fold seats Lexus IS300 2017 Owner's Manual / LEXUS 2017 IS200T,IS300,IS350 OWNER'S MANUAL (OM53D76U)

130
IS350/300/200t_U (OM53D76U)3-3. Adjusting the seats
■Power easy access system (if equipped)
The driver’s seat and steering wheel move in
accordance with engine switch mode and
the driver’s seat belt condition. ( →P. 134)
■When adjusting the seat
●Take care when adjusting the seat so that the head restraint does not touch the ceiling.
●When folding down a rear seatback, if it inte rferes with a front seatback, adjust the front
seat position so that the seats no longer inte rfere with each other. However, if adjusting
the front seat position causes the correct driving posture to not be maintained, return
the rear seatback to its original position. ( →P. 132)
Front seats
Adjustment procedure
Seat position adjustment
Seatback angle adjustment
Seat cushion (front) angle adjust-
ment Seat cushion (rear) angle adjust-
ment
Lumbar support adjustment (if
equipped)1
2
3
4
5

1323-3. Adjusting the seats
IS350/300/200t_U (OM53D76U)
Check that the luggage security sys-
tem lever in the trunk is in the unlock
position.
Pull the seatback lock release lever
and fold the seatback down.
To return the rear seatbacks to their
original position, lift them up until they
lock.
→ P. 118
Rear seats
The rear seatbacks can be folded down.
Folding down the rear seatbacks
1
2
Luggage security system

1333-3. Adjusting the seats
3
Operation of each component
IS350/300/200t_U (OM53D76U)
WARNING
Observe the following precautions. Failure to do so may result in death or serious injury.
■When folding the rear seatbacks down
●Do not fold the seatbacks down while driving.
●Stop the vehicle on level ground, set the pa rking brake and shift the shift lever to P.
●Do not allow anyone to sit on a folded seatback or in the trunk while driving.
●Do not allow children to enter the trunk.
■After returning the rear seatback to the upright position
●Check that the seat belts are not twisted or caught in the seatback.
●Make sure that the seatback is securely
locked in position by lightly pushing it back
and forth.
If the seatback is not securely locked, the red
marking will be visible on the seatback lock
release knob. Make sure that the red marking
is not visible.

1684-1. Before driving
IS350/300/200t_U (OM53D76U)
WARNING
■Things that must not be carried in the trunk
The following things may cause a fire if loaded in the trunk:
●Receptacles containing gasoline
●Aerosol cans
■Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals from being depressed properly, may block the
driver’s vision, or may result in items hittin g the driver or passengers, possibly causing
an accident.
●Stow cargo and lugg age in the trunk whenever possible.
●To prevent cargo and luggage from sliding forward during braking, do not stack any-
thing in the enlarged trunk. Keep cargo and luggage low, as close to the floor as pos-
sible.
●When you fold down the rear seats, long items should not be placed directly behind
the front seats.
●Never allow anyone to ride in the enlarged trunk. It is not designed for passengers.
They should ride in their seats with their seat belts properly fastened.
●Do not place cargo or luggage in or on the following locations.
• At the feet of the driver
• On the front passenger or re ar seats (when stacking items)
• On the package tray
• On the instrument panel
•On the dashboard
• In front of the Lexus Display Audio scre en (if equipped) or navigation system
screen (if equipped)
●Secure all items in the occupant compartment.
■Capacity and distribution
●Do not exceed the maximum axle weight rating or the total vehicle weight rating.
●Even if the total load of occupant’s weight and the cargo load is less than the total load
capacity, do not apply the load unevenly. Improper loading may cause deterioration
of steering or braking control whic h may cause death or serious injury.

641Alphabetical index
IS350/300/200t_U (OM53D76U)
Paddle shift switches ............................. 179
Parking assist sensors (intuitive parking assist) .................. 248
Parking brake.......................................... 186
Parking lights ........................................... 188 Light switch ............................................188
Replacing light bulbs ....................... 502
PCS (Pre-Collision System) .............. 214 Warning light ........................................ 517
Personal lights..........................................413 Wattage ................................................. 586
Pop-up display .......................................... 92
Power easy access system .................134
Power outlet ........................................... 422
Power steering (Electric power steering system)................................. 290 Warning light ........................................ 517
Power windows .......................................149 Door lock linked window operation ............................. 151
Jam protection function ................... 150
Operation ............................................... 149
Window lock switch.......................... 149
Pre-Collision System (PCS) .............. 214 Warning light ........................................ 517 Radar cruise control (dynamic
radar cruise control).........................236
Radiator...................................................... 471
Radio ..........................................................326
Rear passengers’ seat belt reminder lights .....................................518
Rear personal lights .............................. 413 Wattage ................................................ 586
Rear seats .................................................. 132 Fold down the seatback................... 132
Luggage security system.................. 118
Rear sunshade........................................423 Operation.............................................. 423
Reverse operation feature ............ 423
Rear turn signal lights ........................... 184 Replacing light bulbs ...................... 500
Turn signal lever ...................................184
Wattage ................................................ 586
Rear view mirror Inside rear view mirror...................... 144
Outside rear view mirrors ..............146
Rear window defoggers .................... 406
Refueling.................................................. 203 Capacity................................................. 576
Fuel types............................................... 576
If the fuel filler door cannot be opened .........................205
Opening the fuel tank cap ............205
PR

642Alphabetical index
IS350/300/200t_U (OM53D76U)
Remote Touch*.................................... 396
Replacing Electronic key battery ......................493
Fuses........................................................ 495
Light bulbs ............................................ 498
Tires ......................................................... 546
Reporting safety defects for U.S. owners.....................................614
Resetting the message indicating maintenance is required ................ 454
Rev indicator ...............................................81
Rev peak .......................................................81
Seat belt reminder light....................... 518
Seat belts..................................................... 30 Adjusting the seat belt ..........................31
Automatic Locking Retractor......... 32
Child restraint system installation ..............................................60
Cleaning and maintaining the seat belt ........................................ 451
Emergency Locking Retractor ................................................ 32
How to wear your seat belt .............30
How your child should wear the seat belt .......................................... 32
Pregnant women, proper seat belt use.......................................... 33
Reminder light and buzzer ............ 518
Seat belt extender................................. 32
Seat belt pretensioners ........................31
SRS warning light................................ 516 Seat heaters................................................411
Seat position memory .......................... 134
Seat ventilators..........................................411
Seating capacity ..................................... 169
Seats, Front ...............................................130
Adjustment............................................. 130
Adjustment precautions.....................131
Child seats/child restraint system installation ............................. 57
Cleaning.................................................450
Driving position memory................. 134
Head restraints .....................................139
Power easy access system ............. 134
Properly sitting in the seat ................ 28
Seat heaters ..............................................411
Seat position memory ....................... 134
Seat ventilators........................................411
Seats, Rear ................................................ 132 Fold down the seatback................... 132
Luggage security system.................. 118
Sensor Automatic headlight system ......... 190
Inside rear view mirror......................145
Intuitive parking assist...................... 248
LDA (Lane Departure Alert with steering control) ....................227
Radar sensor............................ 209, 276
Rain-sensing windshield wipers................................................... 202
Service reminder indicators ................ 74
Shift lever ................................................... 177 Automatic transmission .................... 177
If the shift lever cannot be shifted from P ..............182
S
*: For vehicles with a naviga tion system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.
