SWITCHES
21 If further defrosting or defogging is desired, simply actuate
the switch again. When the surface has cleared, push the
switch once again to turn the defogger off. Continuous use
may cause the battery to discharge, especially during
stop±and±go driving. The defogger is not designed to dry
rain water or to melt snow.
If the outside rear view mirrors are heavily coated with ice,
use a spray de±icer before operating the switch.
NOTICE
When cleaning the inside of the rear window, be
careful not to scratch or damage the heater wires.
To prevent the battery from being discharged, do
not operate the defogger continuously longer than
necessary.
POWER WINDOW SWITCHES
For driver's window
For front passenger's window
For left rear window
For right rear window
To raise or lower the windows, use the switch on each
door. The passengers' windows can also be controlled
by the switches on the driver's door.
The ignition key must be in the ªONº position. However, even
if the ignition key is turned to the ªACCº or ªLOCKº position,
the window can be operated until any of the doors is opened
(or for about 45 seconds).
Page 9 of 10
SWITCHES
23
Operating the driver's window from outside
the vehicle
The driver's window can be raised or lowered using an
ignition key.
Insert the ignition key into the key hole.
To raise the window: Turn the key in the locking direction
and hold it for a few seconds.
To lower the window: Turn the key in the unlocking
direction and hold it for a few seconds.
CAUTION!
To avoid serious personal injury, you must do the
following.
Always make sure the head, hands and other parts
of the body of all occupants are kept completely
inside the vehicle before you close the power
windows. If someone's neck, head or hands gets
caught in a closing window, it could result in a
serious injury. When anyone closes the power
windows, be sure that they operate the windows
safely.
When small children are in the vehicle, never let
them use the power window switches without
supervision. Use the window lock switch to prevent
them from making unexpected use of the switches.
Never leave small children alone in the vehicle,
especially with the ignition key still inserted. They
could use the power window switches and get
trapped in a window. Unattended children can
become involved in serious accidents.
Page 10 of 10
SWITCHES
24
EMERGENCY FLASHER SWITCH
To turn on the emergency flashers, push the switch.
All the turn signal lights will flash. The emergency flashers
will work with the engine running or off and with or without the
ignition key.
Turn on the emergency flashers to warn other drivers if you
must stop your vehicle where it might be a traffic hazard.
Always pull your vehicle as far off the road as possible.
The turn signal light switch will not work when the emergency
flashers are in operation.
NOTICE
To prevent the battery from being discharged, do not
leave the switch on longer than necessary when the
engine is not running.
SEAT HEATER SWITCHES
The seat heater has two switches one marked ªLº (for
the left seat) and the other marked ªRº (for the right
seat). Push these switches to turn the respective seat
heater on, and push the switches again to turn them off.
The ignition key must be in the ªONº position.
NOTICE
To prevent the battery from being discharged, turn
the switches on only when the engine is running.
