Page 561 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5618-2. Steps to take in an emergency
8
When trouble arises
IS350 AWD/IS350/IS300 AWD/IS300_U
WARNING
■Using the tire jack
Observe the following precautions.
Improper use of the tire jack may cause

Page 562 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5628-2. Steps to take in an emergency
IS350 AWD/IS350/IS300 AWD/IS300_U
Remove the luggage mat.
Take out the jack handle from the
reverse side of the luggage mat.
Remove the spacer.
Take out the jack.

Page 563 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5638-2. Steps to take in an emergency
8
When trouble arises
IS350 AWD/IS350/IS300 AWD/IS300_U
Remove the luggage mat.
Remove the spacer and tool tray.
Loosen the center fastener that
secures the spare

Page 564 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5648-2. Steps to take in an emergency
IS350 AWD/IS350/IS300 AWD/IS300_U
Chock the tires.
Slightly loosen the wheel nuts (one
turn).
Turn the tire jack portion “A” by hand
until the notch of the ja

Page 565 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5658-2. Steps to take in an emergency
8
When trouble arises
IS350 AWD/IS350/IS300 AWD/IS300_U
Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and the
tire

Page 566 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5668-2. Steps to take in an emergency
IS350 AWD/IS350/IS300 AWD/IS300_U
Remove any dirt or foreign matter
from the wheel contact surface.
If foreign matter is on the wheel contact
surface, the wheel n

Page 567 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5678-2. Steps to take in an emergency
8
When trouble arises
IS350 AWD/IS350/IS300 AWD/IS300_U
■The compact spare tire
●The compact spare tire is identified by the label “TEMPORARY USE ONLY” on

Page 568 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5688-2. Steps to take in an emergency
IS350 AWD/IS350/IS300 AWD/IS300_U
WARNING
■When using the compact spare tire
●Remember that the compact spare tire provided is specifically designed for use w

Page 569 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5698-2. Steps to take in an emergency
8
When trouble arises
IS350 AWD/IS350/IS300 AWD/IS300_U
NOTICE
■Be careful when driving over bumps with the compact spare tire installed on the vehi-
cle
When d

Page 570 of 660

Lexus IS300 2020  Owners Manual / LEXUS 2020 IS300,IS350 OWNERS MANUAL (OM53F29U) 5708-2. Steps to take in an emergency
IS350 AWD/IS350/IS300 AWD/IS300_U
One of the following may be the cause of the problem:
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the v
