STARTING AND DRIVING
246
(g) Good driving practice
If the transmission repeatedly shifts up and down between the
fourth and overdrive gears when climbing a gentle slope, shift
the selector lever to the ªMº position and select the fourth gear
by pushing the transmission switch. Be sure to shift the
selector lever to the ªDº position after climbing the slope.
CAUTION
Always keep your foot on the brake pedal while stopped
with the engine running. This prevents the vehicle from
creeping.
NOTICE
Always use the brake pedal or the parking brake to hold
the vehicle on an upgrade. Do not attempt to hold the vehicle using the accelerator pedal, as this can causethe transmission to overheat.
(h) If you cannot shift the selector
If you cannot shift the selector lever even though the brake
pedal is depressed, use the shift lock override button. For
instructions, see ªIf you cannot shift automatic transmission
selector leverº on page 304.
(i) If the ªECT PWRº indicator light flashes
If the ªECT PWRº indicator light flashes, contact your Lexus
dealer as soon as possible. There may be trouble in the
transmission system.
04 06.30

STARTING AND DRIVING
247
MANUAL TRANSMISSION
SV31034
The shift pattern is the conventional pattern shown above.
CAUTION
The shift lever knob can become extremely hot after
parking under the sun.
Press the clutch pedal down fully while shifting, and then
release it slowly. Do not rest your foot on the pedal while
driving, because it will cause clutch trouble. Do not use the
clutch to hold the vehicle when stopped on an uphill grade ±
use the parking brake.
Upshifting too soon or downshifting too late will cause lugging,
and possibly pinging. Regularly revving the engine to
maximum speed in each gear will cause excessive engine
wear and high fuel consumption.Recommended shifting speeds
The transmission is fully synchronized and upshifting or
downshifting is easy.
For the best compromise between fuel economy and vehicle
performance, you should upshift or downshift at the following
speeds:
gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64 (40)
4 to 5 or 5 to 4 72 (45)
Downshift to the appropriate gear if acceleration is needed
when you are cruising below the above downshifting speeds.
Upshifting too soon or downshifting too late will cause lugging,
and possibly pinging. Regularly revving the engine to
maximum speed in each gear will cause excessive engine
wear and high fuel consumption.
Maximum allowable speeds
To get on a highway or to pass slower traffic, maximum
acceleration may be necessary. Make sure you observe the
following maximum allowable speeds in each gear: gear km/h (mph)1 56 (35)
2 98 (61)
3 145 (91)
04 06.30

STARTING AND DRIVING
248
NOTICE
Do not downshift if you are going faster than the maxi-mum allowable speed for the next lower gear.
Good driving practice
 If it is difficult to shift into reverse, put the transmission in
neutral, release the clutch pedal momentarily, and then try again.
 When towing a trailer, in order to maintain engine braking
efficiency, do not use fifth gear.
CAUTION
Be careful when downshifting on a slippery surface.
Abrupt shifting could cause the vehicle to skid or spin.
NOTICE
Make sure the vehicle is completely stopped before
shifting into reverse.
ELECTRONIC CONTROLLED TRANSMISSION
(Vehicle with automatic transmission only)
SV31039

1Power position 2Normal position
The electronic controlled system has 2 modes: Normal
and Power modes.
Normal mode: For ordinary driving, Lexus recommends that
you use the normal mode to improve fuel economy.
Power mode: For more powerful acceleration and sporty
driving.
In the power mode, the ªECT PWRº light in the instrument
cluster is on and the transmission is shifted up at higher vehicle
speeds and shifted down more responsively than in the normal
mode.
04 06.30

STARTING AND DRIVING
261
BRAKE SYSTEM
The tandem master cylinder brake system is a hydraulic
system with two separate sub±systems. If either sub±system
should fail, the other will still work. However, the pedal will be
harder to press, and your stopping distance will increase. Also,
the brake system warning light may come on.
CAUTION
Do not drive your vehicle with only a single brake
system. Have your brakes fixed immediately.
Brake booster
The brake booster uses engine vacuum to power±assist the
brakes. If the engine should quit while you are driving, you can
bring the vehicle to a stop with normal pedal pressure. There
is enough reserved vacuum for one or two stops but no more!
CAUTION
Do not pump the brake pedal if the engine stalls. Each
push on the pedal uses up your reserved vacuum.
 Even if the power assist is completely lost, the brakes
will still work. But you will have to push the pedal
hard, much harder than normal. And your braking
distance will increase.
Anti±lock brake system
The anti±lock brake system is designed to automatically
help prevent lock±up of the wheels during a sudden
braking or braking on slippery road surfaces. This assists
in providing directional stability and steering
performance of the vehicle under these circumstances.
Effective way to press the ABS brake pedal: When the
anti±lock brake system function is in action, you may feel the
brake pedal pulsating and hear a noise. In this situation, to
let the anti±lock brake system work for you, just hold the
brake pedal down more firmly. Do not pump the brake in a
panic stop. This will result in reduced braking performance.
The anti±lock brake system becomes operative after the
vehicle has accelerated to a speed in excess of approximately
10 km/h (6 mph). It stops operating when the vehicle
decelerates to a speed below approximately 5 km/h (3 mph).
Depressing the brake pedal on slippery road surfaces such as
on a manhole cover, a steel plate at a construction site, joints
in a bridge, etc. on a rainy day tends to activate the anti±lock
brake system.
You may hear a click or motor sound in the engine
compartment for a few seconds when the engine is started or
just after the vehicle begins to move. This means that the
anti±lock brake system is in the self±check mode, and does not
indicate a malfunction.
When the anti±lock brake system is activated, the
following conditions may occur. They do not indicate a
malfunction of the system:
04 06.30

STARTING AND DRIVING
262
You may hear the anti±lock brake system operating and feel
the brake pedal pulsating and the vibrations of the vehicle
body and steering wheel. You may also hear the motor
sound in the engine compartment even after the vehicle is stopped.
 At the end of the anti±lock brake system activation, the
brake pedal may move a little forward.
CAUTION
Do not overestimate the anti±lock brake system:
Although the anti±lock brake system assists in
providing vehicle control, it is still important to drive
with all due care and maintain a moderate speed and
safe distance from the vehicle in front of you, because
there are limits to the vehicle stability and effectiveness
of steering wheel operation even with the anti±lock
brake system on.
If tire grip performance exceeds its capability, or if
hydroplaning occurs during high speed driving in the
rain, the anti±lock brake system does not provide
vehicle control.
Anti±lock brake system is not designed to shorten the
stopping distance: Always drive at a moderate speed
and maintain a safe distance from the vehicle in front of
you. Compared with vehicles without an anti±lock brake
system, your vehicle may require a longer stopping
distance in the following cases:
 Driving on rough, gravel or snow±covered roads.
 Driving with tire chains installed.
 Driving over the steps such as the joints on the road.
 Driving on roads where the road surface is pitted or
has other differences in surface height.
Install all 4 tires of specified size at appropriate
pressure: The anti±lock brake system detects vehicle
speeds using the speed sensors for respective wheels'
turning speeds. The use of tires other than specified
may fail to detect the accurate turning speed resulting
in a longer stopping distance.
04 06.30

STARTING AND DRIVING
264
CAUTION
If the ªABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti±lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Drum±in±disc type parking brake system
Your vehicle has a drum±in±disc type parking brake system.
This type of brake system needs bedding±down of the brake
shoes periodically or whenever the parking brake shoes
and/or drums are replaced.
Have your Lexus dealer perform the bedding±down.
Brake assist system
When you slam the brakes on, the brake assist system
judges as an emergency stop and provides more powerful
braking for a driver who cannot hold down the brake pedal
firmly.
When you slam the brakes on, more powerful braking will be
applied. At this time, you may hear a sound in the engine
compartment and feel the vibrations of the brake pedal. This
does not indicate a malfunction.
The brake assist system becomes operative after the vehicle
has accelerated to a speed in excess of approximately 10 km/h
(6 mph). It stops operating when the vehicle decelerates to a
speed below approximately 5 km/h (3 mph).For an explanation of this system's warning light, see ªABSº
warning light on page 54 or 263.
04 06.30

STARTING AND DRIVING
265
BRAKE PAD WEAR INDICATORS
SS31030
The brake pad wear limit indicators on your disc brakes
give a warning noise when the brake pads are worn to the
extent that replacement is required.
If you hear a squealing or scraping noise while driving, have
the brake pads checked and replaced by your nearest Lexus
dealer immediately.
Avoid continuous driving with the warning noise.
Continuous driving without replacing the brake pads will cause
expensive rotor damage and increasing brake pedal effort to
get the same stopping distance.
LIMITED±SLIP DIFFERENTIAL
Some vehicles are equipped with a limited±slip differential. If
one rear wheel begins to spin, the limited±slip differential is
designed to aid traction by automatically transmitting driving
force to the other rear wheel. If you are not sure whether your
vehicle is equipped with one, you can ask your Lexus dealer.
CAUTION
Do not start or run the engine while your vehicle is
supported by a jack. The vehicle could be driven off the
jack and could pose a danger or result in serious injury.
NOTICE
Use only a spare tire of the same size, construction and
load capacity as the original tires on your Lexusbecause damage to the limited±slip differential couldpossibly occur with another tire type.
04 06.30

DRIVING TIPS
268
BREAK±IN PERIOD
Drive gently and avoid high speeds.
You need not follow a break±in schedule with your new Lexus.
But following a few simple tips for the first 1600 km (1000 miles)
can add to the future economy and long life of your vehicle:
Avoid full throttle acceleration when starting and driving.
 Avoid racing the engine.
 Try to avoid hard stops during the first 300 km (200 miles).
 Do not drive slowly with the manual transmission in a high
gear.
 Do not drive for a long time at any single speed, either fast
or slow.
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).
04 06.30

DRIVING TIPS
270
Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.WINTER DRIVING TIPS
Make sure your coolant is properly protected against
freezing.
Only use ªToyota Super Long Life Coolantº or similar high
quality ethylene glycol based non±silicate, non±amine,
non±nitrite, and non±borate coolant with long±life hybrid
organic acid technology. (Coolant with long±life hybrid organic
acid technology is a combination of low phosphates and
organic acids.)
See ªChecking the engine coolant levelº on page 337 for
details of coolant type selection.
For the U.S.A.ЪToyota Super Long Life Coolantº is a mixture
of 50% coolant and 50% deionized water. This coolant
provides protection down to about ±35 C (±31F).
For CanadaЪToyota Super Long Life Coolantº is a mixture of
55% coolant and 45% deionized water. This coolant provides
protection down to about ±42 C (±44F).
NOTICE
Do not use plain water alone.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 380 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
04 06.30

DRIVING TIPS
271
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 335 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer ± they will be pleased to help.
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de±icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle's paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into ªPº (automatic) or into
first or reverse (manual) and block the front wheels. Do not use
the parking brake, or snow or water accumulated in and around
the parking brake mechanism may freeze the parking brake,
making it hard to release. Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of
the things you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.
04 06.30
