Lexus IS300 2019 / LEXUS 2019 IS300,IS350 QUICK GUIDE (OM53E86U) User Guide
Manufacturer: LEXUS, Model Year: 2019, Model line: IS300, Model: Lexus IS300 2019Pages: 74, PDF Size: 2 MB
Page 11 of 74
11
Turn Signal Lever
Right turn
Lane change to the right (move the
lever partway an d release it)
The right hand signal s will flash 3 times.
Lane change to the left (move the lever
partway and release it)
The left hand signals will flash 3 times.
Left turn
■ If the turn signals do not stop flashing after turning left or right, or if you
want to stop them flashing
Operate the lever in the opposite direction to either position or . If you move the
lever to either position or , the selected turn signals will flash.
The lever will return to its or iginal position after operation.
1
2
3
4
■Customization
The number of times the turn signals flas h during a lane change can be changed.
23
14
Page 12 of 74
12
Multi-information Display
■Except F SPORT modelsMenu icon display area ( P. 16)
Displays the following items.
When a menu icon is not selected, the outside temperature and clock are displayed.
•Menu icons
• Outside temperature
•Clock
Content display area
A variety of information can be displayed by selecting a menu icon. Additionally, warn-
ing or advice pop-up displays will be displayed in some situations.
• Menu icon content
• Warning message
Indicator/shift position display area
Displays the following items:
•Indicators
• Shift position display
Odometer/trip meter display area
Displays the following items:
• Odometer/trip meter
• Distance until next engine oil change
Meter control switches ( P. 15)
Odometer/trip meter and tr ip meter reset button (P. 15)
The multi-information display presents the driv er with a variety of driving-related data,
such as the current outside temperature. Th e multi-information display can also be used
to change the display settings and other settings.
1
2
3
4
5
6
Page 13 of 74
13
■F SPORT models
Main meter in center position
Main meter moved to the right
Page 14 of 74
14
Clock
Outside temperature
Indicator/shift position display area
Displays the following items:
•Indicators
• Shift position display
Content display area
Main meter in center position:
Displays various drive information on the main meter. Additionally, warning or advice
pop-up displays will be disp layed in some situations.
• Drive information
• Warning message
Main meter moved to the right:
A variety of information can be displayed by selecting a menu icon. Additionally, warn-
ing or advice pop-up displays will be displayed in some situations.
• Menu icon content
• Warning message
Odometer/trip meter display area
Displays the following items:
• Odometer/trip meter
• Distance until next engine oil change
Menu icons ( P. 16)
Meter control switches ( P. 15)
Odometer/trip meter and tr ip meter reset button (P. 15)1
2
3
4
5
6
7
8
Page 15 of 74
15
■Using the multi-information display
■Using the content display area
The content display area is operated using the meter control switches.
:Select menu icons
:Change displayed content,
scroll up/down the screen
and move the cursor
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
Pressing and holding the switch will
display the first screen of the selected
menu icon.
Except F SPORT models Press: Display the top screen
Press and hold: Register current
screen as the top screen
F SPORT models Move the main meter
When the main meter moves to the
right, the menu icons will be displayed
on the left side.
■Using the odometer/trip meter display area
Items in this area are operated using the odometer/trip meter and trip meter reset button.
Press: Change displayed itemEach time the button is pressed, the dis-
played item will be changed.
Press and hold: Reset Display the desired trip meter and press
and hold the button to reset the trip
meter.
1
2
3
4
4
■ Move the main meter (F SPORT models)
Moves between center and right-side positions.
Page 16 of 74
16
■Menu icons
Select a menu icon to display its content.
Drive information
Select to display various drive data.
Navigation system-linked display (if equipped)
Select to display the following na vigation system-linked information.
• Route guidance
• Compass display (heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the
meter control switches.
Driving assist system information
Select to display the operational status of the following systems:
• Dynamic radar cruise control
• LDA (Lane Departure Aler t with steering control)
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display settings and other settings.
If a problem is detected in any of the vehicle’s systems, a warning message is shown on the
multi-information display.
Page 17 of 74
17
Headlights
Operating the switch turns on the lights as follows: The side marker, parking, tail, license plate, in strument panel
lights, and daytime running
lights turn on.
The headlights and all lights
listed above (except daytime
running lights) turn on.
The headlights, parking lights, daytime running lights and all
the lights listed above turn on
and off automatically. (When
the engine switch is in IGNI-
TION ON mode.)
Off
The daytime running lights turn
on.
■ Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
(Canada)
(U.S.A.)
1
2
3
4
(U.S.A.)
(Canada)
1
2
Page 18 of 74
18
Automatic High Beam
■Activating the Automatic High Beam
Push the lever away from you with the
headlight switch in the or
position.
Press the Automatic High Beam
switch.
The Automatic High Beam indicator
will come on when the system is oper-
ating.
The Automatic High Beam uses a camera sens or located behind the upper portion of
the windshield to assess the brightness of the lights of vehicles ahead, streetlights, etc.,
and automatically turns the high beams on or off as necessary.
1
2
Page 19 of 74
19
■Turning the high beam on/off manually
● Switching to the low beams
Pull the lever to its original position.The Automatic High Beam indicator will
turn off.
Push the lever away from you to activate
the Automatic High Beam system again.
● Switching to the high beams
Press the Automatic High Beam switch.The Automatic High Beam indicator will
turn off and the high beam indicator will
turn on.
Press the switch to activate the Auto-
matic High Beam system again.
Page 20 of 74
20
Windshield Wipers and Washer
Intermittent windshield wipers with interval adjuster
(U.S.A.) or (Canada)
Up 2 levels
Up 1 level
(U.S.A.) or (Canada)
Down 1 level
(U.S.A.) or (Canada)
Down 2 levels
Operating the lever operates the wipers or washer as follows. The lever will
return to its original position after operation.
1
2
3
4
or or or
OffTemporary
operationTemporary operationIntermittent operationHigh speedoperation
Intermittent operationOffOffLow speedoperationHigh speed operation
Low speed operationOffIntermittent
operationHigh speedoperationHigh speedoperation
High speed operationOffLow speedoperationNo changeNo change
Status
before
operation
Operation
