odometer lexus LS400 1998 Audio System / LEXUS 1998 LS400 OWNER'S MANUAL (OM50498U)

For detailed information, refer to the description given in each section.
PICTORIAL INDEX
ix
Page
1
Engine coolant temperature gauge 34
. . . . . . . . . . . . . . . . .
2 Tachometer 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
3 Turn signal indicator light 24
. . . . . . . . . . . . . . . . . . . . . . . .
4 Headlight indicator light 22
. . . . . . . . . . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 24
. . . . . . . . . . . . . . . .
6 Automatic transmission indicator lights 160
. . . . . . . . . . . .
7 Fuel gauge 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
8 Low fuel level warning light 40
. . . . . . . . . . . . . . . . . . . . . .
9 Cruise control indicator light 168
. . . . . . . . . . . . . . . . . . . . .
10 Height control indicator light 172
. . . . . . . . . . . . . . . . . . . .
11 Power mode indicator light 167
. . . . . . . . . . . . . . . . . . . . . .
12 Snow mode indicator light 167
. . . . . . . . . . . . . . . . . . . . . . .
13 Antilock brake system warning light 39
. . . . . . . . . . . . . . . Page
14 Vehicle skid control system off
indicator light 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15 Malfunction indicator lamp 39
. . . . . . . . . . . . . . . . . . . . . . .
16 Slip indicator light 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17 Multi information display 41
. . . . . . . . . . . . . . . . . . . . . . . .
18 Odometer and trip meter 36
. . . . . . . . . . . . . . . . . . . . . . . . .
19 Brake system warning light 37
. . . . . . . . . . . . . . . . . . . . . . .
20 SRS warning light 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21 Open door warning light 39
. . . . . . . . . . . . . . . . . . . . . . . . .
22 Driver’s seat belt reminder light 38
. . . . . . . . . . . . . . . . . . .
23 Discharge warning light 39
. . . . . . . . . . . . . . . . . . . . . . . . . .
24 Instrument panel light control 46
. . . . . . . . . . . . . . . . . . . . .
25 ODO/TRIP RESET button 36
. . . . . . . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each section.
PICTORIAL INDEX
xi
Page
1
Engine coolant temperature gauge 34
. . . . . . . . . . . . . . . . .
2 Tachometer 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
3 Turn signal indicator light 24
. . . . . . . . . . . . . . . . . . . . . . . .
4 Tail light indicator light 22
. . . . . . . . . . . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 24
. . . . . . . . . . . . . . . .
6 Automatic transmission indicator lights 160
. . . . . . . . . . . .
7 Fuel gauge 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
8 Low fuel level warning light 40
. . . . . . . . . . . . . . . . . . . . . .
9 Cruise control indicator light 168
. . . . . . . . . . . . . . . . . . . . .
10 Power mode indicator light 167
. . . . . . . . . . . . . . . . . . . . . .
11 Snow mode indicator light 167
. . . . . . . . . . . . . . . . . . . . . . .
12 Antilock brake system warning light 39
. . . . . . . . . . . . . . . Page
13 Vehicle skid control system
off indicator light 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14 Malfunction indicator lamp 39
. . . . . . . . . . . . . . . . . . . . . . .
15 Slip indicator light 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16 Multi information display 41
. . . . . . . . . . . . . . . . . . . . . . . .
17 Odometer and trip meter 36
. . . . . . . . . . . . . . . . . . . . . . . . .
18 Brake system warning light 37
. . . . . . . . . . . . . . . . . . . . . . .
19 SRS warning light 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20 Open door warning light 39
. . . . . . . . . . . . . . . . . . . . . . . . .
21 Driver’s seat belt reminder light 38
. . . . . . . . . . . . . . . . . . .
22 Discharge warning light 39
. . . . . . . . . . . . . . . . . . . . . . . . . .
23 Instrument panel light control 46
. . . . . . . . . . . . . . . . . . . . .
24 ODO/TRIP RESET button 46
. . . . . . . . . . . . . . . . . . . . . . . .

SECTION 1 3
33
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder
indicators
Fuel gauge 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and trip meter 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 36. . . . . . . . . . . . . . . . .
Multi information display 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GAUGES, METERS AND SERVICE REMINDER INDICATORS
36
ODOMETER AND TRIP METER
13L0041
This meter displays the odometer and two trip meters. To
change the mode indication, push the ”ODO/TRIP” button.
The odometer records the total distance the vehicle has been
driven. The twin trip meter records two different distances
independently.
For example, you can use one meter to calculate the fuel economy
and the other to measure the distance on each trip.
To change the trip meter indication from one trip to the other,
push the ”ODO/TRIP” button. To set the A trip meter to zero,
display the A meter reading, then push the ”RESET” button.
The same applies for the B trip meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS
AND WARNING BUZZERS
IF THIS INDICATOR
OR BUZZER COMES
ON ...DO THIS.
(a) If parking brake is off,
stop and check.
(b) Fasten driver’s seat belt.

(Indicator and buzzer)
(c) Fasten front passenger’s
seat belt.
(Under the center vent)
(d) Take vehicle to Lexus
dealer immediately.
(e) Stop and check.

or

CHASSIS
245
Tire selection
When replacing a tire, use only the same size and construction
as originally installed and with the same or greater load capacity.
Using any other size or type of tire may seriously affect handling,
ride, speedometer/odometer calibration, ground clearance, and
clearance between the body and tires or snow chains.
Do not mix radial, belted, or conventional tires on your vehicle.
Do not use tires or wheels other than the manufacturer’s
recommended size.
It can cause dangerous handling characteristics, resulting in loss of
control. If you need to change from conventional tires to radial tires
or vice versa, replace them as a set.
INSTALLING SNOW TIRES AND
CHAINS
When to use snow tires or chains
Snow tires or chains are recommended when driving on snow or
ice.
On wet or dry roads, conventional or radial tires provide better
traction than snow or studded tires.
Snow tire selection
If you need snow tires, select the same size, construction and load
capacity as the original tires on your Lexus.
Do not use tires other than stated above. Since your vehicle has
radial tires as original equipment, make sure your snow tires also
have radial construction. Do not install studded tires without first
checking local regulations for possible restrictions.
Snow tire installation
Snow tires should be installed on all wheels.
Installing snow tires on the rear wheels only can lead to an excessive
difference in road grip capability between the front and rear tires
which could cause loss of vehicle control.

CHASSIS
247
REPLACING WHEELS
When to replace your wheels
If you have wheel damage such as bending, cracks or heavy
corrosion, the wheel should be replaced.
If you fail to replace damaged wheels, a tire may slip off a wheel or
they may cause loss of handling control.
Replacement with used wheels is not recommended as they may
have been subjected to rough treatment or high mileage and could
fail without warning. Also, bent wheels which have been
straightened may have hidden structural damage and therefore
should not be used. Never use an inner tube in a leaking wheel which
is designed for a tubeless tire.
Wheel selection
When replacing wheels, care should be taken to ensure that they
are equivalent to those removed in load capacity, diameter, rim
width, and offset.
Correct replacement wheels are available at your Lexus dealer.
A wheel of a different size or type may adversely affect handling,
wheel and bearing life, brake cooling, speedometer/odometer
calibration, stopping ability, headlight aim, bumper height, vehicle
ground clearance, and tire or snow chain clearance to the body and
chassis.
ALUMINUM WHEEL
PRECAUTIONS
After driving your vehicle the first 1600 km (1000 miles), check
that the wheel nuts are tight.
If you have rotated, repaired, or changed your tires, check that the
wheel nuts are still tight after driving 1600 km (1000 miles).
When using tire chains, be careful not to damage the aluminum
wheels.
Use only the Lexus wheel nuts and wrench designed for your
aluminum wheels.
When balancing your wheels, use only Lexus balance weights or
equivalent and a plastic or rubber hammer.
As with any wheel, periodically check your aluminum wheels for
damage. If damaged, replace immediately.
SUSPENSION AND CHASSIS
CAUTION
Do not modify the suspension/chassis with lift kits, spacers,
springs, etc. It can cause dangerous handling characteristics,
resulting in loss of control.

INDEX (H L)
281
H
Hazard switch 31. . . . . . . . . . . . . . . . . . . . . . . . .
Headlight cleaner switch 27. . . . . . . . . . . . . . . .
Headlight switch 5, 22. . . . . . . . . . . . . . . . . . . .
Head restraints 73. . . . . . . . . . . . . . . . . . . . . . . .
Height control system 171 . . . . . . . . . . . . . . . . . .
High speed operation
During breakin 181. . . . . . . . . . . . . . . . . . . .
Hood release, Engine 62 . . . . . . . . . . . . . . . . . . .
How to start the engine 159. . . . . . . . . . . . . . . .
I
Identification
Engine 219. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle 219. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch 157. . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light 50. . . . . . . . . . . . . . . . . . . .
Instrument panel
Brightness control 46. . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 52. . . . . . . . . . . .
Clock 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 34. . . . . . . . . . . . . . . . . . . . . . . . . .
Multi information display 41. . . . . . . . . . . . . .
Odometer 36. . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature display 51. . . . . . . . . . . .
Tachometer 35. . . . . . . . . . . . . . . . . . . . . . . . .
Trip meter 36. . . . . . . . . . . . . . . . . . . . . . . . . .
Twin trip meter 36. . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 79. . . . . . . . . . . . . . . . . .
Instrument panel light control 46. . . . . . . . . . . .
Instrument panel overview Pictorial index. . . . . .
Interior lights 49. . . . . . . . . . . . . . . . . . . . . . . . .
J
Jack, location 198. . . . . . . . . . . . . . . . . . . . . . . .
Jump starting 194. . . . . . . . . . . . . . . . . . . . . . . .
K
Keys 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key reminder buzzer 40 . . . . . . . . . . . . . . . . . . .
L
Light bulbs, Replacing 264. . . . . . . . . . . . . . . . .
Lock
Doors 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering column 157. . . . . . . . . . . . . . . . . . . .
Trunk lid 63. . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid opener 64. . . . . . . . . . . . . . . . . . . . .
Low fuel level warning light 34. . . . . . . . . . . . .
Lower vent 131. . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions 59. . . . . . . . . . . .

INDEX (M Q)
282
M
Maintenance
Doityourself maintenance 221. . . . . . . . . . .
Does your vehicle need repairing? 217. . . . . .
General maintenance 214
Maintenance requirements 213. . . . . . . . . . . .
Parts and tools 222. . . . . . . . . . . . . . . . . . . . . .
Where to go for service? 213. . . . . . . . . . . . . .
Malfunction indicator lamp 39. . . . . . . . . . . . . .
Multi information display 41. . . . . . . . . . . . . . .
Maximum allowable speed 164. . . . . . . . . . . . .
Mirrors
Antiglare inside rear view 79. . . . . . . . . . . . .
Folding rear view 79. . . . . . . . . . . . . . . . . . . .
Outside rear view 77. . . . . . . . . . . . . . . . . . . .
Power rear view 78. . . . . . . . . . . . . . . . . . . . . .
Vanity 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon roof 66. . . . . . . . . . . . . . . . . . . . . . . . . . .
MTBE 228. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
N
New vehicle breakin 181
O
Odometer 36. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil
Checking the engine oil 230. . . . . . . . . . . . . . .
Consumption 229. . . . . . . . . . . . . . . . . . . . . . .
Power steering 240. . . . . . . . . . . . . . . . . . . . . .
Viscosity and grade 232. . . . . . . . . . . . . . . . . .
Opener
Trunk lid 63. . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel filler door 65. . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 181. . . . . . . . . . .
Outside rear view mirrors 77. . . . . . . . . . . . . . .
Overheating, Engine 196 . . . . . . . . . . . . . . . . . .
Overview
Engine compartment 220
P
Parking brake
Operation 158. . . . . . . . . . . . . . . . . . . . . . . . . .
Reminder light 37. . . . . . . . . . . . . . . . . . . . . . .
Parts 222. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights 50. . . . . . . . . . . . . . . . . . . . . . . .
Polishing 271. . . . . . . . . . . . . . . . . . . . . . . . . . .
Power door locks 19. . . . . . . . . . . . . . . . . . . . . .
Power outlet 53. . . . . . . . . . . . . . . . . . . . . . . . . .
Power rear view mirror control 78. . . . . . . . . . .
Power steering fluid level 240. . . . . . . . . . . . . .
Power window switches 28. . . . . . . . . . . . . . . . .
Protecting your Lexus from corrosion 270. . . . .
Q
Quick index Back cover. . . . . . . . . . . . . . . . . . .
