Page 155 of 628

1533-2. Opening, closing and locking the doors and trunk
3
Operation of each component
IS300h_EE(OM53B95E)
Note for the push-start function
Even when the electronic key is within the effective range (detection areas), the
system may not operate properly when the electronic key is on the instrument
panel, rear package tray or floor, or in the door pockets or glove box when the
hybrid system is started or power switch modes are changed.
Even if the electronic key is not inside the vehicle, it may be possible to start
the hybrid system if the electronic key is near the window.
When the vehicle is not driven for extended periods
Vehicles with entry function: To prevent theft of the vehicle, do not leave the
electronic key within 2 m (6 ft.) of the vehicle.
The smart entry & start system can be deactivated in advance. (P. 575)
To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get the
electronic key too close to the vehicle when operating the system from the out-
side of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention function may not
operate.)
Do not leave the electronic key inside the luggage compartment.
The key confinement prevention function may not operate, depending on the
location of the key (close to a spare tire [if equipped], the inside edge of the lug-
gage compartment), conditions (inside a metal bag, close to metallic objects)
and the radio waves in the surrounding area. (P. 146)
If the smart entry & start system does not operate properly
Locking and unlocking the doors and opening the trunk: Use the mechanical
key.
(P. 548)
Starting the hybrid system: P. 5 4 9
Customization
Settings (e. g. smart entry & start system) can be changed.
(Customizable features: P. 575)
If the smart entry & start system has been deactivated in a customized setting
Locking and unlocking the doors and opening the trunk:
Use the wireless remote control or mechanical key. (P. 136, 144, 548)
Starting the hybrid system and changing power switch modes:P. 549
Stopping the hybrid system: P. 210
Page 462 of 628

4487-3. Do-it-yourself maintenance
IS300h_EE(OM53B95E)
The meanings of each caution symbol on the top of the 12-volt battery are
as follows:
Before recharging
When recharging, the 12-volt battery produces hydrogen gas which is flammable
and explosive. Therefore, observe the following precautions before recharging:
If recharging with the 12-volt battery installed on the vehicle, be sure to discon-
nect the ground cable.
Make sure the power switch on the charger is off when connecting and discon-
necting the charger cables to the 12-volt battery.
After recharging/reconnecting the 12-volt battery
The hybrid system may not start. Follow the procedure below to initialize the
system.
Shift the shift lever to P.
Open and close any of the doors.
Restart the hybrid system.
Unlocking the doors using the smart entry & start system may not be possible
immediately after reconnecting the 12-volt battery. If this happens, use the
wireless remote control or the mechanical key to lock/unlock the doors.
Start the hybrid system with the power switch in ACCESSORY mode. The
hybrid system may not start with the power switch turned off. However, the
hybrid system will operate normally from the second attempt.
The power switch mode is recorded by the vehicle. If the 12-volt battery is
reconnected, the vehicle will return the power switch mode to the status it was
in before the 12-volt battery was disconnected. Make sure to turn off the power
switch before disconnecting the 12-volt battery. Take extra care when connect-
ing the 12-volt battery if the power switch mode prior to the 12-volt battery
being disconnected is unknown.
If the system will not start even after multiple attempts at all the methods above,
contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Caution symbols
No smoking, no naked
flames, no sparks12-volt battery acid
Shield eyesNote operating instruc-
tions
Keep away from childrenExplosive gas
1
2
3
Page 487 of 628

4737-3. Do-it-yourself maintenance
7
Maintenance and care
IS300h_EE(OM53B95E)
Remove the depleted battery.
Insert a new battery with the “+” ter-
minal facing up.
Use a CR2032 lithium battery
Batteries can be purchased at any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional, local electrical appliance
shops or camera stores.
Replace only with the same or equivalent type recommended by the manufac-
turer.
Dispose of used batteries according to local laws.
When the card key battery needs to be replaced (if equipped)
The battery for the card key is available only at Lexus dealers. Your Lexus dealer
can replace the battery for you.
If the electronic key battery is depleted
The following symptoms may occur:
The smart entry & start system and wireless remote control will not function
properly.
The operational range will be reduced.
Certification for the key battery
Replace only with the same or equivalent type recommended by the manufac-
turer.
Dispose of used batteries according to local laws.
4
Page 563 of 628

5498-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
Doors
Use the mechanical key (P.
131) in order to perform the fol-
lowing operations:
Locks all the doors
Closes the windows and moon
roof (turn and hold)
*
Unlocks all the doors
Opens the windows and moon roof (turn and hold)
*
*
: This setting must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
Trunk
Turn the mechanical key clock-
wise to open.
If the electronic key does not operate properly
If communication between the electronic key and vehicle is interrupted
(P. 151) or the electronic key cannot be used because the battery is
depleted, the smart entry & start system and wireless remote control can-
not be used. In such cases, the doors and trunk can be opened and the
hybrid system can be started by following the procedure below.
Locking and unlocking the doors, unlocking the trunk and key
linked functions
1
2
3
4
Page 567 of 628

5538-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
Once the hybrid system has started, remove the jumper cables in the
exact reverse order from which they were connected.
Once the hybrid system starts, have the vehicle inspected at any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped
professional as soon as possible.
Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
To prevent 12-volt battery discharge
Turn off the headlights and the audio system while the hybrid system is off.
Turn off any unnecessary electrical components when the vehicle is running at
a low speed for an extended period, such as in heavy traffic.
Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when
the vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the 12-volt battery
may discharge, and the hybrid system may be unable to start. (The 12-volt bat-
tery recharges automatically while the hybrid system is operating.)
When recharging or replacing the 12-volt battery
For vehicles with an alarm: Make sure that the key is not inside the vehicle
when recharging or replacing the 12-volt battery. The key may be locked in the
vehicle if the alarm is activated. (P. 98)
In some cases, it may not be possible to unlock the doors using the smart entry
& start system when the 12-volt battery is discharged. Use the wireless remote
control or the mechanical key to lock or unlock the doors.
The hybrid system may not start on the first attempt after the 12-volt battery has
recharged but will start normally after the second attempt. This is not a mal-
function.
The power switch mode is memorized by the vehicle. When the 12-volt battery
is reconnected, the system will return to the mode it was in before the 12-volt
battery was discharged. Before disconnecting the 12-volt battery, turn the
power switch off.
If you are unsure what mode the power switch was in before the 12-volt battery
discharged, be especially careful when reconnecting the 12-volt battery.
8
Page 594 of 628

579
9 9-2. Customization
Vehicle specifications
IS300h_EE(OM53B95E)
Door lock (P. 136, 143, 549)
Smart entry & start system and wireless remote control (P. 136, 143)
FunctionDefault set-
tingCustomized set-
ting
Unlocking using a
mechanical keyAll doors
unlocked in
one stepDriver's door
unlocked in one
step, all doors
unlocked in two
steps
———O
Speed-detecting auto-
matic door lock functionOnOffO—OO
Shifting gears to position
other than P locks all
doors
OffOnO—OO
Shifting gears to P
unlocks all doorsOffOnO—OO
Opening driver's door
unlocks all doorsOnOffO—OO
Locking/unlocking of the
trunk when all doors are
locked/unlockedOnOff———O
1234
FunctionDefault set-
tingCustomized set-
ting
Operation signal
(Emergency flashers)OnOffO—OO
Time elapsed before auto-
matic door lock function
is activated if door is not
opened after being
unlocked
30 seconds
60 seconds
O—OO120 seconds
Open door warning
buzzerOnOff———O
1234
Page 595 of 628

5809-2. Customization
IS300h_EE(OM53B95E)
Smart entry & start system (P. 136, 143, 149)
*: If equipped
Wireless remote control (P. 136, 143)
Driving position memory* (P. 168)
*: If equipped
FunctionDefault set-
tingCustomized set-
ting
Smart entry & start sys-
temOnOffO—OO
Smart door unlocking*All the doorsDriver's doorO—OO
Number of consecutive
door lock operations
*
As many as
desired2 times———O
1234
FunctionDefault set-
tingCustomized set-
ting
Wireless remote controlOnOff———O
Unlocking operation
All doors
unlocked in
one step
Driver's door
unlocked in one
step, all doors
unlocked in two
steps
O—OO
Trunk unlocking opera-
tionPress and
hold (short)
One short press
———O
Push twice
Press and hold
(long)
Off
1234
FunctionDefault set-
tingCustomized set-
ting
Driver's seat movement
when exiting the vehicleStandardOffO—OOPartial
Selecting the door link-
ing driving position mem-
ory with door unlock
operation
Driver's doorAll doors———O
1234
Page 600 of 628

585
9 9-2. Customization
Vehicle specifications
IS300h_EE(OM53B95E)
Vehicle customization
When the speed-detecting automatic door lock and shift-linked automatic door
lock are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, all the doors will
be locked.
• If the vehicle is started with all doors locked, the speed-detecting automatic
door lock will not operate.
• If the vehicle is started with any door unlocked, the speed-detecting auto-
matic door lock will operate.
When the smart entry & start system is off, the entry unlock function cannot be
customized.
When the doors remain closed after unlocking the doors and the timer activated
automatic door lock function activates, signals will be generated in accordance
with the operation buzzer volume and operational signal (Emergency flashers)
function settings.
When customizing using the Remote Touch or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever
to P. Also, to prevent 12-volt battery discharge, leave the hybrid system operating
while customizing the features.
CAUTION
During customization
As the hybrid system needs to be operating during customization, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may col-
lect and enter the vehicle. This may lead to death or a serious health hazard.
NOTICE
During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is operating
while customizing features.
Page 611 of 628

595Alphabetical index
IS300h_EE(OM53B95E)
Clock .........................................420
Coat hooks .................................424
Condenser .................................446
Console box ...............................414
Coolant ......................................444
Capacity ................................567
Checking ...............................444
Preparing and checking
before winter ......................311
Cooling system ..........................444
Engine overheating ...............556
Hybrid system overheating ...556
Cruise control
Cruise control .......................245
Dynamic radar cruise control .....
249
Cup holders ...............................415
Current fuel consumption ..........117
Curtain shield airbags .................43
Customizable features ...............576DAB (Digital Audio Broadcast)339
Daytime running light system . 227
Defogger
Front windshield .................. 404
Outside rear view mirrors .... 404
Rear window ........................ 404
Differential ............................... 569
Digital Audio Broadcast (DAB)339
Dimensions ............................... 562
Display
Drive information ................ 117
Dynamic radar cruise control ....
249
LDA (Lane Departure Alert) 265
Multi-information display.... 116
Warning message................. 514
Distance .................................... 118
Do-it-yourself maintenance ...... 435
Door courtesy lights
Location ............................... 411
Wattage ................................ 572
Door lock
Doors ................................... 136
Smart entry & start system .. 149
Wireless remote control ....... 130D
Page 617 of 628

601Alphabetical index
IS300h_EE(OM53B95E)
Jack
Positioning the jack ..............438
Vehicle-equipped jack ..........460
Jack handle ................................460
Jam protection function
Moon roof .............................188
Power window ......................185
Keyless entry
Smart entry & start
system.........................136, 143
Wireless remote control136, 143
Keys...........................................130
Battery-Saving Function.......150
Electronic key .......................130
If the electronic key does not
operate properly .................549
Key number plate .................130
Keyless entry ................136, 143
Mechanical key.....................131
Power switch ........................209
Replacing the battery ............472
Warning buzzer ....................137
Wireless remote control........130
Knee airbags ................................43Lane Departure Alert (LDA) .... 264
Language
(multi-information display).... 118
LDA (Lane Departure Alert) .... 264
Lever
Auxiliary catch lever ........... 437
Hood lock release lever ....... 437
Shift lever ............................ 216
Turn signal lever .................. 222
Wiper lever .......................... 235
Lexus Display Audio system.... 316
Lexus Display Audio controller 318
Lexus parking assist-sensor ...... 271
License plate lights ................... 226
Light switch ......................... 226
Replacing light bulbs ........... 493
Light bulbs
Replacing ............................. 481
Wattage ................................ 572
J
K
L
