cruise control Lexus IS300 2004 Air Conditioning / LEXUS 2004 IS300 OWNER'S MANUAL (OM53461U)

4.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
ivThis vehicle should not be modified with non-genuine Lexus
products. Modification with non-genuine Lexus products
could af
fect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance pro blems resulting from the modification may not
be covered under warranty.
Spark ignition system of your Lexus
The spark ignition system in your Lexus meets all
requirements of the Canadian Interference-Causing
Equipment Standard.
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti-lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Tires and loading on your Lexus
Underinflated or overinflated tire pressure and the
excess load may result in the deterioration of steering
ability and braking ability, leading to an accident. Check
the tire inflation pressure periodically and be sure to
keep the load limits given in this Owner's Manual. For
details about tire inflation pressure and load limits, see
pages 349 and 274.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.
03 07.09

8.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
viii
Page
1Power door lock switch and power window switches 22, 37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Power rear view mirror control switches 181 . . . . . .
3Rear fog light switch 33
. . . . . . . . . . . . . . . . . . . . . . . . .
4Headlight cleaner switch 36
. . . . . . . . . . . . . . . . . . . . .
5Driving position memory switches 176
. . . . . . . . . . .
6Headlight, turn signal and fog light
switches 30, 32, 33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Transmission shift switches 242
. . . . . . . . . . . . . . . . .
8Instrument panel light control 58
. . . . . . . . . . . . . . . . .
9Cruise control switch 249
. . . . . . . . . . . . . . . . . . . . . . .
10Wiper and washer switches 34
. . . . . . . . . . . . . . . . . . .
11Ignition switch 235
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Emergency flasher switch 40
. . . . . . . . . . . . . . . . . . . .
13Auxiliary box 73
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14Outside temperature display/Clock 63
. . . . . . . . . . . . Page
15Front passenger's seat belt reminder light 51
. . . . .
16Automatic air conditioning controls 190
. . . . . . . . . .
17Car audio 204
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Seat heater switches 40
. . . . . . . . . . . . . . . . . . . . . . . . .
19Glove box 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Parking brake lever 236
. . . . . . . . . . . . . . . . . . . . . . . . .
21Driving pattern selector switch
(Automatic transmission) 238 . . . . . . . . . . . . . . . . . . . .
22Ashtray 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
23Cigarette lighter 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24Automatic transmission selector lever/
Manual transmission gear shift lever 238, 247 . . . . .
25Traction control system off/Snow mode
switch (Manual transmission) 252, 255 . . . . . . . . . . . .
26Hood lock release lever 86
. . . . . . . . . . . . . . . . . . . . . .
03 07.09

10.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
x
Page
1Driver's seat belt reminder light51
. . . . . . . . . . . . . . .
2Open door warning light 55
. . . . . . . . . . . . . . . . . . . . . .
3Tachometer 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Headlight high beam indicator light 32
. . . . . . . . . . .
5Low engine oil level warning light 53
. . . . . . . . . . . . .
6Vehicle stability control system
warning light 56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Turn signal indicator lights 32
. . . . . . . . . . . . . . . . . . .
8Cruise control indicator light 249
. . . . . . . . . . . . . . . .
9Momentary fuel consumption meter 46
. . . . . . . . . . .
10Voltmeter 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
11Automatic headlight leveling system warning
light 56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
12Engine coolant temperature gauge 45
. . . . . . . . . . . .
13Anti-lock brake system warning light 54
. . . . . . . . . .
14Malfunction indicator lamp 54
. . . . . . . . . . . . . . . . . . .
15Fuel gauge 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16Low fuel level warning light 55
. . . . . . . . . . . . . . . . . . . Page
17Odometer and trip meter
48
. . . . . . . . . . . . . . . . . . . . .
18Power mode indicator light 240
. . . . . . . . . . . . . . . . . .
19Snow mode indicator light 240
. . . . . . . . . . . . . . . . . . .
20ODO/TRIP knob 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Automatic transmission indicator lights 238 . . . . . .
22M mode indicator 241
. . . . . . . . . . . . . . . . . . . . . . . . . . .
23Gear position indicator for manual control 241 . . . .
24Discharge warning light 52
. . . . . . . . . . . . . . . . . . . . . .
25Rear light failure warning light 55
. . . . . . . . . . . . . . . .
26Security indicator light 27
. . . . . . . . . . . . . . . . . . . . . . .
27Traction control system
off indicator/warning light 55 . . . . . . . . . . . . . . . . . . . .
28Low engine oil pressure warning light 52
. . . . . . . . .
29Slip indicator light 252, 255, 258
. . . . . . . . . . . . . . . . . .
30Brake system warning light 50
. . . . . . . . . . . . . . . . . . .
31SRS warning light 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Engine oil replacement reminder light 53
. . . . . . . . .
03 07.09

12.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xii
Page
1Tachometer47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Headlight high beam indicator light 32
. . . . . . . . . . .
3Low engine oil level warning light 53
. . . . . . . . . . . . .
4Vehicle stability control system warning light 56 . .
5Turn signal indicator lights 32
. . . . . . . . . . . . . . . . . . .
6Cruise control indicator light 249
. . . . . . . . . . . . . . . .
7Momentary fuel consumption meter 46
. . . . . . . . . . .
8Voltmeter 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
9Automatic headlight leveling system warning
light 56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
10Engine coolant temperature gauge 45
. . . . . . . . . . . .
11Anti-lock brake system warning light 54
. . . . . . . . . .
12Malfunction indicator lamp 54
. . . . . . . . . . . . . . . . . . .
13Fuel gauge 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14Low fuel level warning light 55
. . . . . . . . . . . . . . . . . . .
15Odometer and trip meter 48
. . . . . . . . . . . . . . . . . . . . .
16Power mode indicator light 240
. . . . . . . . . . . . . . . . . . Page
17Snow mode indicator light
240
. . . . . . . . . . . . . . . . . . .
18ODO/TRIP knob 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Automatic transmission indicator lights 238 . . . . . .
20M mode indicator 241
. . . . . . . . . . . . . . . . . . . . . . . . . . .
21Gear position indicator for manual control 241 . . . .
22Discharge warning light 52
. . . . . . . . . . . . . . . . . . . . . .
23Rear light failure warning light 55
. . . . . . . . . . . . . . . .
24Security indicator light 27
. . . . . . . . . . . . . . . . . . . . . . .
25Traction control system
off indicator/warning light 55 . . . . . . . . . . . . . . . . . . . .
26Low engine oil pressure warning light 52
. . . . . . . . .
27Slip indicator light 252, 255, 258
. . . . . . . . . . . . . . . . .
28Brake system warning light 50
. . . . . . . . . . . . . . . . . . .
29SRS warning light 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Open door warning light 55
. . . . . . . . . . . . . . . . . . . . . .
31Driver's seat belt reminder light 51
. . . . . . . . . . . . . . .
03 07.09

OPERATION OF SELECTOR LEVER
SELECTOR LEVER POSITION
P: Parking, engine starting and key removal position
R: Reverse position
N: Neutral position
D: Normal driving position (Shifting into overdrive
possible)
M: Position for manual shifting up or downshifting
(Shifting into overdrive possible)*
3, 2: Position for more powerful engine braking
L: Position for maximum engine braking
SVBA009
Shift while pressing the brake pedal. (Ignition
switch must be in the ºONº position.)
*:When the cruise control is being used, even if you downshift from º5º to º4º\
, engine braking will not be enabled because
the cruise control is not cancelled. For the operation to decrease the \
vehicle speed, see page 251.
SV31020
QUICK REFERENCE
4
3. AUTOMATIC TRANSMISSION
03 07.09

SECTION 3 - 1
231
STARTING AND DRIVING
Starting and driving
Three-way catalytic converter232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . .
Engine exhaust caution 233
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine 234
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . .
Ignition switch with steering lock 235
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .
Parking brake 236
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 237
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 238
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission 247
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronic controlled transmission 248
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Cruise control 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction control system 252
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Vehicle stability control system 258
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . .
Electronic throttle control system 260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . .
Brake system 261
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear indicators 265
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . Limited -slip differential
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . 265
03 07.09

STARTING AND DRIVING
238
AUTOMATIC TRANSMISSION
Your automatic transmission has a shift lock system to
minimize the possibility of incorrect operation. This
means you can only shift out of ºPº position when the
brake pedal is depressed with the ignition switch in ºONº
position. ()
SV31020

The shift position is displayed on the instrument
cluster.
P: Parking, engine starting and key removal position
R: Reverse position
N: Neutral position
D: Normal driving position (Shifting into overdrive
possible)
M: Position for manual shifting up or downshifting
When the cruise control is being used, even if you
downshift from º5º to º4º, engine braking will not be
enabled because the cruise control is not cancelled. For
the operation to decrease the vehicle speed, see page 251.
3, 2: Position for more powerful engine braking
L: Position for maximum engine braking
03 07.09

STARTING AND DRIVING
243
Warning tone sounds twice in any of the following cases:

You attempt to downshift the transmission when it is not
possible to downshift due to the high vehicle speed.
 You attempt to downshift from º2º position.
 You attempt to upshift from º5º position.
If the ºMº indicator flashes, there is a problem somewhere
in the system. In this case, it should be noted that you
cannot downshift or upshift the transmission using the
switches on the steering wheel. Consult with your Lexus
dealer as soon as possible. The transmission works
exactly in the same way as when you put the selector lever
in the ºDº position.
CAUTION
Be careful when downshifting on a slippery surface.
The abrupt change in engine speed could cause the
vehicle to spin or skid.
(c) Using engine braking
SV31023
To use the braking power of the engine, downshift the
transmission in the way described below:
1Shift into the ºMº position, and you push the transmission
down shift switch. The transmission will downshift to
fourth gear and engine braking will be obtained. This is
effective only when you are driving in the ºDº position or
in fifth gear (ºMº position).
When the cruise control is being used, even if you
downshift from º5º to º4º, engine braking will not be
enabled because the cruise control is not cancelled. If
you need to decrease the vehicle speed, see page 251.
2Shift into the º3º position. The transmission will downshift
to third gear when the vehicle speed is or becomes lower
than the speed listed below and stronger engine braking
will be obtained.
03 07.09

STARTING AND DRIVING
249
CRUISE CONTROL
The cruise control allows you to cruise the vehicle at a
desired speed over 40 km/h (25 mph) with your foot off the
accelerator pedal.
Your cruising speed can be maintained although a slight speed
change may occur when driving up or down a gradient, within
the limits of engine performance. On steeper hills, a great
speed change will occur so it is better to drive without the cruise
control.
When the cruise control is on, the driving pattern of the
automatic transmission is fixed in the normal position,
regardless of the position of the selector switch.
CAUTION
 To help maintain maximum control of your vehicle,
do not use the cruise control when driving in heavy
or varying traffic, or on slippery (rainy, icy or
snow-covered) or winding roads.
 Avoid vehicle speed increases when driving
downhill. If the vehicle speed is too fast in relation to
the cruise control set speed, cancel the cruise
control then downshift the transmission to use
engine braking to slow down.
Turning the system on
SV31029
To operate the cruise control, push the main switch. This turns
the system on. The indicator light in the instrument cluster
shows that you can now set your desired cruising speed.
Another push on the switch will turn the system completely off.
When the ignition key is turned off, the main switch is also
automatically turned off. To use the cruise control again, push
the main switch again to turn it on.
CAUTION
To avoid accidental cruise control engagement, keep
the main switch off when not using the cruise control.
03 07.09

STARTING AND DRIVING
250
Setting operation
SV31030

Each function is described below.
1Setting at a desired speed.
Automatic transmission: The transmission must be in the
ºDº position or the gear position must be º4º or º5º in M mode
before you set the cruise control speed.
Bring the vehicle to the desired speed, press the control lever
downward in the ºSET/COASTº direction and release it. This
sets the vehicle at that speed. Now you may take your foot off
the accelerator pedal. If you need acceleration - for example,
when passing - depress the accelerator pedal enough for the
vehicle to exceed the set speed. When you release the
accelerator pedal, the vehicle will return to the speed set prior
to the acceleration.
2Cancelling the preset speed
You can cancel the preset speed by either of the following:
a. Pulling the control lever in the ºCANCELº direction.
b. Depressing the brake pedal.
c. Depressing the clutch pedal (manual transmission)
If the vehicle speed falls below about 40 km/h (25 mph), the
preset speed will be automatically cancelled.
If the vehicle speed drops 16 km/h (10 mph) below the preset
speed, the preset speed will also automatically be cancelled.
If the preset speed automatically cancels out for other than
these reasons, have your vehicle checked by your Lexus
dealer at the earliest opportunity.
3Resetting to a faster speed
Press the control lever upward in the ºRES/ACCº direction and
hold it. Release the lever when the desired speed is attained.
While the lever is held upward, the vehicle will gradually gain
speed.
When the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
increased 1.6 km/h (1 mph) each time by pressing the control
lever upward in the ºRES/ACCº direction quickly within 0.6
seconds.
However, a quicker way to reset is to accelerate the vehicle
and then press the control lever downward in the
ºSET/COASTº direction.
03 07.09
