ENGINE
230Failure to check the oil level regularly could lead to serious
engine trouble due to insufficient oil.
For detailed information on oil level check, see ”Checking the
engine oil level” on page 230.
USED ENGINE OIL
CAUTION
Used engine oil contains potentially harmful contaminants
which may cause skin disorders such as inflammation or
skin cancer, so care should be taken to avoid prolonged and
repeated contact with it. To remove used engine oil from
your skin, wash thoroughly with soap and water.
Do not leave used oil within the reach of children.
Dispose of used oil and used oil filters only in a safe and
acceptable manner. Do not dispose of used oil and used oil
filters in household trash, in sewers or onto the ground.
Call your Lexus dealer or a service station for information
concerning recycling or disposal.
CHECKING THE ENGINE OIL
LEVEL
62L004-4
With the engine at operating temperature and turned off, check
the oil level on the dipstick.
1. To get a true reading, the vehicle should be on a level spot. After
turning off the engine, wait a few minutes for the oil to drain back
into the bottom of the engine.
2. Pull out the dipstick, and wipe it clean with a rag.
3. Reinsert the dipstick and push it in as far as it will go, or the
reading will not be correct.

ENGINE
231
62L002-1
1
Add oil 2
O.K. 3
Too full
4. Pull the dipstick out and look at the oil level on the end. If it is
between the full line (
5
) and the low line ( 4
), it is O.K.
62L003-3
If the oil level is below or only slightly above the low line, add
engine oil of the same type as already in the engine.Remove the oil filler cap and add engine oil a little at a time, checking
the dipstick. The approximate quantity of oil needed to fill between
the low line and the full line on the dipstick is indicated below for
reference.
When the level reaches within the correct range, return the filler cap
and turn the cap clockwise until you hear a click.
Oil quantity. L (qt., lmp. qt.) 1.5 (1.6, 1.3)
NOTICE
Avoid overfilling, or the engine could be damaged. Check the oil
level on the dipstick once again after adding the oil.

ENGINE
233
CHECKING THE ENGINE
COOLANT LEVEL
62L007-2
1
Reservoir cap 2
Upper line 3
Lower line
Park the vehicle at a level spot and look at the seethrough
coolant reservoir when the engine is cool. The coolant level is
satisfactory if it is between the upper and lower lines on the tank.
If the level is low, add ethyleneglycol type coolant.
The coolant level in the reservoir will vary with engine coolant
temperature. However, if the level is on or below the lower line, add
coolant to bring the level up to the upper line.
Use only ethyleneglycol type coolant. It will prevent freezing and
corrosion. Neither supplemental inhibitors nor additives are needed
nor recommended. (For information on ethyleneglycol coolant,
see also ”Engine coolant selection” described below.)If the coolant level drops within a short time after replenishing, there
may be a leak in the system. Visually check the radiator, hoses,
reservoir cap, drain cock and water pump.
If you can find no leak, have your Lexus dealer test the cap pressure
and check for leaks in the cooling system.
CAUTION
To prevent burning yourself, do not remove the reservoir cap
when the engine is hot.
Engine coolant selection
Your coolant must contain ethyleneglycol antifreeze. In addition
to preventing freezing and subsequent damage to the engine, this
will also prevent corrosion. Further supplemental inhibitors or
additives are neither needed nor recommended.
Read the antifreeze container for information on freeze protection.
Follow the manufacturer’s directions for how much to mix with
water. The total capacity of the cooling system is given on page 226.
We recommend 50% solution be used for your Lexus, or a sufficient
quantity to provide protection to about 35C (31F).
NOTICE
Do not use alcohol type antifreeze or plain water alone.

CHASSIS
240
CHECKING POWER STEERING
FLUID
63L0021
Check the fluid level on the dipstick. If necessary, add automatic
transmission fluid DEXRONII or III.
If the vehicle has been driven around 80 km/h (50 mph) for 20
minutes (a little more in frigid temperatures), the fluid is hot (60C
8 0C or 140F 175F). You may also check the level when the
fluid is cold (about room temperature, 10C 30C or 50F 85F)
if the engine has not been run for about five hours.
63L0031
1
If cold O.K. 2
If hot O.K. 3
Add fluid
1. Clean all dirt off the reservoir.
2. Remove the filler cap by turning it counterclockwise and wipe the
dipstick clean.
3. Reinstall the filler cap.
4. Remove the filler cap again and look at the fluid level. If the fluid
is cold, the level should be in the ”COLD” range on the dipstick.
Similarly, if it is hot, the fluid level should be in the ”HOT” range.
If the level is at the low side of either range, add automatic
transmission fluid DEXRON
II or III to bring the level within the
range.
5. After replacing the filler cap, visually check the steering box case,
vane pump and hose connections for leaks or damage.

ELECTRICAL COMPONENTS
254
Checking battery exterior
64L009
1
Terminals 2
Holddown clamp
Check the battery for corroded or loose connections, cracks, or
loose holddown clamps.
1. If the battery is corroded, wash it off with a solution of warm
water and baking soda. Coat the terminals with grease to prevent
further corrosion.
2. If the connections are loose, tighten the clamp bolts but do not
overtighten.
3. Tighten the holddown clamp only enough to keep the battery
firmly in place. Overtightening may damage the battery case.
NOTICE
Make sure the engine and all accessories are turned off
before performing maintenance.
When checking the battery, remove the ground cable first and
reinstall it last.
Be careful not to cause a short circuit with tools.
Take care no solution gets into the battery when washing it.

ELECTRICAL COMPONENTS
257
Adding distilled water
(Maintenance type battery only)
64L062
1
Low 2
O.K.
1. Remove the vent plugs.
2. Add distilled water to cells needing fluid.
If the side of your battery is covered, check the water level by looking
down directly above the cell as illustrated above.
3. Retighten the vent plugs securely.
NOTICE
Do not overfill the cells. Excess electrolyte could squirt out
of the battery during heavy charging, causing corrosion or
damage.
Use a cover on the battery for longer life.
BATTERY RECHARGING
PRECAUTIONS
During recharging, the battery is producing hydrogen gas.
Therefore, before recharging:
1. Maintenance type batteries Remove the vent plugs.
2. If recharging with the battery installed on the vehicle, be sure to
disconnect the ground cable.
3. Make sure the power switch on the recharger is off when
connecting the charger cables to the battery and when disconnecting
them.
CAUTION
Always charge the battery in an unconfined area. Do not
charge the battery in a garage or closed room where there
is not sufficient ventilation.
Nonmaintenance batteries: Only do a slow charge (5 A or
less). Charging at a quicker rate is dangerous. The battery
may explode causing personal injuries.
Maintenance type batteries: Be sure to remove the vent
plugs before recharging.
NOTICE
Never recharge the battery while the engine is running. Also,
make sure all accessories are turned off.

ELECTRICAL COMPONENTS
258
CHECKING AND REPLACING THE
BLADE TYPE FUSES
64L011-1
Driver’s side instrument panel
64L012-2
Engine compartment 1
Spare fuses 2
Pullout tool
1. Turn the ignition switch off and open the fuse box lid.Determine which fuse may be causing the problem. The lid of the
fuse box shows the name of the circuit for each fuse.
64L013
2. Make sure the inoperative component is turned off. Pull the
suspected fuse straight out with the pullout tool and check it.
If it has blown, push a new fuse into the clips.

ELECTRICAL COMPONENTS
261
ADDING WASHER FLUID
64L017
If the washer tank becomes nearly empty, add washer fluid.
You may use plain water as washer fluid. However, in cold areas
where temperatures range below the freezing point, use washer fluid
containing antifreeze. This product is available at your Lexus dealer
and most auto parts stores. Follow the manufacturer’s directions for
how much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it
may damage your vehicle’s paint.
CHECKING THE HEADLIGHT AIM
(Vehicles with discharge headlight only)
64L0732
1
Adjusting bolt (vertical movement)
2
Beam angle gauge and adjusting bolt
(horizontal movement)
Before checking the headlight aim:
1. Be sure that the body around the headlight is not deformed.
2. Park the vehicle on a level spot.
3. The driver gets into the driver’s seat and puts the vehicle in a state
readying for a driving (with a full tank).
4. Bounce the vehicle several times.

INDEX (A C)
278
A
”ABS” warning light 178
Adding washer fluid 261. . . . . . . . . . . . . . . . . . .
Adjustment
Driver’s seat lumbar support 73. . . . . . . . . . . .
Front seat cushion angle and height 72. . . . . .
Front seat position 71. . . . . . . . . . . . . . . . . . . .
Front seatback angle 72
Seat belts 80. . . . . . . . . . . . . . . . . . . . . . . . . . .
Airbags (SRS) 86. . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 247. . . . . . . . . . .
Antifreeze 233. . . . . . . . . . . . . . . . . . . . . . . . . . .
Antilock brake system 177. . . . . . . . . . . . . . . .
Antitheft steering column lock 157. . . . . . . . . .
Appearance care
Cleaning the interior 273
Protecting your Lexus from corrosion 270. . .
Washing and waxing 271
Audio system 132. . . . . . . . . . . . . . . . . . . . . . . .
Automatic air conditioning controls 121. . . . . . .
Automatic transmission
Driving with an automatic
transmission 160. . . . . . . . . . . . . . . . . . . . . .
Shift pattern 160. . . . . . . . . . . . . . . . . . . . . . . .
Shifting speed 163. . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Engine hood 62. . . . . . . . . . . . .
B
Battery
Checking battery condition 253. . . . . . . . . . . .
Recharging precautions 257. . . . . . . . . . . . . . .
Winter driving tips 182. . . . . . . . . . . . . . . . . . .
Before starting the engine 157. . . . . . . . . . . . . .
Belts
Seat belts 80. . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear limit warning light 178. . . . . . .
Brake system warning light 37. . . . . . . . . . . . . .
Brakes
Antilock brake system 177. . . . . . . . . . . . . . .
Booster 176. . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking tips 176. . . . . . . . . . . . . . . . . . . . . . . .
Fluid level 239. . . . . . . . . . . . . . . . . . . . . . . . .
Pad wear limit warning light 178. . . . . . . . . . .
Parking 158. . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake reminder light 37. . . . . . . . . . . .
Breakin period 181. . . . . . . . . . . . . . . . . . . . . .
Brightness control 46. . . . . . . . . . . . . . . . . . . . .
C
Carbon monoxide caution 156. . . . . . . . . . . . . .
Cassette tape player 140
Car audio operating tips 148. . . . . . . . . . . . . . . .
Center vents 130. . . . . . . . . . . . . . . . . . . . . . . . .
Checking and replacing the
blade type fuses 258. . . . . . . . . . . . . . . . . . . . . .
Checking brake fluid 239. . . . . . . . . . . . . . . . . .
Checking the cartridge type fuses 260. . . . . . . .
Checking the engine oil level 230. . . . . . . . . . . .
Child restraint 98. . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint precautions 98. . . . . . . . . . . . . . .
Childprotector, Rear door 19. . . . . . . . . . . . . . .
Cigarette lighter and ashtray 52. . . . . . . . . . . . .
Cleaning the interior 273. . . . . . . . . . . . . . . . . . .
Clock 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather, Operation 182. . . . . . . . . . . . . . .
Compact disc player 143. . . . . . . . . . . . . . . . . . .
Converter, Threeway catalytic 155. . . . . . . . . .

INDEX (E G)
280
Checking the coolant level 233. . . . . . . . . . . .
Coolant 233. . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant temperature gauge 34. . . . . . . . . . . . .
Emission control device 155. . . . . . . . . . . . . .
Engine compartment 220 . . . . . . . . . . . . . . . . .
Exhaust gas caution 156. . . . . . . . . . . . . . . . . .
Hood release 62. . . . . . . . . . . . . . . . . . . . . . . .
Oil consumption 229. . . . . . . . . . . . . . . . . . . .
Oil level 230. . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 196. . . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 226. . . . . . . . . . . . . . . . . . . . . . . .
Starting procedure 159. . . . . . . . . . . . . . . . . . .
Threeway catalytic converter 155. . . . . . . . .
Engine coolant, Winter driving tips 182. . . . . . .
Engine immobiliser system 10. . . . . . . . . . . . . .
Engine oil, Winter driving tips 182. . . . . . . . . . .
Engine coolant temperature gauge 34. . . . . . . . .
Exhaust gas caution 156. . . . . . . . . . . . . . . . . . . F
Facts about engine oil consumption 229. . . . . . .
Flasher, Headlight 5, 24. . . . . . . . . . . . . . . . . . .
Flat tire
After changing wheels 204. . . . . . . . . . . . . . . .
Changing tires 202. . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 197 . . . . . . . . . . . . . . . . .
Jack point 201. . . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 197. . . . . . . . . . . . . . . . . .
Jacking up 201. . . . . . . . . . . . . . . . . . . . . . . . .
Loosening wheel nuts 201 . . . . . . . . . . . . . . . . .
Lowering vehicle 203. . . . . . . . . . . . . . . . . . . .
Reinstalling wheel ornament 204. . . . . . . . . . .
Removing wheel ornament 200. . . . . . . . . . . .
Wheel block 200. . . . . . . . . . . . . . . . . . . . . . .
Wheel nuts 201. . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 58. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid level
Brake 239. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 233. . . . . . . . . . . . . . . . . . . . . .
Power steering 240. . . . . . . . . . . . . . . . . . . . . .
Washer fluid 261. . . . . . . . . . . . . . . . . . . . . . .
Fog light 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign countries, Operation in 181. . . . . . . . . . Front seat
Lumbar support 73. . . . . . . . . . . . . . . . . . . . . .
Position 71. . . . . . . . . .
Seat cushion angle and height 72. . . . . . . . . . .
Seatback angle 72. . . . . . . . . . . . . . . . . . . . . . .
Fuel
Filler door opener 65. . . . . . . . . . . . . . . . . . . .
Fuel economy 189. . . . . . . . . . . . . . . . . . . . . .
Fuel information 227. . . . . . . . . . . . . . . . . . . .
Gauge 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MTBE 228. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 181. . . . . . . . . .
Tank cap 65. . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse
Blade type fuses 258. . . . . . . . . . . . . . . . . . . .
Cartridge type fuses 260. . . . . . . . . . . . . . . . . .
Fuse locations 249. . . . . . . . . . . . . . . . . . . . . . . .
Fuse box 220. . . . . . . . . . . . . . . . . . . . . . . . . . . .
G
Garage door opener 54. . . . . . . . . . . . . . . . . . . .
Gas station information Inside back cover. . . . .
Gauge
Engine coolant temperature 34. . . . . . . . . . . . .
Fuel 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glovebox 54. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Good driving practice 166 . . . . . . . . . . . . . . . . . .
