warning lexus LC500C 2021 Owner's Manual / LEXUS 2021 LC500 CONVERTIBLE OWNER'S MANUAL QUICK GUIDE (OM11518U)

3
LC500_QG_OM11518U_(U)
Parking Brake ...........................................................................................................................29
Pictorial Index ................................................................................................................ ............. 5
Remote Touch ................................................................................................................... .......55
SiriusXM Satellite Radio ... .................................. ........................ ................................ ..........95
Smart Access System with Push-button Start ................................................................. 16
Soft top roof .................................................................................................................. ............ 53
Tire Pressure Warning System.............................................................................................51
Turn Signal Lever .............................................................................................................. ...... 28
USB/AUX Ports .................................................................................................................. ....86
Voice Command System
*
Basic operation ................................................................................................................ ............... 79
Command list ................................................................................................................... .............. 80
Windshield Wipers and Washer ........................................................................................ 39
*: These features may be oper ated by Voice Command (See P.79)

5
LC500_QG_OM11518U_(U)
■Instrument panel
Engine switch .............................................................................................................. P.21
Starting the engine/changing the mode.............................................................. P.21, 22
Emergency stop of the engine ........................................................................................P.23
When the engine will not start ......................................................................................P.102
Warning messages
*
Shift lever .................................................................................................................... P.24
Changing the shift position...............................................................................................P.24
Precautions against towing
*
Meters*
Reading the meters/adjusting the instrument panel lights*
Warning lights/indicator lights .......................................................................................P.97
When the warning lights come on
*
Multi-information display ...................................................................................... P.32
Display.......................................................................................................................................P.32
When the warning messages are displayed
*
Pictorial Index
A
B
C
D

6
LC500_QG_OM11518U_(U)
Parking brake switch ............................................................................................... P.29
Applying/releasing..............................................................................................................P.29
Precautions against winter season
*
Warning buzzer/message*
Turn signal lever ........................................................................................................ P.28
Headlight switch ....................................................................................................... P.36
Headlights/parking lights/tail lights/license plate lights/ daytime
running lights ..........................................................................................................................P.36
Automatic High Beam ....................................................................................................... P.37
Windshield wiper and washer switch ................................................................. P.39
Usage ........................................................................................................................................P.39
Adding washer fluid
*
Warning messages*
Emergency flasher switch*
Hood lock release lever*
Tilt and telescopic steering control switch*
Adjustment*
Driving position memory ................................................................................................... P.19
Air conditioning system .......................................................................................... P.75
Usage .......................................................................................................................... .............. P.76
Rear window defogger ...................................................................................................... P.75
Audio system.............................................................................................................. P.67
Trunk opener main switch
*
*
: Refer to the “OWNER’S MANUAL”.
E
F
G
H
I
J
K
L
M

33
LC500_QG_OM11518U_(U)
Menu icons
Drive information
Select to display various drive data.
Navigation system-linked display
Select to display the following navigation system-linked information.
•Route guidance
• Compass display
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the
meter control switches.
Driving assist system information
Select to display the dynamic radar cr uise control with full-speed range/LKA
(Lane-Keeping Assist) information, when the system is used. (P.41, 42)
Warning message display
Select to display warning messages and me asures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display settings
If a problem is detected in any of the vehicl e’s systems, a warning message is shown on the
multi-information display.

40
LC500_QG_OM11518U_(U)
■PCS (Pre-Collision System)
The pre-collision system uses a radar sensor and front camera to detect vehicles and pedes-
trians in front of your vehicle. When the syst em determines that the possibility of a frontal
collision with a vehicle or pedestrian is high, a warning operates to urge the driver to take
evasive action and the potential brake pressure is increased to help the driver avoid the col-
lision. If the system determines that the possib ility of a frontal collision with a vehicle or
pedestrian is extremely high, the brakes are au tomatically applied to help avoid the collision
or help reduce the impact of the collision.
■LKA (Lane-Keeping Assist)
 P.41
■Automatic High Beam
P.37
■Dynamic radar cruise contro l with full-speed range
P.42
Lexus Safety System +
The Lexus Safety System + consists of the fo llowing drive assist systems and contributes to
a safe and comfortable driving experience:
Drive assist systems of Lexus Safety System +

51
LC500_QG_OM11518U_(U)
The tire pressure detected by the tire pres-
sure warning system can be displayed on
the multi-information display.
The illustration used is intended as an exam-
ple, and may differ from the image that is
actually displayed on the multi-information
display.
Tire Pressure Warning System
Your vehicle is equipped with a tire pressure warning system that uses tire pressure warn-
ing valves and transmitters to detect low tire inflation pressure before serious problems
arise.
The tire inflation pressure display function

52
LC500_QG_OM11518U_(U)
1Turn the engine switch to ON.
2Press or of the meter control switches and select .
3Press or of the meter control switch es and select “Vehicle Settings”, then
press “OK”.
4Press or of the meter control switch es and select “TPWS SET”, then press
“OK”.
5Press or of the meter co ntrol switches and select “Set tire pressure”. Then
press and hold “OK” until the tire pressure warning light starts blinking.
A message is displayed on the multi-infor-
mation display. Also, “--” is displayed for
inflation pressure of each tire on the multi-
information display while the tire pressure
warning system determines the position.
6Drive the vehicle at approximately 25 mph (40 km/h) or more for approximately 10 to
30 minutes.
When initialization is comple te, the inflation pressure of each tire will be displayed on
the multi-information display.
Initializing the tire pressure warning system

What to do if...
97
LC500_QG_OM11518U_(U)
List of Warning/Indicator Lights
Immediately stop the vehicle in a safe pl ace and contact your Lexus dealer. Continu-
ing to drive the vehicle may be dangerous.
(U.S.A.)
Brake system warning light
(Red)
(Canada)
Immediately stop the vehicle in a safe place and contact your Lexus dealer.
Charging system warning lightLow engine oil pressure warn-
ing light
Have the vehicle inspected by your Lexus dealer immediately.
(U.S.A.)Malfunction
indicator lamp
Brake Override System
warning light/Drive-Start
Control warning light
(Canada)
(Flashes)
Brake hold operated indicator
SRS warning light(Flashes)(U.S.A.)Parking brake
indicator
(U.S.A.)
ABS warning light(Flashes)
(Canada)
(Canada)
(Yellow)
Brake system warning light
(Red or
yellow)
Electric power steering
system warning light
(Blinking and then
continu-
ously on)
Tire pressure warning light
(Flashes or
illuminates)PCS warning light
Slip indicator
For further information, refe r to the “OWNER’S MANUAL”.

98
What to do if...
LC500_QG_OM11518U_(U)
Follow the correction procedures.
Low fuel level warning lightMaster warning light
Driver’s and front passenger’s
seat belt reminder light
(Orange)
LKA indicator
Rear passenger’s seat belt
reminder lights
(Illuminates without
blinking)Tire pressure warning light*
Stop and check.
High coolant temperature
warning light
For further information, refe r to the “OWNER’S MANUAL”.

What to do if...
99
LC500_QG_OM11518U_(U)
See the “OWNER’S MANUAL”
Turn signal indicatorPCS warning light
Headlight indicator (U.S.A.)
BSM (Blind Spot Monitor)
outside rear view mirror indi-
cators
Tail light indicator (Canada)BSM (Blind Spot Monitor)
indicator
Headlight high beam indicatorRCTA (Rear Cross Traffic
Alert) indicator
Automatic High Beam
indicatorBrake hold standby indicator
Cruise control indicatorBrake hold operated
indicator
Dynamic radar cruise control
indicatorSecurity indicator
Cruise control “SET” indicatorSmart access system with
push-button start indicator
(White or green)LKA indicatorLow outside temperature
indicator
(Flashes in
orange)LKA indicatorEco Driving Indicator Light
Intuitive parking assist
indicator(U.S.A.)
Parking brake
indicator
(Flashes)
Slip indicator(Canada)
VSC OFF indicator
(U.S.A.)
“AIR BAG ON/
OFF” indicator
For further information, refe r to the “OWNER’S MANUAL”.
