fuel type Lexus IS350 2019 Owner's Manual / 2019 IS300,IS350 OWNER'S MANUAL (OM53E71U)

15Pictorial index
IS350 AWD/IS350/IS300 AWD/IS300_U
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 306
To prevent freezing (windshield wiper de-icer)
*. . . . . . . . . . . . . . . . . . . . . . . P. 422
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 456
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 589
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 485
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 595
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30 6
Checking/rotation/tire pressure warning system . . . . . . . . . . . . . . . . . . . . . . P. 485
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 559
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 470
Opening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 470
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 590
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 579
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 535
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Parking lights/daytime running lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 198
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Stop lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 1 91
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
4
5
6
7
Light bulbs of the exterior lights for driving(Replacing method: P. 507, Watts: P. 597)
*: If equipped
8
9
10
11
12
13
14

421-1. For safe use
IS350 AWD/IS350/IS300 AWD/IS300_U
■If the SRS airbags deploy (inflate)
●Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the
extremely high speed deployment (inflation) by hot gases.
●A loud noise and white powder will be emitted.
●Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the
seats, parts of the front and rear pillars, an d roof side rails may be hot for several min-
utes. The airbag itself may also be hot.
●The windshield may crack.
●All of the doors will be unlocked. ( P. 129)
●Fuel supply to the engi ne will be stopped. (P. 524)
●For Lexus Enform Safety Connect subscribers, if any of the following situations occur,
the system is designed to send an emerge ncy call to the response center, notifying
them of the vehicle’s location (without needing to push the “SOS” button) and an agent
will attempt to speak with the occupants to ascertain the level of emergency and assis-
tance required. If the occupants are unable to communicate, the agent automatically
treats the call as an emergency and helps to dispatch the necessary emergency ser-
vices. ( P. 68)
• An SRS airbag is deployed.
• A seat belt pretensioner is activated.
• The vehicle is involved in a severe rear-end collision.
■SRS airbag deployment cond itions (SRS front airbags)
●The SRS front airbags will deploy in the event of an impact that exceeds the set thresh-
old level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30
km/h] frontal collision with a fixed wa ll that does not move or deform).
However, this threshold velocity will be cons iderably higher in the following situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move
or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the
front of the vehicle “underrides”, or goes under, the bed of a truck
●Depending on the type of collision, it is possi ble that only the seat belt pretensioners will
activate.
●The SRS front airbags for the fr ont passenger will not activate if there is no passenger
sitting in the front passenger seat. However, the SRS front airbags for the front passen-
ger may deploy if luggage is put in the seat, even if the seat is unoccupied. ( P. 46)
■SRS airbag deployment conditions (S RS side and curtain shield airbags)
●The SRS side and curtain shield airbags w ill deploy in the event of an impact that
exceeds the set threshold level (the level of force corresponding to the impact force
produced by an approximately 3300 lb. [15 00 kg] vehicle colliding with the vehicle
cabin from a direction perpendicular to the vehicle orientation at an approximate
speed of 12 - 18 mph [20 - 30 km/h]).
●Both SRS curtain shield airbags will de ploy in the event of vehicle rollover.
●Both SRS curtain shield airbags will deploy in the event of a severe frontal collision.

1744-1. Before driving
IS350 AWD/IS350/IS300 AWD/IS300_U
■Breaking in your new Lexus
To extend the life of the vehicle, observin g the following precautions is recommended:
●For the first 186 miles (300 km):
Avoid sudden stops.
●For the first 621 miles (1000 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive continuously in low gears.
• Do not drive at a constant speed for extended periods.
■Drum-in-disc type parking brake system
Your vehicle has a drum-in-disc type parking brake system. This type of brake system
needs bedding-down of the brake shoes peri odically or whenever the parking brake
shoes and/or drum are replaced. Have your Lexus dealer perform the bedding down
operation.
■Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability of the cor-
rect fuel. ( P. 598)
■Idling time before engine stop (IS300)
To prevent damage to the turbocharger, allow the engine to idle immediately after high-
load driving.
Driving conditionIdling time
Normal city driving or high-spe ed driving (at the highway speed
limit or recommended speed)
Not necessary
Steep hill driving, co ntinuous driving (race track driving etc.)
Approximately
1 minute

218
IS350 AWD/IS350/IS300 AWD/IS300_U4-4. Refueling
●Close all the doors and windows,
and turn the engine switch off.
●Confirm the type of fuel.
■Fuel types
P. 589
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehi cle has a fuel tank opening that only accom-
modates the specia l nozzle on unleaded fuel pumps.
■If the malfunction indicator lamp illuminates
The malfunction indicator lamp may illuminate erroneously if refueling is performed
repeatedly when the fuel tank is nearly full.
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle

5899-1. Specifications
9
Vehicle specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
Engine
IS350 AWD/IS350/IS300 AWDIS300
Model3.5 L 6-cylinder (2GR-FKS)
engine2.0 L 4-cylinder (8AR-FTS)
engine
Type 6-cylinder V type,
4-cycle, gasoline 4-cylinder in line,
4-cycle, gasoline
(with turbocharger)
Bore and stroke
3.70 
3.27 in.
(94.0  83.0 mm) 3.39
 3.39 in.
(86.0  86.0 mm)
Displacement 210.9 cu. in. (3456 cm3) 121.9 cu. in. (1998 cm3)
Valve clearance
(engine cold)Automatic adjustment
Drive belt tensionAutomatic adjustment
Fuel
Fuel typeUnleaded gasoline only
Octane Rating91 (Research Octane Number 96) or higher
Fuel tank capacity
(Reference)17.5 gal. (66.3 L, 14.6 Imp. gal.)

6009-1. Specifications
IS350 AWD/IS350/IS300 AWD/IS300_U
NOTICE
■Notice on fuel quality
●Do not use improper fuels. If improper fuels are used, the engine will be damaged.
●Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters
causing the emission control system to malfunction.
●Do not use gasohol other than the type previously stated.
Other gasohol may cause fuel system damage or vehicle performance problems.
●Using unleaded gasoline with an octane numb er or rating lower than the level previ-
ously stated may cause pe rsistent heavy knocking.
At worst, this may lead to engine da mage and will void the vehicle warranty.
■Fuel-related poor driveability
If poor driveability (poor hot starting, vaporization, engine knocking, etc.) is encoun-
tered after using a different type of fuel, discontinue the use of that type of fuel.
■When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle’s paint.

646Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
First-aid kit storage belt ..................... 435
Flat tire ...................................................... 559
Floor mats ................................................... 26
FluidAutomatic transmission ................. 593
Brake ....................................................... 594
Washer .................................................. 484
Footwell light .......................................... 428 Wattage ..................................................597
Front passenger occupant classification system ............................ 46
Front personal lights............................ 429 Wattage ..................................................597
Front seats .................................................143 Adjustment ............................................. 143
Cleaning ................................................ 458
Correct driving posture .................... 28
Driving position memory .................147
Head restraints ..................................... 152
Power easy access system .............147
Seat heaters .......................................... 427
Seat position memory........................147
Seat ventilators .................................... 427
Front turn signal lights ......................... 198 Replacing light bulbs ....................... 508
Turn signal lever .................................. 198
Wattage ..................................................597 Fuel............................................................... 218
Capacity................................................ 589
Fuel gauge ............................................... 89
Fuel pump shut off system ............ 524
Information........................................... 598
Refueling ..................................................218
Type......................................................... 589
Warning light ....................................... 527
Fuel consumption Average fuel economy .............................. 112, 113, 115
Current fuel consumption....................... 112, 113, 115
Fuel filler door.......................................... 218 If the fuel filler door cannot be opened ......................... 220
Refueling ..................................................218
Fuel gauge ................................................. 89
Fuel pump shut off system .................524
Fuses.......................................................... 504
Garage door opener...........................442
Gauges........................................................ 89
Gear positions......................................... 195
Glove box ................................................432
Glove box light.......................................432
F
G

652Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
Rear view mirrorInside rear view mirror ..................... 157
Outside rear view mirrors .............. 159
Rear window defoggers .................... 422
Refueling ................................................... 218 Capacity ................................................ 589
Fuel types .............................................. 589
If the fuel filler door cannot be opened .........................220
Opening the fuel tank cap.............220
Remote Touch
*......................................412
Replacing Electronic key battery ..................... 502
Fuses........................................................ 504
Light bulbs ............................................ 507
Tires ......................................................... 559
Reporting safety defects for U.S. owners................................... 624
Resetting the message indicating maintenance is required ................ 462
Rev indicator ...............................................91
Rev peak .......................................................91 Seat belt reminder light ......................527
Seat belts .................................................... 30
Adjusting the seat belt.......................... 31
Automatic Locking Retractor .........32
Child restraint system installation ............................................. 60
Cleaning and maintaining the seat belt ....................................... 459
Emergency Locking Retractor.................................................32
How to wear your seat belt............. 30
How your child should wear the seat belt ...........................................32
Pregnant women, proper seat belt use ......................................... 33
Reminder light and buzzer ........... 527
Seat belt extender .................................32
Seat belt pretensioners........................ 31
SRS warning light .............................. 525
Seat heaters............................................. 427
Seat position memory .......................... 147
Seat ventilators....................................... 427
Seating capacity .....................................183
S

660
IS350 AWD/IS350/IS300 AWD/IS300_UGAS STATION INFORMATION
Auxiliary catch leverTrunk openerFuel filler door
P. 470 P. 130 P. 220
Hood lock release leverTire inflation pressure
P. 470
P. 595
Fuel tank capacity
(Reference) 17.5 gal. (66.3 L, 14.6 Imp. gal.)
Fuel type
Unleaded gasoline only P. 589
Cold tire inflation
pressure P. 595
Engine oil capacity
(Drain and refill —
reference)P. 590
Engine oil type
P. 590
