Lexus IS300h 2013 Owner's Guide

31Pictorial index
IS300h_EE(OM53B95E)
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Sun visors
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 420
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 420
Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
Personal lights
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
Moon roof switches
*3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 187
Intrusion sensor cancel switch
*3 . . . . . . . . . . . . . . . . . . . . . . . . P. 99
Intrusion sensor and tilt sensor cancel switch
*3. . . . . . . . . . . . . P. 99
1
2
3
4
5
6
*1: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to
the CHILD can occur. (P. 76)
*2: The illustration shows the front, but they are also equipped in the rear.
*3: If equipped

32Pictorial index
IS300h_EE(OM53B95E)

33
1For safety and security
IS300h_EE(OM53B95E)
1-1. For safe use
Before driving ..................... 34
For safety drive ................... 36
Seat belts ............................. 38
SRS airbags......................... 43
Airbag manual on-off
system ............................... 54
Pop Up Hood ...................... 56
Safety information for
children ............................. 59
Child restraint systems........ 60
Installing child restraints .... 69
Exhaust gas precautions...... 78
1-2. Hybrid system
Hybrid system features ....... 79
Hybrid system precautions . 83
1-3. Theft deterrent system
Immobilizer system ............ 90
Double locking system ....... 95
Alarm .................................. 96

34
IS300h_EE(OM53B95E)1-1. For safe use
Use only floor mats designed specifically for vehicles of the same model
and model year as your vehicle. Fix them securely in place onto the car-
pet.
Insert the retaining hooks (clips)
into the floor mat eyelets.
Turn the upper knob of each
retaining hook (clip) to secure the
floor mats in place.
*: Always align the marks.
The shape of the retaining hooks (clips) may differ from that shown in the
illustration.
Before driving
Floor mat
1
*
2

351-1. For safe use
1
For safety and security
IS300h_EE(OM53B95E)
CAUTION
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering with
the pedals while driving. An unexpectedly high speed may result or it may
become difficult to stop the vehicle, leading to an accident, or leading to death or
a serious injury.
When installing the driver’s floor mat
Do not use floor mats designed for other models or different model year vehi-
cles, even if they are Lexus Genuine floor mats.
Only use floor mats designed for the driver’s seat.
Always install the floor mat securely using the retaining hooks (clips) pro-
vided.
Do not use two or more floor mats on top of each other.
Do not place the floor mat bottom-side up or upside-down.
Before driving
Check that the floor mat is securely fixed
in the correct place with all the provided
retaining hooks (clips). Be especially
careful to perform this check after clean-
ing the floor.
With the hybrid system stopped and the
shift lever in P, fully depress each pedal to
the floor to make sure it does not interfere
with the floor mat

361-1. For safe use
IS300h_EE(OM53B95E)
Adjust the angle of the seatback
so that you are sitting straight up
and so that you do not have to
lean forward to steer. (P. 1 6 4 )
Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. (P. 164)
Lock the head restraint in place with the center of the head restraint
closest to the top of your ears. (P. 173)
Wear the seat belt correctly. (P. 38)
Make sure that all occupants are wearing their seat belts before driving
the vehicle. (P. 3 8 )
Use a child restraint system appropriate for the child until the child
becomes large enough to properly wear the vehicle’s seat belt. (P. 6 1 )
For safety drive
For safe driving, adjust the seat and mirror to an appropriate position
before driving.
Correct driving posture
1
2
Correct use of the seat belts
3
4

371-1. For safe use
1
For safety and security
IS300h_EE(OM53B95E)
Make sure that you can see backward clearly by adjusting the inside and
outside rear view mirrors properly. (P. 178, 180)
Adjusting the mirrors
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the
effectiveness of the seat belt and head restraint.
Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat tracks
and stop the seat from locking in place. This may lead to an accident and the
adjustment mechanism may also be damaged.
When driving over long distances, take regular breaks before you start to feel
tired.
Also, if you feel tired or sleepy while driving, do not force yourself to con-
tinue driving and take a break immediately.

381-1. For safe use
IS300h_EE(OM53B95E)
Extend the shoulder belt so that it
comes fully over the shoulder,
but does not come into contact
with the neck or slide off the
shoulder.
Position the lap belt as low as
possible over the hips.
Adjust the position of the seat-
back. Sit up straight and well
back in the seat.
Do not twist the seat belt.
To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.
To release the seat belt, press the
release button.
Seat belts
Make sure that all occupants are wearing their seat belts before driving
the vehicle.
Correct use of the seat belts
Fastening and releasing the seat belt
Release but-
1
2

391-1. For safe use
1
For safety and security
IS300h_EE(OM53B95E)
Push the seat belt shoulder
anchor down while pressing the
release button.
Push the seat belt shoulder
anchor up.
Move the height adjuster up and
down as needed until you hear a
click.
The pretensioners help the seat belts
to quickly restrain the occupant by
retracting the seat belts when the
vehicle is subjected to certain types
of severe frontal collision.
The seat belt pretensioners also acti-
vate when the vehicle is subjected to
certain types of severe side collision.
The pretensioners do not activate in
the event of a minor frontal impact, a
minor side impact, a rear impact or a
vehicle rollover.
Adjusting the seat belt shoulder anchor height (front seats)
1
2
Seat belt pretensioners (front seats)

401-1. For safe use
IS300h_EE(OM53B95E)
After the rear center seat belt has been used
Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.
Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult size.
Use a child restraint system appropriate for the child, until the child becomes
large enough to properly wear the vehicle’s seat belt. (P. 6 1 )
When the child becomes large enough to properly wear the vehicle’s seat belt,
follow the instructions regarding seat belt usage. (P. 38)
Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for
the first collision, but will not activate for the second or subsequent collisions.
Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional for seat belt replacement or installation. Stow the buckle as shown.
