STARTING AND DRIVING
256
Normal driving mode
SV31037

Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the traction control system is in the self±check mode, but does
not indicate a malfunction.
When the traction control system is operating, the following
conditions occur:
 The system controls the spinning of the rear wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is functioning properly. The slip indicator light comes on for a few seconds when the
ignition key is turned to ªONº. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
04 06.30

STARTING AND DRIVING
257
Traction control off mode
SV31036
If your wheels get stuck in a ditch when you are driving on
a severe off road and sand, turn off the traction control
system. This system that controls engine performance
interferes with the process of freeing your wheels.
To turn off: Push ªTRAC OFFº switch.
The ªTRAC OFFº indicator/warning light will come on.
To turn on: Push ªTRAC OFFº switch once again.
The ªTRAC OFFº indicator/warning light will go off.
SV31043
ªTRAC OFFº indicator/warning light
This light also warns that there is a problem somewhere in the
traction control system.
The light will come on when the ignition key is turned to ªONº
and will go off after a few seconds. It will come on again when
you push the ªTRAC OFFº switch to turn off the system.
If the light comes on with the normal driving mode while driving,
the system does not work. However, as conventional braking
operates when the brake is applied, there is no problem to
continue your driving.
In the following cases, contact your Lexus dealer:
The light does not come on when the ignition key is turned
to ªONº
 The light remains on after the ignition is turned on.
 The light comes on with the normal driving mode while
driving.
 The light flashes.
04 06.30

STARTING AND DRIVING
258
VEHICLE STABILITY CONTROLSYSTEM
The vehicle stability control system helps provide
comprehensive control of the systems such as anti±lock
brake system, traction control, engine control, etc. This
system automatically controls the brakes and engine to
help prevent the vehicle from skidding when cornering on
a slippery road surface or operating steering wheel
abruptly.
This system activates when the vehicle speed is about more
than 15 km/h (9 mph).
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the system is in the self±check mode, but does not indicate a
malfunction.
CAUTION
 Do not rely excessively on the vehicle stability
control system. Even if the vehicle stability control
system is operating, you must always drive carefully
and attentively to avoid serious injury. Reckless
driving will result in an unexpected accident. If the
slip indicator light blinks, sounding an alarm, special
care should be taken while driving.
 Only use tires of specified size. The size,
manufacture, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle
stability control system may not function correctly.
When replacing the tires or wheels, contact your
Lexus dealer.
 In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.
04 06.30

STARTING AND DRIVING
259
SV31037

Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving.
The slip indicator light comes on for a few seconds when the
ignition key is turned to ªONº. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
ªVSCº warning light
SV31042
This light warns that there is a problem somewhere in the
vehicle stability control system or traction control system.
The light will come on when the ignition key is turned to ªONº
and will go off after a few seconds.
If the light comes on while driving, the vehicle stability control
system and traction control system do not work. However, as
conventional braking operates when the brake is applied, there
is no problem to continue your driving.
04 06.30

STARTING AND DRIVING
263
ªABSº warning light
SV31014

U.S.A.
SV31031

CANADA
The light comes on when the ignition key is turned to the ªONº
position. If the anti±lock brake system and the brake assist
work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the ªABSº warning light is on (and the brake system
warning light is off), the anti±lock brake system, the brake
assist system, the traction control system and/or the vehicle
stability control system do not operate, but the brake system
still operates conventionally.
When the ªABSº warning light is on (and the brake system
warning light is off), the anti±lock brake system and/or the
traction
control system do/does not operate so that the wheels
could lock up during a sudden braking or braking on slippery
road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on when the ignition key is turned
to the ªONº position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
04 06.30

IN CASE OF AN EMERGENCY
298
IF YOUR VEHICLE BECOMESSTUCK
If your vehicle becomes stuck in snow, mud, sand, etc.,
then you may attempt to rock the vehicle free by moving
it forward and backward.
Your vehicle is equipped with the traction control system,
turn off the system to become unstuck to allow the tires
to spin enough to remove the vehicle from the
obstruction. (For details, see ªTraction control systemº
on page 252 or 255.)
CAUTION
Do not attempt to rock the vehicle free by moving it
forward and backward if people or objects are anywhere
near the vehicle. During the rocking operation the
vehicle may suddenly move forward or backward as it
becomes unstuck, causing injury or damage to nearby
people or objects.
NOTICE
If you rock your vehicle, observe the following precautions to prevent damage to the transmission and
other parts.
Do not depress the accelerator pedal while shifting the selector lever or before the transmission iscompletely shifted to forward or reverse gear.
Do not race the engine and avoid spinning thewheels.
If your vehicle remains stuck after rocking the vehicleseveral times, consider other ways such as towing.
04 06.30

CHASSIS
360
Name of each section of tire
SV63016

1Bead
2Sidewall
3Shoulder
4Tread
5Belt
6Inner liner
7Reinforcing rubber
8Carcass
9Rim lines
10Bead wires
11Chafer
Uniform tire quality grading
This information has been prepared in accordance
with regulations issued by the National Highway
Traffic Safety Administration of the U.S. Department
of Transportation. It provides the purchasers and/or
prospective purchasers of Lexus vehicles with
information on uniform tire quality grading.
Your Lexus dealer will help answer any questions
you may have as you read this information.
DOT quality grades ± All passenger vehicle tires
must conform to Federal Safety Requirements in
addition to these grades. Quality grades can be
found where applicable on the tire sidewall between
tread shoulder and maximum section width. For
example: T readwear 200 Traction AA Temperature A
Tread wear ± The treadwear grade is a comparative
rating based on the wear rate of the tire when tested
under controlled conditions on a specified government
test course. For example, a tire graded 150 would wear
one and a half (1 ± 1/2) times as well on the government
course as a tire graded 100. The relative performance
of tires depends upon the actual conditions of their use,
however, and may depart significantly from the norm
due to variations in driving habits, service practices and
differences in road characteristics and climate.
04 06.30

CHASSIS
361
Traction AA, A, B, C ± The traction grades, from highest
to lowest, are AA, A, B and C, and they represent the
tire's ability to stop on wet pavement as measured under
controlled conditions on specified government test
surfaces of asphalt and concrete. A tire marked C may
have poor traction performance.
Warning: The traction grade assigned to this tire is
based on braking (straight ahead) traction tests and
does not include cornering (turning) traction.
Temperature A, B, C ± The temperature grades are A
(the highest), B, and C, representing the tire's resistance
to the generation of heat and its ability to dissipate heat
when tested under controlled conditions on a specified
indoor laboratory test wheel. Sustained high
temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive
temperature can lead to sudden tire failure. The grade
C corresponds to a level of performance which all
passenger car tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades B and A
represent higher levels of performance on the laboratory
test wheel than the minimum required by law.
Warning: The temperature grades for this tire are
established for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in combination,
can cause heat buildup and possible tire failure.
04 06.30

CHASSIS
365
TYPES OF TIRES
Determine what kind of tires your vehicle is originally
equipped with.
1. Summer tires
Summer tires are high±speed capability tires best suited
to highway driving under dry conditions.
Since summer tires do not have the same traction
performance as snow tires, summer tires are
inadequate for driving on snow±covered or icy roads.
For driving on snow±covered or icy roads, we
recommend using snow tires. If installing snow tires, be
sure to replace all four tires.
2. All season tires
All season tires are designed to provide better traction
in snow and to be adequate for driving in most winter
conditions, as well as for use all year round.
All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose
snow. Also, all season tires fall short in acceleration and
handling performance compared with summer tires in
highway driving.
The details about how to distinguish summer tires from
all season tires are described on page 354.
CAUTION
 Do not mix summer and all season tires on your
vehicle as this can cause dangerous handling
characteristics, resulting in loss of control.
 Do not use tires other than the manufacturer's
designated tires, and never mix tires or wheels
of the sizes different from the originals as this
can cause dangerous handling characteristics,
resulting in loss of control.
04 06.30

CHASSIS
370
CAUTION
Observe the following instructions. Otherwise, an
accident may occur resulting in death or serious
injuries.
Do not mix radial, bias belted, or bias±ply tires
on your vehicle, as this may cause dangerous
handling characteristics resulting in loss of
control.
 Do not use tires other than the manufacturer's
recommended size, as this may cause
dangerous handling characteristics resulting in
loss of control.
If you need to change from conventional tires to radial
tires or vice versa, replace them as a set.
INSTALLING SNOW TIRES AND
CHAINS
When to use snow tires or chains
Snow tires or chains are recommended when driving on
snow or ice.
On wet or dry roads, conventional or radial tires provide better
traction than snow or studded tires.
Snow tire selection
If you need snow tires, select tires of the same size,
construction and load capacity as the originally installed
tires.
Do not use tires other than stated above. Since your vehicle
has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires
without first checking local regulations for possible restrictions.
CAUTION
Observe the following instructions. Otherwise, an
accident may occur resulting in death or serious
injuries.
Do not use snow tires other than the manufacturer's
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
04 06.30
