For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xi
Page
1Power door lock switch and power window switches 22, 37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Power rear view mirror control switches 181 . . . . . .
3Rear fog light switch 33
. . . . . . . . . . . . . . . . . . . . . . . . .
4Headlight cleaner switch 36
. . . . . . . . . . . . . . . . . . . . .
5Driving position memory switches 176
. . . . . . . . . . .
6Headlight, turn signal and fog light
switches 30, 32, 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Transmission shift switches 242
. . . . . . . . . . . . . . . . .
8Instrument panel light control 58
. . . . . . . . . . . . . . . . .
9Cruise control switch 249
. . . . . . . . . . . . . . . . . . . . . . .
10Wiper and washer switches 34
. . . . . . . . . . . . . . . . . . .
11Ignition switch 235
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Emergency flasher switch 40
. . . . . . . . . . . . . . . . . . . .
13Auxiliary box /Navigation system
(See ªNavigation System Owner's Manualº) 72 . . . .
14Outside temperature display/Clock 62
. . . . . . . . . . . . Page
15Front passenger's seat belt reminder light 51
. . . . .
16Automatic air conditioning controls 190
. . . . . . . . . .
17Audio system 204
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Seat heater switches 40
. . . . . . . . . . . . . . . . . . . . . . . . .
19Glove box 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Parking brake lever 236
. . . . . . . . . . . . . . . . . . . . . . . . .
21Driving pattern selector switch
(Automatic transmission) 238 . . . . . . . . . . . . . . . . . . . .
22Ashtray 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
23Cigarette lighter 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24Automatic transmission selector lever/
Manual transmission gear shift lever 238, 247 . . . . .
25Traction control system off/Snow mode
switch (Manual transmission) 252, 255
. . . . . . . . . . . .
26Hood lock release lever 86
. . . . . . . . . . . . . . . . . . . . . .
04 06.30

OPERATION OF SELECTOR LEVER
SELECTOR LEVER POSITION
P: Parking, engine starting and key removal position
R: Reverse position
N: Neutral position
D: Normal driving position (Shifting into overdrive
possible)
M: Position for manual shifting up or downshifting
(Shifting into overdrive possible)*
3, 2: Position for more powerful engine braking
L: Position for maximum engine braking
SVBA009
Shift while pressing the brake pedal. (Ignition
switch must be in the ªONº position.)
*:When the cruise control is being used, even if you downshift from ª5º to ª4º\
, engine braking will not be enabled because
the cruise control is not cancelled. For the operation to decrease the v\
ehicle speed, see page 251.
SV31020
QUICK REFERENCE
4
3. AUTOMATIC TRANSMISSION
04 06.30

QUICK REFERENCE
5
4. HEADLIGHT AND TURN SIGNALSWITCH
SVBA013
SVBA013

HEADLIGHT SWITCHWith the ignition OFF
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Automatic light control
Headlights also turn on.
With the engine started and parking brake
released Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on
at full intensity.
Automatic light control
SVBA014
SSBA011b
Right or left turn
Lane change
(Right or left) High beam
Headlight flasher

TURN SIGNAL SWITCH
04 06.30

SWITCHES
31
Daytime Running Light System
The headlights turn on at reduced intensity when the parking
brake is released with the engine started, even with the light
switch in the ªOFFº position. They will not go off until the ignition
switch is turned off.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Twist
the knob to the second clickstop to turn on the headlights
to full intensity for driving at night.
When setting the knob to the third clickstop (ªAUTOº), the
headlights will automatically adjust to full intensity and/or turn
on the other lights depending on the darkness of the
surroundings. Likewise, as the surroundings become brighter,
the headlights will turn to reduced intensity, ultimately turning
off the other lights.
NOTICE
To prevent the battery from being discharged, do not leave the lights on longer than necessary when theengine is not running.
Automatic headlight leveling system
SV12022
The headlight beam level is always maintained automatically
at the proper level in all loading conditions so that your
headlights do not dazzle other road users.
If this system fails, the warning light in the instrument cluster
comes on. If this occurs, have your vehicle checked by Lexus
dealer.
04 06.30

GAUGES, METERS AND SERVICE REMINDER INDICATORS
48
ODOMETER AND TRIP METER
SV13015
This meter displays the odometer and two trip meters. To
change the mode indication, push the ªODO/TRIPº knob
briefly. Each time you push the knob, the mode changes
in order from the odometer to trip meter A to trip meter B,
then back to the odometer, etc.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To set A trip meter to zero, display the A meter reading,
push the knob and hold it. The same applies for the B trip
meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORSAND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)or
(Indicator and buzzer)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver's seat
belt
(c)Fasten front
passenger's seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)Stop and check.
04 06.30

GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the ªONº position.
 When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
turned to the ªONº position even after the parking brake is
released.
If you drive your vehicle without releasing the parking brake,
the buzzer sounds.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
Have your vehicle checked at your Lexus dealer in the
following cases:
The light does not come on even if the parking brake is
applied when the ignition key is in the ªONº position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If either of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
In the case, the brakes may not work properly and
your stopping distance will become longer. Depress
the brake pedal firmly and bring the vehicle to an
immediate stop.
 The brake system warning light remains on together
with the ªABSº warning light.
In this case, not only the anti±lock brake system will
fail but also the vehicle will become extremely
unstable during braking.
04 06.30

GAUGES, METERS AND SERVICE REMINDER INDICATORS
57
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Turn the ignition key to ªACCº.
The following service reminder indicator should come on. It
goes off after about 6 seconds.
4. Turn the ignition key to ªONº.
The following service reminder indicators should come on.


or
or

or
The following service reminder indicators go off after a few
seconds.
or

The lights other than the slip indicator light may stay on for
about 60 seconds after the engine is started. It is normal if they
go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.
04 06.30

OCCUPANT RESTRAINT SYSTEMS
176
CAUTION
When using the lower anchorages for the child
restraint system, be sure that there are no irregular
objects around the anchorages or that the seat belt is
not caught.
 Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its
manufacturer.
 Do not install a child restraint system on the rear seat
if it interferes with the lock mechanism of the front
seats. This can cause death or serious injury to the
child and front passenger in case of sudden braking
or a collision.
DRIVING POSITION MEMORY
SYSTEM
The microcomputer can memorize the positions of the driver's
seat. Two different driving position profiles can be entered into
the computer's memory.
Automatic transmission: Recording a driving position in the
computer's memory can only be done when the ignition key is
in the ªONº position and the selector lever is in the ªPº posi\
tion.
Manual transmission: Recording a driving position in the
computer's memory can only be done when the ignition key is
in the ªONº position and the parking brake is applied.
04 06.30

OCCUPANT RESTRAINT SYSTEMS
177
Setting the driving position
SV16170
1. Adjust the driver's seat to the desired position.
2. While pushing the ªSETº button, push button ª1º or ª2º
until the signal beeps.
The beep sound means that the positions are recorded in the
computer's memory.
By repeating these two steps and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
SV16171
Automatic transmissionÐ
When you push button ª1º or ª2º, the driving position will
be automatically adjusted to the position recorded for
that button.
Manual transmissionÐ
While button ª1º or ª2º is being pushed down, the driving
position will be automatically adjusted to the position
recorded for that button.
Conditions for memorized position activation
 Automatic transmission: Ignition key ªONº and selector
lever in ªPº position.
 Manual transmission: Ignition key ªONº and apply the
parking brake.
 Ignition switch off and within 30 seconds of opening driver's
door.
04 06.30

SECTION 3 ± 1
231
STARTING AND DRIVING
Starting and driving
Three±way catalytic converter232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . .
Engine exhaust caution 233
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine 234
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . .
Ignition switch with steering lock 235
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .
Parking brake 236
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 237
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 238
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission 247
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronic controlled transmission 248
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Cruise control 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction control system 252
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Vehicle stability control system 258
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . .
Electronic throttle control system 260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . .
Brake system 261
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear indicators 265
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . Limited ±slip differential
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . 265
