high beam Lexus IS350 2015 Owner's Manual / LEXUS 2015 IS250,IS350 OWNERS MANUAL QUICK GUIDE (OM53C80U)

Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manual s so you will have a better
understanding of your vehicle’ s capabilities and limitations.
1
Air Conditioning System*
Adjusting the temperature ...................................................................................................... .. 58
Air conditioning control screen .............................................................................................. 59
Using automatic mode........................................................................................................... ..... 60
Adjusting the temperature for driver and passenger seats separately (“DUAL” mode) .................................................................................................................. ....... 60
Audio System (with Lexus Display Audio) *
Display Audio operation buttons............................................................................................ 54
Using the steering whee l switches to change audio sources ..................................... 54
Audio menu screen .............................................................................................................. ........ 55
Operating the audio system using the steering wheel switches ............................... 57
Audio System (with navigation system)*
Audio control screen ................................................................................................................... 44
Remote control (steering wheel switches) ......................................................................... 44
Basic operation ................................................................................................................ .............. 45
Radio.......................................................................................................................... ......................... 46
DVD player/CD player........................................................................................................... ... 46
Operating an iPod .............................................................................................................. .......... 48
Automatic High Beam .......................................................................................................................15
BSM (Blind Spot Monitor) .............................................................................................................. 28
Cruise Control ............................................................................................................................... ....... 21
Dynamic Radar Cruise Control .................................................................................................. 23
Floor Mat Installation ...........................................................................................................................4
Garage Door Opener ..................................................................................................................... 68
*: This feature may be operated by Voice command (See P.62)

7
OverviewInstrument Panel
BSM (Blind Spot Monitor) main switch P.28
Odometer/trip meter and trip
meter reset button
*1
Instrument panel light control
switches
*1
Windshield wiper
de-icer switch
*1
Rear sunshade
switch
*1
Intuitive parking assist
switch
*2 P.27
Automatic high beam
switch
 P.15

14
Headlights
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all lights
listed above turn on.
The headlights, daytime run-
ning lights and all the lights
listed above turn on and off
automatically. (When the
engine switch is in IGNITION
ON mode.)
Off
The daytime running lights turn
on.
■Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
(Canada)
(U.S.A.)
1
2
3
4
(U.S.A.)
(Canada)
1
2

15
Automatic High Beam (if equipped)
■Activating the Automatic High Beam system
Push the lever away from you with the
headlight switch in the or
position.
Press the Automatic High Beam
switch.
The Automatic High Beam indicator
will come on when the headlights are
turned on automatically to indicate that
the system is active.
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of
streetlights, the lights of oncoming and prec eding vehicles, etc., and automatically turns
the high beam on or off as necessary.
1
2

16
■Turning the high beam on/off manually
● Switching to low beam
Pull the lever to the original position.The Automatic High Beam indicator will
turn off.
Push the lever away from you to activate
the Automatic High Beam system again.
● Switching to high beam
Press the Automatic High Beam switch.The Automatic High Beam indicator will
turn off and the high beam indicator will
turn on.
Press the switch to activate the Auto-
matic High Beam system again.

76
What to do if...
Follow the correction procedures.
Open door warning lightMaster warning light
Low fuel level warning light
(Illuminates without
blinking)Tire pressure warning light*1
Seat belt reminder light
See the Owner’s Manual
Tu r n s i g n a l i n d i c a t o rIntuitive parking assist 
indicator (if equipped)
Headlight indicator (U.S.A.)
(Flashes)
Slip indicator
Tail light indicator (Canada)VSC OFF indicator
Headlight high beam indicator(Flashes
faster)
Pre-collision system warning 
light (if equipped)
Automatic High Beam 
indicator (if equipped) BSM (Blind Spot Monitor) 
outside rear view mirror 
indicators (if equipped)
Fog light indicator 
(if equipped) Security indicator
Cruise control indicatorLow outside temperature 
indicator
Dynamic radar cruise control
indicator (if equipped)Eco Driving Indicator Light
Cruise control “SET” indicatorEco drive mode indicator*2
LDA (Lane Departure Alert) 
indicator (if equipped)
