service indicator lexus LC500h 2019 Owner's Manual / LEXUS 2019 LC 500,LC 500H OWNER'S MANUAL (OM11471U)

2TABLE OF CONTENTS
For your information ......................................6
Reading this manual .................................... 10
How to search ................................................. 11
Pictorial index ................................................. 12
1-1. For safe use Before driving .................................... 22
For safe driving.................................. 23
Seat belts ............................................. 24
SRS airbags ....................................... 28
Pop Up Hood ................................... 36
Front passenger occupant classifi- cation system ................................. 38
Exhaust gas precautions ............... 42
1-2. Child safety Riding with children........................ 43
Child restraint systems ................. 43
1-3. Lexus Enform Lexus Enform Safety Connect .. 54
Lexus Enform Remote .................. 59
Lexus Enform Service Connect 60
1-4. Hybrid system Hybrid system fe atures (LC500h)
................................................................ 61
Hybrid system precautions (LC500h) ....................................... 64
1-5. Theft deterrent system Engine immobilize r system bilizer system> ............................... 69
Alarm...................................................... 71
Theft prevention labels (U.S.A.). 722-1. Instrument cluster
Warning lights an d indicators.....74
Gauges and meters ....................... 80
Multi-information display ............. 84
Head-up display .............................. 90
Energy monitor/consumption screen ................................................ 95
3-1. Key information Keys .................................................... 102
3-2. Opening, closing and locking the doors and trunk
Doors ................................................. 106
Trunk ................................................... 110
Smart access system with push-but- ton start ............................................ 113
3-3. Adjusting the seats Front seats........................................ 120
Driving position memory ............ 122
Head restraints ............................... 125
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................................ 127
Inside rear view mirror ............... 128
Outside rear view mirrors.......... 129
3-5. Opening and closing the windows Power windows .............................. 132
1For safety and security
2Vehicle status information and
indicators
3Before driving

541-3. Lexus Enform
1-3.Lexus Enform
*:If equipped
Vehicles without sunshade“SOS” button
LED light indicators
Microphone
Vehicles with sunshade“SOS” button
LED light indicators
Microphone
Lexus Enform Safety Con-
nect*
Safety Connect is a subscription-
based telematics service that uses
Global Positioning System (GPS)
data and embedded cellular tech-
nology to provide safety and secu-
rity features to subscribers. Safety
Connect is supported by Lexus’
designated response center, which
operates 24 hours per day, 7 days
per week.
Safety Connect service is available
by subscription on select, telemat-
ics hardware-equipped vehicles.
By using the Safety Connect ser-
vice, you are agreeing to be bound
by the Telematics Subscription Ser-
vice Agreement and its Terms and
Conditions, as in effect and
amended from time to time, a cur-
rent copy of which is available at
Lexus.com. All use of the Safety
Connect service is subject to such
then-applicable Terms and Condi-
tions.
System components
A
B
C
A
B
C

561-3. Lexus Enform
*: U.S. Patent No. 7,508,298 B2
Stolen Vehicle Location
Helps drivers in the event of vehicle theft.
(
P.57)
 Emergency Assistance Button
(“SOS”)
Connects drivers to response-center sup-
port. ( 
P.57)
Enhanced Roadside Assistance
Provides drivers various on-road assis-
tance. ( 
P.57)
After you have signed the Telematics
Subscription Service Agreement and
are enrolled, you can begin receiving
services.
A variety of subscription terms is avail-
able for purchase. Contact your Lexus
dealer, call the following or push the
“SOS” button in your vehicle for fur-
ther subscription details.
• The United States
1-800-25-LEXUS (1-800-255-3987)
• Canada
1-800-26-LEXUS (1-800-265-3987)
•Puerto Rico
1-877-539-8777
■Safety Connect Serv ices Information
●Phone calls using the vehicles Blue-
tooth® technology will not be possible
during Safety Connect.
●Safety Connect is available beginning Fall
2009 on select Lexus models (in the
contiguous United States only). Contact
with the Safety Connect response center
is dependent upon the telematics device
being in operative co ndition, cellular con- nection availability,
and GPS satellite sig-
nal reception, which ca n limit the ability to
reach the response center or receive
emergency service support. Enrollment
and Telematics Subscription Service
Agreement required. A variety of sub-
scription terms is available; charges vary
by subscription term selected and loca-
tion.
●Automatic Collision Notification, Emer-
gency Assistance and Stolen Vehicle
Location will function in the United
States, including Hawaii and Alaska,
Puerto Rico and in Canada, and
Enhanced Roadside Assistance will func-
tion in the United States, Puerto Rico and
in Canada.
●Automatic Collision Notification, Emer-
gency Assistance, Stolen Vehicle and
Enhanced Road Assistance will not func-
tion in the United St ates Virgin Islands.
For vehicles first sold in the USVI, no
Safety Connect services will function in
and outside the United States Virgin
Islands.
●Safety Connect services are not subject
to section 255 of the Telecommunica-
tions Act and the device is not TTY com-
patible.
■Languages
The Safety Connect re sponse center will
offer support in mult iple languages. The
Safety Connect system will offer voice
prompts in English, Spanish, and French.
Please indicate your language of choice
when enrolling.
■When contacting the response center
You may be unable to contact the response
center if the network is busy.
When the engine switch switch> is turned to IGNITION ON
mode , the red indicator
light comes on for 2 seconds then turns
off. Afterward, the green indicator light
Subscription
Safety Connect LED light Indi-
cators

571-3. Lexus Enform
1
For safety and security
comes on, indicating that the service is
active.
The following indicator light patterns
indicate specific system usage condi-
tions:
Green indicator light on = Active
service
 Green indicator light flashing =
Safety Connect call in process
 Red indicator light (except at vehi-
cle start-up) = System malfunction
(contact your Lexus dealer)
 No indicator light (off) = Safety
Connect service not active
■Automatic Collision Notification
In case of either airbag deployment or
severe rear-end collision, the system is
designed to automatically call the
response center. The responding agent
receives the vehicle’s location and
attempts to speak with the vehicle
occupants to assess the level of emer-
gency. If the occupants are unable to
communicate, the ag ent automatically
treats the call as an emergency, con-
tacts the nearest emergency services
provider to describe the situation, and
requests that assistance be sent to the
location.
■Stolen Vehicle Location
If your vehicle is stolen, Safety Connect
can work with local authorities to assist
them in locating and recovering the
vehicle. After filing a police report, call
the Safety Connect response center at 1-800-25-LEXUS (1-800-255-
3987) in the United States, 1-877-
539-8777 in Puerto Rico or 1-800-
265-3987 in Canada, and follow the
prompts for Safety Connect to initiate
this service.
In addition to assisting law enforce-
ment with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle
location data may, under certain cir-
cumstances, be shared with third par-
ties to locate your vehicle. Further
information is available at Lexus.com.
■Emergency Assistance Button
(“SOS”)
In the event of an emergency on the
road, push the “SOS” button to reach
the Safety Connect response center.
The answering agent will determine
your vehicle’s location, assess the
emergency, and dispatch the neces-
sary assistance required.
If you accidentally press the “SOS” button,
tell the response-center agent that you are
not experiencing an emergency.
■Enhanced Roadside Assistance
Enhanced Roadside Assistance adds
GPS data to the already included war-
ranty-based Lexus roadside service.
Subscribers can press the “SOS” but-
ton to reach a Safety Connect
response-center agent, who can help
with a wide range of needs, such as:
towing, flat tire, fuel delivery, etc. For a
description of the Roadside Assistance
services and their limitations, please
see the Safety Connect Terms and
Conditions, which are available at
Safety Connect services

2876-2. Maintenance
6
Maintenance and care
The OBD system determines that a
problem exists somewhere in the emis-
sion control system. Your vehicle may
not pass the I/M test and may need to
be repaired. Contact your Lexus
dealer to service the vehicle.
When the 12-volt battery is discon-
nected or discharged
Readiness codes that are set during
ordinary driving are erased.
Also, depending on your driving
habits, the readiness codes may not
be completely set.
 When the fuel tank cap is loose
The malfunction indicator lamp
comes on indicating a temporary
malfunction and your vehicle may
not pass the I/M test. The error code in the OBD system will
not be cleared unless the vehicle is
driven 40 or more times.
Contact your Lexus dealer to prepare
the vehicle for re-testing.
Emission inspection and
maintenance (I/M) pro-
grams
Some states have vehicle emission
inspection programs which include
OBD (On Board Diagnostics)
checks. The OBD system monitors
the operation of the emission con-
trol system.
If the malfunction indicator lamp
comes on
Your vehicle may not pass the
I/M test in the following situa-
tions:
When the malfunction indicator
lamp still remains on after sev-
eral driving trips
If your vehicle does not pass the
I/M test

3818-1. Specifications
8
Vehicle specifications
■Gasoline quality
In very few cases, driveability problems may
be caused by the brand of gasoline you are
using. If driveability problems persist, try
changing the brand of gasoline. If this does
not correct the problem, consult your Lexus
dealer.
■Recommendation of the use of gasoline
containing detergent additives
●Lexus recommends the use of gasoline
that contains detergent additives to avoid
the build-up of engine deposits.
●All gasoline sold in the U.S.A. contains
minimum detergent additives to clean
and/or keep clean intake systems, per
EPA’s lowest additive s concentration pro-
gram.
●Lexus strongly recommends the use of
Top Tier Detergent Gasoline. For more
information on Top Tier Detergent Gaso-
line and a list of marketers, please go to
the official websit e www.toptiergas.com.
■Recommendation of the use of low
emissions gasoline
Gasolines containing oxygenates such as
ethers and ethanol, as well as reformulated gasolines, are available in some cities.
These fuels are typically acceptable for use,
providing they meet other fuel require-
ments.
Lexus recommends these fuels, since the
formulations allow for reduced vehicle
emissions.
■Non-recommendation of the use of
blended gasoline
●Use only gasoline containing up to 15%
ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 15% etha-
nol, including from
any pump labeled
E30 (30% ethanol [ ]), E50 (50%
ethanol [ ]), E85 (85% ethanol [ ])
(which are only some examples of fuel
containing more than 15% ethanol).
●If you use gasohol in your vehicle, be sure
that it has an octane rating no lower than
91.
●Lexus does not recommend the use of
gasoline containing methanol.
■Non-recommendation of the use of gas-
oline containing MMT
Some gasoline contains an octane enhanc-
ing additive called MMT (Methylcyclopen-
tadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gas-
oline that contains MMT. If fuel containing
MMT is used, your emission control system
may be adversely affected.
The malfunction indicator lamp on the
instrument cluster may come on. If this hap-
pens, contact your Lexus dealer for service.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knock-
Fuel information
You must only use unleaded gaso-
line.
Select premium unleaded gasoline
with an octane rating of 91
(Research Octane Number 96) or
higher required for optimum
engine performance and fuel econ-
omy. If the octane ra ting is less than
91, damage to the engine may
occur and may void the vehicle war-
ranty.
At minimum, the gasoline you use
should meet the specifications of
ASTM D4814 in the U.S.A..
A
BC

428Alphabetical index
Child restraint system installation ......... 44
Cleaning and maintaining the seat belt..........................................................................277
Emergency Locking Retractor .............. 26
How to wear your seat belt ..................... 25
How your child should wear the seat belt ............................................................................ 25
Pregnant women, proper seat belt use .............................................................................24
Reminder light and buzzer ................... 339
Seat belt extender ........................................ 25
Seat belt guide ............................................... 26
Seat belt pretensioners ...............................27
SRS warning light ...................................... 336
Seat heaters .................... ............................... 255
Seating capacity.............................................144
Seat lights........................................................ 258
Seat position memory.................................. 122
Seats....................................................................120 Adjustment precautions ...........................120
Adjustment......................................................120
Child seats/child restraint system installa-tion .................................................................... 43
Cleaning..........................................................277
Driving position memory......................... 122
Head restraints .............................................125
Jam protection function..............................121
Properly sitting in the seat .........................23
Seat heaters .................................................. 255
Seat position memory ............................... 122
Seat ventilators............................................ 255
Seat ventilators .............. ............................... 255
Sensor Automatic headlight system................... 173
Automatic High Beam system.............. 176
Inside rear view mirror..............................128
Intuitive parking assist................................ 214
LKA (Lane-Keeping Assist)...................196
Radar sensor......................................185, 222
Rain-sensing windshield wipers........... 179
Service plug ...................................................... 64
Service reminder message ..................... 283 Shift lever
Automatic transmission ........................... 155
Hybrid transmission..................................... 161
Shift lever light .............................................. 258
Shift position and gear position ................ 80
Side airbags ...................................................... 28
Side marker lights.......................................... 173 Light switch .....................................................173
Replacing light bulbs ................................ 324
Side mirrors .....................................................129 Adjustment ......................................................129
BSM (Blind Spot Monitor)....................220
Folding.............................................................. 130
Linked mirror functi on when reversing
........................................................................... 130
Mirror position memory ........................... 122
Side turn signal lights ................................... 167 Replacing light bulbs ................................ 324
Turn signal lever ...........................................167
Side windows ..................................................132
Slip indicator .................................................. 337
Smart access system with push-button start.................................................................... 113Antenna location ........................................... 113
Entry functions .............................................. 106
Starting the engine ..................................... 146
Starting the hybrid system ...................... 149
Snow mode ........................................... 159, 165
Snow tires ....................................................... 238
Spark plug ...................................................... 376
Specifications ................................................ 372
Speedometer ................................................... 80
Sport mode ......................................................213
Steering lock Column lock release ....................... 147, 150
Steering lock system warning message................................................................. 147, 150
Steering wheel ................................................ 127 Adjustment ...................................................... 127
Auto tilt away.................................................. 127
Heated steering wheel ............................255
Steering wheel position memory......... 122
