air condition Lexus IS350 2019 Owner's Manual / LEXUS 2019 IS300,IS350 OWNER'S MANUAL QUICK GUIDE (OM53E86U)

Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
1
Air Conditioning System*
Adjusting the temperature ...................................................................................................... .. 53
Air conditioning control screen .............................................................................................. 54
Using automatic mode........................................................................................................... ..... 56
Adjusting the temperature for driver and passenger seats separately (“DUAL” mode) .................................................................................................................. ....... 56
Audio System (with Lexus Display Audio)*
Lexus Display Audio operation bu ttons .............................................................................. 49
Using the steering whee l switches to change audio sources ..................................... 49
Audio menu screen .............................................................................................................. ........ 50
Operating the audio system using the steering wheel switches ............................... 52
Audio System (with Navigation System)*
Audio control screen ................................................................................................................... 40
Remote control (steering wheel audio switches) . ........................................................... 40
Basic operation ................................................................................................................ ................ 41
Radio.......................................................................................................................... ........................... 41
DVD player/CD player........................................................................................................... ... 42
Operating an iPod .............................................................................................................. .......... 43
Automatic High Beam .......................................................................................................................18
BSM (Blind Spot Monitor) .............................................................................................................. 30
Dynamic Radar Cruise Control .................................................................................................. 25
Floor Mat Installation ...........................................................................................................................4
Garage Door Opener ..................................................................................................................... 62
*: This feature may be operated by Voice command (See P.58)

6
Remote Touch screen
Navigation system

Lexus Display Audio system

P.32
P.35
P.44
Emergency flasher switch*
See P.9
Engine switch
*
: If equipped
*: Refer to “OWNER’S MANUAL”.
Trunk opener*
Clock*
Trunk opener main switch*
Audio system P.40, 49
Shift lever*
Hood lock release lever*
Air conditioning system
P.53

33
■Menu
Press the “MENU” button on the Remote
Touch to display the “Menu” screen.
“Destination” ( P. 36)
“Radio” ( P. 41)
“Media” ( P. 40)
“Phone” ( P. 37)
“LEXUS App Suite”
“Info”
“Climate” ( P. 53)
“Setup”
“Display” ( P. 34)
■Side Display
The following functions can be displayed
and operated on the side display.
Navigation
Audio
Phone
Vehicle information
Air conditioning system ( P. 53)
1
2
23
34
45
6
7
8
89
1
2
3
34
45

45
■“Menu” screen
To display the “Menu” screen, press the “MEN U” button on the Lexus Display Audio con-
troller.
*: Available in the 48 states, D.C. and Alaska
■ Screen for display settings
Go to “Display”: “MENU” button  “Display”
Turn off screen.
Adjust screen quality.
Adjust screen quality of the rear view
monitor camera.
Change to day mode.
ButtonFunction
“Radio”Display the radio top screen
“Media”Display the media top screen
“Climate”Display the air conditioning control screen ( P. 53)
“Phone”Display the phone top screen
“Connected Navi”*
If a turn-by-turn navigation application has been
downloaded to a connected phone, the application
will be displayed and can be used.
“Info”Display the “Information” screen
“Setup”Display the “Setup” screen
“Display”Display the display settings screen
1
2
3
4

53
Air Conditioning System
■Adjusting the temperature
To adjust the temperature setting, touch and
slide your finger up or down on the sensor.
The temperature setting can also be
adjusted by touching on the sensor.
When the temperature setting is changed, a
buzzer sounds.
If is not pressed, the system will
blow ambient temperature air or heated
air.

54
■Air conditioning control screen
With a Lexus Display Audio
Adjust the left-hand side temperature
setting
Adjust the fan speed setting
Select to set auto mode on/off
Select to set eco mode on/off
Select to set cooling and dehumidifica-
tion function on/off
If the “A/C” indicator is turned off, the
system will blow ambient temperature
air or heated air.
Adjust the temperature for driver and
passenger seats se parately (“DUAL”
mode)
Display the option control screen
Select the air flow mode
Adjust the right-hand side temperature
setting
With a navigation system
Adjust the left-hand side temperature
setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side temperature
setting
Display the option control screen
Select to set automatic mode on/off
Select to set cooling and dehumidifica-
tion function on/off
If the “A/C” indicator is turned off, the
system will blow ambient temperature
air or heated air.
Adjust the temperature for driver and
passenger seats se parately (“DUAL”
mode)
Select to set eco mode on/off
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9

55
■Option control screen
Select on the air conditioning control screen to display the option control
screen. The functions can be switched on and off.
Removing pollen from the air (M icro dust and pollen filter)
■Side display operation screen (veh icles with a navigation system)
Select the air flow mode
Adjust the left-hand side temperature
setting
Adjust the fan speed setting
Adjust the right-hand side temperature
setting
Select to set auto mode on/off
Select to set cooling and dehumidifica-
tion function on/off
If the “A/C” indicator is turned off, the
system will blow ambient temperature
air or heated air.
Adjust the temperature for driver and
passenger seats separately (“DUAL”
mode)
With a Lexus Display Audio With a navigation system
1
1
2
3
4
5
6
7

56
■Using automatic mode
Press the automatic mode button to turn on the airflow and adjust the temperature setting.
■Adjusting the temperature for driv er and passenger seats separately
(“DUAL” mode)
In dual mode, driver and passenger side temp erature settings can be adjusted separately.
To turn on the “DUAL” mode, perfor m any of the following procedures:
● Press or select “DUAL” on the air conditioning control screen.
● Select “DUAL” on the side display operation screen. (vehicles with a navigation system)
● Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.
While in “DUAL” mode, the temperature of the rear air outlets is set at the right-hand side
temperature setting.

61
Info
*: Vehicles with navigation systemClimate (vehicles with navigation system)
*: Only within the possible temperature range of the air co nditioning system
CommandAction
“Destination Assist” *Connects the system to the Lexus response center
“Show Forecast”Displays weather information
“Show Traffic”Displays traffic information
CommandAction
“Turn Climate Control On”Turns air conditioning system on
“Turn Climate Control Off”Turns air conditioning system off
“Warmer”Increases the temperature of the air conditioning sys-
tem
“Cooler”Decreases the temperature of the air conditioning
system
“<#> degrees”Changes the set temperature of the air conditioning
system to <#> degrees
*
Commands relating to operation of the audio/ visual and air conditioning systems can only
be performed when the audio and air conditio ning systems are turned on. Refer to the
“OWNER’S MANUAL” and “NAVIG ATION SYSTEM OWNER’S MANUAL”.
