engine coolant Lexus IS350 2012 Quick Guide / LEXUS 2012 IS250,IS350 (OM53A87U) User Guide

5
When trouble arises
513
5-2. Steps to take in an emergency
If your vehicle overheats
If your engine overheats:
Stop the vehicle in a safe place and turn off the automatic air
conditioning system.
Check to see if steam is coming out from under the hood.
If you see steam: Stop the engine. Carefully lift the hood after the steam sub-
sides and then restart the engine.
If you do not see steam: Leave the engine running and carefully lift the hood.
Check to see if the cool ing fans are operating.
If the fans are operating: Wait until the temperature of the engine (shown on the
instrument cluster) begins to fall and then stop the engine.
If the fans are not operating: Stop the engine immediately and call your local Lexus
dealer.
After the engine has cooled
down sufficiently, check the
engine coolant level and inspect
the radiator core (radiator) for
any leaks.
If the engine compartment
cover needs to be removed:
P. 3 9 9
STEP1
STEP2
STEP3
STEP4

514
5-2. Steps to take in an emergency
■Overheating
If you observe the following, your vehicle may be overheating.
●The engine coolant temperature gauge enters the red zone or a loss of power is
experienced.
●Steam is coming from under the hood.
CAUTION
■To prevent an accident or injury when in specting under the hood of your vehicle
●If steam is seen coming from under the hood, do not open the hood until the
steam has subsided. The engine compartm ent may be very hot, causing serious
injury such as burns.
●Keep hands and clothing away from the fans and other belts while the engine is
running.
●Do not loosen the radiator cap while the engine and radiator are hot.
Serious injury, such as burns, may resu lt from hot coolant and steam released
under pressure.
Add engine coolant if required.
Water can be used in an emer-
gency if engine coolant is
unavailable. ( P. 5 2 7 )
Have the vehicle checked at your nearest Lexus dealer as soon as pos-
sible.
STEP5

5
When trouble arises
515
5-2. Steps to take in an emergency
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly
can cause damage to the engine.

527
6-1. Specifications
6
Vehicle specifications
Cooling system
Ignition system
Capacity
IS350
9.6 qt. (9.1 L, 8.0 Imp. qt.)
IS250
10.9 qt. (10.3 L, 9.1 Imp. qt.)
Coolant type
Use either of the following.• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili- cate, non-amine, non-nitrite, and non-borate cool-
ant with long-life hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
GapDENSO FK20HBR11
0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning the engine.

546
6-1. Specifications
■Temperature A, B, C
The temperature grades are A (the highest), B, and C, representing
the tire's resistance to the generation of heat and its ability to dissipate
heat when tested under controlled conditions on a specified indoor
laboratory test wheel.
Sustained high temperature can cause the material of the tire to degenerate
and reduce tire life, and excessive temperature can lead to sudden tire fail-
ure.
The grade C corresponds to a level of performance which all passenger car
tires must meet under the Federal Mo tor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory
test wheel than the minimum required by law.
Warning: The temperature grades for this tire are established for a tire that
is properly inflated and not overloaded.
Excessive speed, underinflation, or excess ive loading, either separately or in
combination, can cause heat buildup and possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipp ed, air conditioning and
additional weight optional engine

581
Alphabetical index
If you have a flat tire ........................ 492
If you lose your keys ........................ 504
If you think something is wrong................................................... 469
If your vehicle becomes stuck ......516
If your vehicle has to be stopped in an emergency.............................. 518
If your vehicle needs to be towed ................................................... 463
If your vehicle overheats.................. 513
Emergency flashers Switch ...................................................... 462
Engine Compartment ..................................... 397
Engine switch .......................................... 141
Hood ....................................................... 394
How to start the engine...................... 141
Identification number......................... 521
If the engine will not start ................ 501
Ignition switch.......................................... 141
Overheating........................................... 513
Engine compartment cover............. 399
Engine coolant Capacity..................................................527
Checking ............................................... 404
Preparing and checking before winter .................................... 206 Engine coolant temperature
gauge....................................................... 158
Engine immobilizer system..................90
Engine oil Capacity .................................................524
Checking ................................................ 401
Preparing and checking before winter ................................... 206
EPS .............................................................. 196
Event data recorder .................................21
First-aid kit storage belt ..................... 357
Floor mat ..................................................356
Fluid Brake ....................................................... 406
Washer ...................................................... 411
Fog lights Switch.........................................................176
Wattage ................................................. 536
Footwell lights ........................................ 325
Front fog lights Switch.........................................................176
Wattage ................................................. 536
Front passenger occupant classification system .......................... 109
Front passenger's seat belt reminder light...................................... 473
F
*: For vehicles with a navigation system, refe r to the “Navigation System Owner’s Manual”.

590
What to do if...
What to do if...
A tire puncturesP. 4 9 2If you have a flat tire
The engine does not start
P. 5 0 1If the engine will not start
P. 9 0Engine immobilizer system
P. 5 1 0If the vehicle battery is discharged
The shift lever cannot be
moved out of PP. 5 0 3If the shift lever cannot be shifted
from P
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 5 1 3If your vehicle overheats
The key is lostP. 5 0 4If you lose your keys
The battery runs outP. 5 1 0If the vehicle battery is discharged
The doors cannot be lockedP. 4 8Doors
The horn begins to soundP. 9 2Alarm
The vehicle is stuck in mud or
sandP. 5 1 6If the vehicle becomes stuck
