oil Lexus IS350 2019 / 2019 IS300,IS350 (OM53E71U) Owner's Guide

5909-1. Specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
■Oil capacity (Drain and refill [Reference*])
*: The engine oil capacity is a reference quantity to be used when changing the engine oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.
Lubrication system
IS350 (2WD)IS350 AWD/IS300 AWD (AWD)IS300
With filter6.0 qt.
(5.7 L, 5.0 Imp. qt.)6.8 qt.
(6.4 L, 5.6 Imp. qt.)4.9 qt.
(4.6 L, 4.0 Imp. qt.)
Without filter5.8 qt.
(5.5 L, 4.8 Imp. qt.)6.3 qt.
(6.0 L, 5.3 Imp. qt.)4.5 qt.
(4.3 L, 3.8 Imp. qt.)
Outside temperature

5919-1. Specifications
9
Vehicle specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
Oil viscosity (0W-20 is explained here as an example):• The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value be fore the W allow for easier starting of
the engine in cold weather.
• The 20 in 0W-20 indicates the viscos ity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme lo ad conditions.
How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.

5939-1. Specifications
9
Vehicle specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
*: The fluid capacity is a reference quantity.If replacement is necessary, contact your Lexus dealer.
Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory.
Use Lexus approved “Toyota Genuine Differen tial Gear Oil” or an equivalent oil of
matching quality to satisfy the above specific ation. Please contact your Lexus dealer for
further details.
Automatic transmission
Fluid capacity*
IS350 (2WD)10.0 qt. (9.5 L, 8.4 Imp. qt.)
IS350 AWD/
IS300 AWD
(AWD)
10.6 qt. (10.0 L, 8.8 Imp. qt.)
IS3009.2 qt. (8.7 L, 7.7 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration
in shift quality, locking up of your transm ission accompanied by vibration, and ulti-
mately damage the transmission of your vehicle.
Front differential (AWD models)
Oil capacity 0.74 qt. (0.70 L, 0.61 Imp. qt.)
Oil type and viscosity
Toyota Genuine Differential gear oil GL-5 or equivalent
Above 0 F (-18 C): SAE90
Below 0 F (-18 C): SAE80W or SAE80W-90

5949-1. Specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
IS350 AWD/IS350/IS300 AWD/IS300 (vehicles without LSD [Limited
Slip Differential])
IS350 (vehicles with LSD [Limited Slip Differential])
*: Your Lexus vehicle is filled with “Toyota Genu ine Differential Gear Oil” at the factory.
Use Lexus approved “Toyota Genuine Differen tial Gear Oil” or an equivalent oil of
matching quality to satisfy the above specif ication. Please contact your Lexus dealer
for further details.
*1: Minimum pedal clearance when depressed wi th a force of 112.4 lbf (500 N, 51.0 kgf)
while the engine is running.
*2: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N, 30.6 kgf)
Rear differential
Oil capacity1.42 qt. (1.35 L, 1.19 Imp. qt.)
Oil type and viscosityToyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
*
Oil capacity1.42 qt. (1.35 L, 1.19 Imp. qt.)
Oil type and viscosityToyota Genuine Differential gear oil LX
75W-85 GL-5 or equivalent
*
Brakes
Pedal clearance*12WD4.2 in. (107 mm) Min.
AWD4.7 in. (118 mm) Min.
Pedal free play0.04 — 0.24 in. (1.0 — 6.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Parking brake pedal travel*27  10 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3, or
SAE J1704 or FMVSS No. 116 DOT 4
Steering
Free playLess than 1.2 in. (30 mm)

6089-1. Specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pressure
Tire pressure when the vehicle has been parked for
three hours or more, or has no t been driven more than 1
mile or 1.5 km un der that condition
Maximum inflation pres-
sureThe maximum cold inflated pr essure to which a tire may
be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a manu-
facturer
Accessory weight
The combined weight (in exce ss of those standard items
which may be replaced) of automatic transmission,
power steering, power brakes, power windows, power
seats, radio and heater, to the extent that these items are
available as factory-installed equipment (whether
installed or not)
Curb weight
The weight of a motor vehicle with standard equipment,
including the maximum capacity of fuel, oil and coolant,
and if so equipped, air co nditioning and additional
weight optional engine
Maximum loaded vehicle
weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight150 lb. (68 kg) times the numb er of occupants specified
in the second column of Table 1* that follows
Occupant distributionDistribution of occupants in a vehicle as specified in the
third column of Table 1
* below
Production options weight
The combined weight of in stalled regular production
options weighing over 5 lb. (2.3 kg) in excess of the
standard items which they re place, not previously con-
sidered in curb weight or accessory weight, including
heavy duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
RimA metal support for a tire or a tire and tube assembly
upon which the tire beads are seated

622
IS350 AWD/IS350/IS300 AWD/IS300_U9-3. Initialization
Items to initialize
The following items must be initialized for normal system operation after such
cases as the battery being reconnected
, or maintenance being performed on
the vehicle:
ItemWhen to initializeReference
Message indicating mainte-
nance is required• After the maintenance is per- formedP. 462
Tire pressure warning system
• When rotating the tires
• When changing the tire inflation
pressure by changing traveling
speed or load weight, etc.
P. 487
Oil maintenance• After the maintenance is per-formedP. 477

645Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
E-mail.........................................................380
Eco drive mode ..................................... 297
Eco Driving Indicator........................... 109
EDR (Event data recorder) ...................10
Elapsed time .............................................. 112
Electric Power Steering (EPS) ....... 302Warning light .......................................526
Electronic key ........................................... 118 Battery-saving function .....................137
If the electronic key does not operate properly............................. 572
Replacing the battery ...................... 502
Emergency, in case of If a warning message is displayed ........................................532
If the electronic key does not operate properly ........ 572
If the engine will not start............... 570
If the vehicle battery is discharged .........................................575
If the vehicle is trapped in rising water ......................................... 516
If the warning buzzer sounds................................................. 525
If the warning light turns on.......... 525
If you have a flat tire ......................... 559
If you think something is wrong...............................................523
If your vehicle becomes stuck ..................................................... 583
If your vehicle has to be stopped in an emergency ........... 515
If your vehicle needs to be towed ........................................ 517
If your vehicle overheats ................579 Emergency flashers .............................. 514
Engine ....................................................... 589
ACCESSORY mode .......................187
Compartment ..................................... 473
Engine switch ....................................... 186
Hood........................................................ 470
How to start the engine................... 186
Identification number...................... 588
If the engine will not start ............... 570
Ignition switch (engine switch) .... 186
Overheating......................................... 579
Engine coolant .......................................478 Capacity................................................. 592
Checking ............................................... 478
Preparing and checking before winter ....................................306
Engine coolant temperature gauge ........................................................ 89
Engine immobilizer system .................. 76
Engine oil ..................................................475 Capacity................................................ 590
Checking ............................................... 475
Preparing and checking before winter ....................................306
Engine oil maintenance data ............ 477
Engine switch ...........................................186
Enhanced VSC .......................................301
EPS (Electronic Power Steering) ........ 302 Warning light ....................................... 526
Event data recorder (EDR)................... 10
E

647Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
Hands-free system (for cellular phone) ............................. 371
HD Radio
® system .............................. 338
Head restraints ........................................152
Headlights ............................................... 202 AFS (Adaptive Front-lighting System) ............................................... 203
Light switch ...........................................202
Replacing light bulbs ........................... 511
Headlights cleaner................................ 210
Heaters Air conditioning system ....................417
Heated steering wheel ....................426
Outside rear view mirrors ............. 422
Seat heaters .......................................... 427
Hill-start assist control ......................... 301
Hood .......................................................... 470 Open ........................................................470
Hooks Cargo hooks ........................................435
Coat hooks ............................................ 441
Retaining hooks (floor mat) ............. 26
Horn .............................................................156 I/M test ...................................................... 467
Identification
Engine .................................................... 588
Vehicle .................................................... 587
Ignition switch (engine switch) .........186
Illuminated entry system ....................429
Immobilizer system ................................. 76
Indicators .................................................... 86
Initialization Engine oil maintenance data ........477
Maintenance ........................................ 462
Moon roof .............................................. 168
Multi-information display................ 103
Power windows....................................163
Tire pressure warning system ............................... 487
Initiators (tire pressure warning system) ................................ 493
Inside door handle lights ................... 428
Inside rear view mirror......................... 157
Instrument panel light control .............92
Intercooler .............................................. 480
Intercooler coolant...............................478 Capacity................................................. 592
Checking ............................................... 478
Preparing and checking before winter ....................................306
Interior lights ...........................................429 Wattage ................................................. 597
Intuitive parking assist ........................ 260
HI

650Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
Moon roof..................................................166Door lock linked moon roof operation ......................167
Jam protection function ....................167
Operation ............................................... 166
MP3 disc.................................................. 344
Multi-information display ..................... 94 Audio system-linked ........................... 94
Drive information ................................100
Dynamic radar cruise control......248
LDA (Lane Departure Alert with steering control) ................... 244
Navigation system-linked ................. 94
Settings ..................................................... 103
Warning message .............................532
Navigation system
*
Needle ....................................................... 103
Noise from under vehicle ....................... 8 Odometer .................................................. 89
Oil
Engine oil .............................................. 590
Front differential oil ...........................593
Rear differential oil ............................594
Opener Hood........................................................ 470
Trunk ......................................................... 130
Outer foot lights Location ................................................. 428
Replacing light bulbs .......................... 511
Wattage ................................................. 597
Outside rear view mirrors .................. 159 Adjusting and folding ........................159
Blind spot monitor ............................285
Linked mirror function when reversing................................. 160
Mirror position memory .................. 147
Outside rear view mirror defoggers............................ 422
Outside temperature ............................ 89
Overheating, Engine ...........................579
N
O

660
IS350 AWD/IS350/IS300 AWD/IS300_UGAS STATION INFORMATION
Auxiliary catch leverTrunk openerFuel filler door
P. 470 P. 130 P. 220
Hood lock release leverTire inflation pressure
P. 470
P. 595
Fuel tank capacity
(Reference) 17.5 gal. (66.3 L, 14.6 Imp. gal.)
Fuel type
Unleaded gasoline only P. 589
Cold tire inflation
pressure P. 595
Engine oil capacity
(Drain and refill —
reference)P. 590
Engine oil type
P. 590
