Lexus IS300h 2013 Owner's Manual

3185-1. Basic Operations
IS300h_EE(OM53B95E)
By using the Lexus Display Audio controller, you can control the audio
system, hands-free system, etc.
Display the “Source” screen or
audio top screen (P. 330)
Display the “MENU” screen
(P. 317)
Display the previous screen
Turn or move the controller to
select a function and number.
Move the controller to display
the left or right side of screen.
Push the controller to enter the selected function and number.
Using the Lexus Display Audio controller
Select: Turn or move the con-
troller.
Enter: Push the controller.
Lexus Display Audio controller
1
2
3
4
1
2

3195-1. Basic Operations
5
Lexus Display Audio system
IS300h_EE(OM53B95E)
Basic screen operation
When a list is displayed, use the appropriate button to scroll through
the list.
Indicator turns on when you
can select the list by turning
the controller.
Indicator turns on when you
can return to the previous
screen by pressing the but-
ton.
Indicator turns on when you
can move the controller left to
view additional screen text.
Indicator turns on when you can move the controller right to view
additional screen text.
1
2
3
4

3205-1. Basic Operations
IS300h_EE(OM53B95E)
Input mode
Letters and numbers are inputted via the screen.
Turn the controller to select
the desired character and press
the controller to input the char-
acter.
When this indicator is shown,
you can change input fields by
moving the controller forward.
When this indicator is shown,
you can change character
types by moving the control-
ler to the right and then select-
ing the desired character type.
Select to erase characters one by one. Select and hold to erase all
characters.
Select to complete data input.
Input field mode
When in the input field you can move the cursor to the desired posi-
tion.
Turn the controller to move the
cursor left or right.
When this indicator is shown,
you can move the cursor to the
right input field by moving the
controller to the right.
When this indicator is shown,
you can move the cursor to the
left input field by moving the
controller to the left.
When this indicator is shown, you can change to input mode by
moving the controller backward.
Inputting letters and numbers
1
2
3
4
5
1
2
3
4

3215-1. Basic Operations
5
Lexus Display Audio system
IS300h_EE(OM53B95E)
When using the screen
Under extremely cold conditions, the Lexus Display Audio controller may react
slowly.
If the screen is cold, the display may be dark, or the system may seem to be
operating slightly slower than normal.
The screen may seem dark and hard to see when viewed through sunglasses.
Change your angle of viewing, adjust the display on the “Display” screen (P.
329) or remove your sunglasses.
Using cellular phones
Interference may be heard through the audio system's speakers if a cellular phone
is being used inside or close to the vehicle while the audio system is operating.
CAUTION
Using the Lexus Display Audio controller
Be careful when touching the Lexus Display Audio controller in extreme tem-
peratures as it may become very hot or cold due to the temperature inside the
vehicle.
Laser product
This product is a class 1 laser product.
Do not open the cover of the player or attempt to repair the unit yourself. Refer
servicing to qualified personnel.
NOTICE
To prevent Lexus Display Audio controller malfunction
Do not allow the Lexus Display Audio controller to come into contact with
food, liquid, stickers or lit cigarettes as doing so may cause it to change color,
emit a strange odor or stop functioning.
Do not subject the Lexus Display Audio controller to excessive pressure or
strong impact as the controller may bend or break off.
To prevent 12-volt battery discharge
Do not leave the audio system on longer than necessary when the hybrid sys-
tem is off.
To avoid damaging the audio system
Take care not to spill drinks or other fluids on the audio system.

3225-1. Basic Operations
IS300h_EE(OM53B95E)
Volume switch
• Increases/decreases volume
• Press and hold: Continuously
increases/decreases volume
Radio mode:
• Press (except manual mode):
Select a radio station
• Press (manual mode): Seek up/
down
• Press and hold (manual mode): Continuously seek up/down
CD, MP3/WMA/AAC disc, Bluetooth
®, iPod or USB mode:
• Press: Select a track/file/song/video
• Press and hold: Select a folder/album (MP3/WMA/AAC disc or
USB)
“MODE” switch
• Turns the power on, selects audio source
• Press and hold this switch to mute or pause the current operation. To
cancel the mute or pause, press and hold.
Steering wheel audio switches
Some audio features can be controlled using the switches on the steering
wheel.
Operation may differ depending on the type of audio system or naviga-
tion system. For details, refer to the manual provided with the audio sys-
tem or navigation system.
Operating the audio system using the steering wheel switches
1
2
CAUTION
To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
3

3235-1. Basic Operations
5
Lexus Display Audio system
IS300h_EE(OM53B95E)
iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if it
is not turned on.
USB memory
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
iPod video and A/V
To operate the video functions such as iPod video or A/V, a 4-pole AUX cable is
necessary. However, depending on the cable specifications, the video function
may not work properly. For more information consult any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
USB/AUX ports
Connect an iPod, USB memory device or portable audio player to the
USB/AUX port as indicated below. Select “iPod”, “USB”, “AUX” or
“A/V” on the audio source selection screen and the device can be oper-
ated via Display Audio system.
Connecting using the USB/AUX port
CAUTION
While driving
Do not connect a device or operate the device controls.

324
IS300h_EE(OM53B95E)5-2. Setup
Go to “Setup”: “Setup”
Change the settings for operation
sounds, screen animation, etc.
(P. 325)
Adjust the settings for voice
guidance volume. (P. 328)
Change the settings for register-
ing, removing, connecting and
disconnecting Bluetooth
®
devices.
(P. 358)
Change the settings for FM radio, iPod, etc. (P. 332)
Change the settings for vehicle customization. (P. 575)
Change the settings for phone sound, phonebook, etc. (P. 379)
Setup menu
The Display Audio system can be adjusted to the desired settings.
Display “Setup” screen
1
2
3
4
5
6

3255-2. Setup
5
Lexus Display Audio system
IS300h_EE(OM53B95E)
Go to “General settings”: “Setup” “General”
Change language.
The selectable languages may differ
depending on the model or region.
Change the distance unit.
Set the beep sound on/off.
Change the button color.
Change the startup image and
screen off image. (P. 326)
Set the animation effect on/off.
Delete personal data (P. 327)
Update program versions.
For details, contact any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
Update gracenote database versions.
For details, contact any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
Display the open source license.
General settings
Settings are available for adjusting the operation sounds, screen anima-
tion, etc.
Screen for general settings
1
2
3
4
5
6
7
8
9
10

3265-2. Setup
IS300h_EE(OM53B95E)
Go to “Customize images”:  “Setup”  “General”  “Custom-
ize images”
Select “Set images” and then select the desired image.
Set as startup image.
Set as screen off image.
Set as startup image and
screen off image.
Adding an image
Connect a USB memory device. (P. 323)
Select “Copy from USB” on the “Customize images” screen and
then select the desired image.
Move the controller to the left and then select “Copy”.
Up to 10 images can be downloaded.
Deleting images
Select “Delete images” on the “Customize images” screen and then
select the desired images.
USB memory
When saving the images to a USB memory device, name the folder that the
images are saved to “Image”.
Compatible device formats
The following device format can be used:
• The image’s file format must be JPEG
• USB communication format: USB2.0 FS (480 Mbps)
• File system format: FAT16/32 (Windows)
• Correspondence class: Mass storage class
JPEG file compatibility
Compatible image size: Maximum 10 MB
Customizing images
1
2
1
2
3
1
2
3

3275-2. Setup
5
Lexus Display Audio system
IS300h_EE(OM53B95E)
 “Setup”  “General”  “Delete personal data”
Select “Delete”.
Check carefully beforehand, as data cannot be retrieved once deleted.
The following personal data will be deleted or changed to its default
settings.
• Phonebook data
• Voice tag
• Call history data
• Favorite data
•Bluetooth
® devices data
• Phone sound settings
• Detailed Bluetooth
® settings
• Audio/video setting
• Preset switch data
• Last used radio station
• Customized image data
• FM info setting
• iPod tagging information
• Software update history
• Software update detail information
• Phone display setting
• Contact/call history setting
• Messaging setting
NOTICE
If the console box lid cannot be fully closed
P. 3 5 5
To prevent damage to the USB memory device or its terminals
P. 3 5 5
Deleting personal data
1
2
