Outside temperature display/Clock 63
. . . . . . . . . . . . Page
15Front passenger's seat belt reminder light 51
. . . . .
16Automatic air conditioning controls 190
. . . . . . . . . .
17Car audio 204
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Seat heater switches 40
. . . . . . . . . . . . . . . . . . . . . . . . .
19Glove box 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Parking brake lever 236
. . . . . . . . . . . . . . . . . . . . . . . . .
21Driving pattern selector switch
(Automatic transmission) 238 . . . . . . . . . . . . . . . . . . . .
22Ashtray 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
23Cigarette lighter 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24Automatic transmission selector lever/
Manual transmission gear shift lever 238, 247 . . . . .
25Traction control system off/Snow mode
switch (Manual transmission) 252, 255 . . . . . . . . . . . .
26Hood lock release lever 86
. . . . . . . . . . . . . . . . . . . . . .
03 07.09

10.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
x
Page
1Driver's seat belt reminder light51
. . . . . . . . . . . . . . .
2Open door warning light 55
. . . . . . . . . . . . . . . . . . . . . .
3Tachometer 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Headlight high beam indicator light 32
. . . . . . . . . . .
5Low engine oil level warning light 53
. . . . . . . . . . . . .
6Vehicle stability control system
warning light 56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Turn signal indicator lights 32
. . . . . . . . . . . . . . . . . . .
8Cruise control indicator light 249
. . . . . . . . . . . . . . . .
9Momentary fuel consumption meter 46
. . . . . . . . . . .
10Voltmeter 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
11Automatic headlight leveling system warning
light 56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
12Engine coolant temperature gauge 45
. . . . . . . . . . . .
13Anti-lock brake system warning light 54
. . . . . . . . . .
14Malfunction indicator lamp 54
. . . . . . . . . . . . . . . . . . .
15Fuel gauge 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16Low fuel level warning light 55
. . . . . . . . . . . . . . . . . . . Page
17Odometer and trip meter
48
. . . . . . . . . . . . . . . . . . . . .
18Power mode indicator light 240
. . . . . . . . . . . . . . . . . .
19Snow mode indicator light 240
. . . . . . . . . . . . . . . . . . .
20ODO/TRIP knob 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Automatic transmission indicator lights 238 . . . . . .
22M mode indicator 241
. . . . . . . . . . . . . . . . . . . . . . . . . . .
23Gear position indicator for manual control 241 . . . .
24Discharge warning light 52
. . . . . . . . . . . . . . . . . . . . . .
25Rear light failure warning light 55
. . . . . . . . . . . . . . . .
26Security indicator light 27
. . . . . . . . . . . . . . . . . . . . . . .
27Traction control system
off indicator/warning light 55 . . . . . . . . . . . . . . . . . . . .
28Low engine oil pressure warning light 52
. . . . . . . . .
29Slip indicator light 252, 255, 258
. . . . . . . . . . . . . . . . . .
30Brake system warning light 50
. . . . . . . . . . . . . . . . . . .
31SRS warning light 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Engine oil replacement reminder light 53
. . . . . . . . .
03 07.09

12.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xii
Page
1Tachometer47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Headlight high beam indicator light 32
. . . . . . . . . . .
3Low engine oil level warning light 53
. . . . . . . . . . . . .
4Vehicle stability control system warning light 56 . .
5Turn signal indicator lights 32
. . . . . . . . . . . . . . . . . . .
6Cruise control indicator light 249
. . . . . . . . . . . . . . . .
7Momentary fuel consumption meter 46
. . . . . . . . . . .
8Voltmeter 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
9Automatic headlight leveling system warning
light 56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
10Engine coolant temperature gauge 45
. . . . . . . . . . . .
11Anti-lock brake system warning light 54
. . . . . . . . . .
12Malfunction indicator lamp 54
. . . . . . . . . . . . . . . . . . .
13Fuel gauge 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14Low fuel level warning light 55
. . . . . . . . . . . . . . . . . . .
15Odometer and trip meter 48
. . . . . . . . . . . . . . . . . . . . .
16Power mode indicator light 240
. . . . . . . . . . . . . . . . . . Page
17Snow mode indicator light
240
. . . . . . . . . . . . . . . . . . .
18ODO/TRIP knob 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Automatic transmission indicator lights 238 . . . . . .
20M mode indicator 241
. . . . . . . . . . . . . . . . . . . . . . . . . . .
21Gear position indicator for manual control 241 . . . .
22Discharge warning light 52
. . . . . . . . . . . . . . . . . . . . . .
23Rear light failure warning light 55
. . . . . . . . . . . . . . . .
24Security indicator light 27
. . . . . . . . . . . . . . . . . . . . . . .
25Traction control system
off indicator/warning light 55 . . . . . . . . . . . . . . . . . . . .
26Low engine oil pressure warning light 52
. . . . . . . . .
27Slip indicator light 252, 255, 258
. . . . . . . . . . . . . . . . .
28Brake system warning light 50
. . . . . . . . . . . . . . . . . . .
29SRS warning light 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Open door warning light 55
. . . . . . . . . . . . . . . . . . . . . .
31Driver's seat belt reminder light 51
. . . . . . . . . . . . . . .
03 07.09

KEYS AND DOORS
21
NOTE: *The 2-step unlocking function can be changed.**The interior light can be set not to come on or the durationof lighting can be changed. Ask your Lexus dealer for details.
Locking with inside lock button
SV11004

1Lock 2Unlock
Push in the lock button to lock and unlock the door.
The front doors can be opened by pulling the inside handles
even if the lock buttons are in the locked position.
CAUTION
Do not pull the inside handle of the front doors while
driving. The doors will open and an accident may occur.
Lexus strongly recommends that all children be placed
in the rear seat of the vehicle.
Closing the door with the lock button pushed in will also lock
the door. Be careful not to lock your keys in the vehicle. The
door will not lock if the key is left in the ignition switch when
closing the front doors.
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle during an accident.
It also helps prevent the doors from being opened
unintentionally.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
48
ODOMETER AND TRIP METER
SV13015
This meter displays the odometer and two trip meters. To
change the mode indication, push the ºODO/TRIPº knob
briefly. Each time you push the knob, the mode changes
in order from the odometer to trip meter A to trip meter B,
then back to the odometer, etc.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To set A trip meter to zero, display the A meter reading,
push the knob and hold it. The same applies for the B trip
meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS AND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)or
(Indicator and buzzer)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver's seat
belt
(c)Fasten front
passenger's seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)Stop and check.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
(b) Driver's Seat Belt Reminder Light andBuzzer
This light and buzzer remind you to buckle up the driver's seat
belt.
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes and buzzer sounds if the driver's seat
belt is not fastened. Unless the driver fastens the belt, the light
stays flashing and the buzzer stops after about 4 to 8 seconds.
(c) Front Passenger's Seat Belt Reminder Light
This light reminds you to buckle up the front passenger's seat
belt.
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes if a passenger sits in the front passenger
seat and does not fasten the seat belt. Unless the front
passenger fastens the belt, the light stays flashing. However,
if a front passenger uses an additional seat cushion, the light
may not flash even when the seat belt is not buckled up.
If luggage or other load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built-in sensors in the seat cushion may detect the pressure,
causing the reminder light to come on.
(d) SRS Warning Light
The indicator comes on when the ignition key is turned to
the ºACCº or ºONº position. It goes off after about 6
seconds. This means the SRS airbags and front seat belt
pretensioners are operating properly.
The SRS warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensors, front seat belt pretensioner assemblies, inflators,
warning light, interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the components monitored by the
warning light system. Contact your Lexus dealer as soon as
possible to service the vehicle.
 When the ignition key is turned to the ºACCº or ºONº
position, the light does not come on, remains on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side and curtain
shield airbags and/or seat belt pretensioners fail.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on - evenfor one block. It may ruin the engine.
03 07.09

INTERIOR EQUIPMENT
75
WARNING REFLECTOR HOLDER
Sedan
SS14092

1To loosen 2To tighten
This belt is designed to hold the warning reflector.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Although the warning reflector itself is not included as an
original equipment, this belt can be used to store the warning
reflector.
Make sure the warning reflector is securely held.
SportCross
SV14040
The warning reflector is in the auxiliary box.
Although the warning reflector itself is not included as an
original equipment, this auxiliary box can be used to store the
warning reflector.
03 07.09
