GAUGES, METERS AND SERVICE REMINDER INDICATORS
39
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive belt.
If it is loose or broken, the generator will not charge the battery
properly.
If the belt is O.K., there is a problem somewhere in the charging
system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower, radio,
etc., and drive directly to the nearest Lexus dealer or repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or
loose.
(f) Malfunction Indicator Lamp
This lamp comes on in the following cases.
a. The fuel tank is completely empty. (See ”Fuel gauge” on page 34
for instructions.)
b. The fuel tank cap is not tightened securely. (See ”Fuel tank cap”
on page 65 for instructions.)
c. There is a problem somewhere in your engine electrical system
or electronic throttle control system.
If it comes on while you are driving in case c., have your vehicle
checked/repaired by your Lexus dealer as soon as possible.
(g) ”ABS” Warning Light
This light warns that there is a problem somewhere in your antilock
brake system.
If the light comes on while you are driving, have your vehicle
checked by your Lexus dealer as soon as possible.
The light will come on when the ignition key is turned to ”ON”, and
will go off after about a few seconds.
When the ”ABS” warning light is on (and the brake system warning
light is off), the brake system operates conventionally but antilock
brake system is not assisting brake performance so that the wheels
could lock up during a sudden brake or braking on slippery road
surfaces.
(h) Open Door Warning Light
This light remains on until all the doors are completely closed.

COMFORT ADJUSTMENT
91 some smoke along with nontoxic gas. This does not indicate a fire.
Be sure to wash off any residue as soon as possible to prevent minor
skin irritation.
Deployment of the airbags happen in a fraction of a second, so the
airbags must inflate with considerable force. While the system is
designed to reduce serious injuries, it may also cause minor burns or
abrasions and swellings.
Parts of the airbag module (steering wheel hub, dashboard, front
seats) may be hot for several minutes, but the airbags themselves
will not be hot. The airbags are designed to inflate only once.
A crash severe enough to inflate the driver and front passenger
airbags may break the windshield as the vehicle buckles. In vehicles
with a front passenger airbag, the windshield may also be damaged
by absorbing some of the force of the inflating airbag.
CAUTION
The SRS is designed only as a supplement to the primary
protection of the driver side and front passenger side seat
belt systems. The front seat occupants can be killed or
seriously injured by an inflating airbag if they do not wear
the available seat belts. During sudden braking just before
a collision, an unrestrained driver or front passenger can
move forward into direct contact with or close proximity to
the airbag which may then deploy during the collision. To
obtain maximum protection in an accident, the driver and
all passengers in the vehicle must wear their seat belts.
Wearing a seat belt during an accident reduces the chances
of death or serious injuries or being thrown out of the
vehicle. For instructions and precautions concerning the
seat belt system, see ”Seat belts” on page 80.
Improperly seated and/or restrained infants and children
can be killed or seriously injured by a deploying airbag. An
infant or child who is too small to use a seat belt should be
properly secured using a child restraint system. Lexus
strongly recommends that all infants and children be
placed in the rear seat of the vehicle and properly
restrained. The rear seat is the safest for infants and
children. For instructions concerning the installation of a
child restraint system, see ”Child restraint” on page 98 .

STARTING AND DRIVING
171
Cruise control failure warning
If the ”CRUISE” indicator light in the instrument cluster flashes
when using the cruise control, push the main switch to turn the
system off and then push it again to turn it on.
If any of the following conditions then occurs, there is some trouble
in the cruise control system.
The indicator light does not come on.
The indicator light flashes again.
The indicator light goes out after it comes on.
If this is the case, contact your Lexus dealer and have your Lexus
inspected.
ELECTRONICALLY MODULATED
AIR SUSPENSION
(U.S.A. ONLY)
This electronically modulated air suspension adjusts the
damping effect on the shock absorbers and the vehicle height.
This adjustment is automatically made in response to the driving
conditions to provide good riding comfort and stability in all
driving conditions.
(a) Vehicle height adjustment
31L015-3
This system maintains a stable vehicle height, regardless of
occupants and luggage weight. You can select one of the
following modes using a selector switch.

STARTING AND DRIVING
176
CAUTION
Do not rely excessively on the vehicle skid control system.
Even if the vehicle skid control system is operating, it is not
that your vehicle is absolutely safe. Reckless driving will
result in an unexpected accident. Always keep safety
driving in mind. If the slip indicator light flashes, sounding
an alarm, special care should be taken while driving.
Only use tires of specified size. The size, manufacturer,
brand and tread pattern for all 4 tires should be the same.
If you use the tires other than specified, or different type or
size, the vehicle skid control system may not function
correctly. When replacing the tires or wheels, contact your
Lexus dealer.
BRAKE SYSTEM
The tandem master cylinder brake system is a hydraulic system with
two separate subsystems. If either subsystem should fail, the other
will still work. However, the pedal will be harder to press, and your
stopping distance will be longer. Also, the brake system warning
light may come on.
CAUTION
Do not drive your vehicle with only a single brake system.
Have your brakes fixed immediately.
Brake booster
The brake booster uses engine vacuum to powerassist the brakes.
If the engine should quit while you are driving, you can bring the
vehicle to a stop with normal pedal pressure. There is enough
reserve vacuum for one or two stops but no more!
CAUTION
Do not pump the brake pedal if the engine stalls. Each push
on the pedal uses up your vacuum reserve.
Even if the power assist is completely lost, the brakes will
still work. But you will have to push the pedal hard much
harder than normal. And your braking distance will be
longer.

STARTING AND DRIVING
177
Antilock brake system
The antilock brake system is designed to automatically help
prevent lockup of the wheels during a sudden brake or braking
on slippery road surfaces. This assists in providing directional
stability and steering performance of the vehicle under these
circumstances.
The antilock brake system becomes operative after the vehicle has
accelerated to a speed in excess of approximately 10 km/h (6 mph).
It stops operating when the vehicle decelerates to a speed below
approximately 5 km/h (3 mph).
You may hear a sound in the engine compartment for a few seconds
when the engine is started or just after the vehicle is started. This
means that the antilock brake system is in the selfcheck mode, and
does not indicate a malfunction.
Effective way to press the ABS brake pedal: When the antilock
brake system function is in action, you may feel the brake pedal
pulsating and hear a noise. In this situation, to let the antilock brake
system work for you, just hold the brake pedal down more firmly.
Do not pump the brake. This will result in reduced braking
performance.
The brake pedal pulsation caused by the antilock brake system may
indicate hazardous road surface conditions. Although the antilock
brake system assists in providing vehicle control, it is still important
to drive with all due care, because the antilock brake system cannot
overcome the laws of physics that act on your vehicle:
Braking capability is dependent on tire friction with the road
surface.Even though the antilock brake system is operating, a driver
cannot maintain full control on certain slippery road surfaces,
when cornering at high speeds, or in violent maneuvers.
Avoid high speeds on wet roads. The antilock brake system
cannot eliminate the risk of hydroplaning and loss of tire friction.
Always maintain a safe distance from the vehicle in front of you.
Compared with vehicles not fitted with an antilock brake system,
your vehicle may require a longer stopping distance in the following
cases:
Driving on rough, gravel or snowcovered roads.
Driving with tire chains installed.
Driving on roads where the road surface is pitted or has other
differences in surface height.

STARTING AND DRIVING
178”ABS” warning light
31L019-2
This light comes on when the ignition key is turned to the ”ON”
position. After about a few seconds, the light will go off.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning light
system. Contact your Lexus dealer as soon as possible to service the
vehicle.
The light does not come on as described above, or remains on.
The light comes on while driving.
Even if the antilock brake system should fail, the brake system will
still operate conventionally. But when the ”ABS” warning light is
on (and the brake system warning light is off), antilock brake
system is not assisting brake performance so that the wheels could
lock up during a sudden brake or braking on slippery road surfaces.
Have your vehicle checked by your Lexus dealer as soon as possible.
Drumindisc type parking brake system
Your vehicle has a drumindisc type parking brake system. This
type of brake system needs beddingdown of the brake shoes
periodically or whenever the parking brake shoes and/or drums are
replaced.
Have your Lexus dealer perform the beddingdown.
Brake pad wear limit warning message
31L082
When your brake pads are worn enough to require replacement,
the brake pad wear warning message in the multi information
display appears.
If the warning message in the multi information display appears
while driving, have the brake pads checked and replaced by your
nearest Lexus dealer immediately.
Continuous driving without replacing the brake pads will cause
expensive rotor damage and increasing brake pedal effort to get the
same stopping distance.

DRIVING TIPS
188Because of the added load of the trailer, your vehicle’s engine
may overheat on hot days (at temperatures over 30C [85F])
when going up a long or steep grade with a trailer. If the engine
coolant temperature gauge indicates overheating, immediately
turn off the air conditioning (if in use), pull your vehicle off the
road and stop in a safe spot. See ”If your vehicle overheats” on
page 196 of this manual.
Always place wheel blocks under both the vehicle and trailer
wheels when parking. Apply the parking brake firmly. Put the
transmission in ”P”. Avoid parking on a slope with a trailer, but
if it cannot be avoided, do so only after performing the following:
1. Apply the brakes and keep them applied.
2. Have someone place wheel blocks under both the vehicle and
trailer wheels.
3. When the wheel blocks are in place, release your brakes slowly
until the blocks absorb the load.
4. Apply the parking brake firmly.
5. Shift into ”P” and turn off the engine.When restarting out after parking on a slope:
1. With the transmission in ”P” position, start the engine. Be sure
to keep the brake pedal depressed.
2. Shift into the ”3”, ”2”, ”L” or ”R” position.
3. Release the parking brake and brake pedal and slowly pull or back
away from the wheel blocks. Stop and apply your brakes.
4. Have someone retrieve the blocks.
CAUTION
Do not exceed 72 km/h (45 mph) or the posted towing speed
limit, whichever is lower. Because instability (swaying) of
a towing vehicletrailer combination usually increases as
the speed increases, exceeding 72 km/h (45 mph) may cause
loss of control.
Slow down and downshift before descending steep or long
downhill grades. Do not make sudden downshifts.
Avoid holding the brake pedal down too long or too
frequently. This could cause the brakes to overheat and
result in reduced braking efficiency.

CHASSIS
239
CHECKING BRAKE FLUID
63L0012
To check the fluid level, simply look at the seethrough reservoir.
The level should be between the ”MAX” and ”MIN” lines on the
tank.
It is normal for the brake fluid level to go down slightly as the brake
pads wear. So be sure to keep the reservoir filled.
If the reservoir needs frequent refilling, it may indicate a serious
mechanical problem.
If the level is low, add FMVSS No.116 DOT 3 or SAE J1703 brake
fluid to the brake reservoir.
Remove and replace the reservoir cover by hand. Add brake fluid
up to the ”MAX” line.
Use only newly opened brake fluid. Once opened, brake fluid
absorbs moisture from the air, and excess moisture can cause a
dangerous loss of braking efficiency.
CAUTION
Take care when filling the reservoir because brake fluid can
harm your eyes and damage painted surfaces. If fluid gets in
your eyes, flush your eyes with clean water.

INDEX (A C)
278
A
”ABS” warning light 178
Adding washer fluid 261. . . . . . . . . . . . . . . . . . .
Adjustment
Driver’s seat lumbar support 73. . . . . . . . . . . .
Front seat cushion angle and height 72. . . . . .
Front seat position 71. . . . . . . . . . . . . . . . . . . .
Front seatback angle 72
Seat belts 80. . . . . . . . . . . . . . . . . . . . . . . . . . .
Airbags (SRS) 86. . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 247. . . . . . . . . . .
Antifreeze 233. . . . . . . . . . . . . . . . . . . . . . . . . . .
Antilock brake system 177. . . . . . . . . . . . . . . .
Antitheft steering column lock 157. . . . . . . . . .
Appearance care
Cleaning the interior 273
Protecting your Lexus from corrosion 270. . .
Washing and waxing 271
Audio system 132. . . . . . . . . . . . . . . . . . . . . . . .
Automatic air conditioning controls 121. . . . . . .
Automatic transmission
Driving with an automatic
transmission 160. . . . . . . . . . . . . . . . . . . . . .
Shift pattern 160. . . . . . . . . . . . . . . . . . . . . . . .
Shifting speed 163. . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Engine hood 62. . . . . . . . . . . . .
B
Battery
Checking battery condition 253. . . . . . . . . . . .
Recharging precautions 257. . . . . . . . . . . . . . .
Winter driving tips 182. . . . . . . . . . . . . . . . . . .
Before starting the engine 157. . . . . . . . . . . . . .
Belts
Seat belts 80. . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear limit warning light 178. . . . . . .
Brake system warning light 37. . . . . . . . . . . . . .
Brakes
Antilock brake system 177. . . . . . . . . . . . . . .
Booster 176. . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking tips 176. . . . . . . . . . . . . . . . . . . . . . . .
Fluid level 239. . . . . . . . . . . . . . . . . . . . . . . . .
Pad wear limit warning light 178. . . . . . . . . . .
Parking 158. . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake reminder light 37. . . . . . . . . . . .
Breakin period 181. . . . . . . . . . . . . . . . . . . . . .
Brightness control 46. . . . . . . . . . . . . . . . . . . . .
C
Carbon monoxide caution 156. . . . . . . . . . . . . .
Cassette tape player 140
Car audio operating tips 148. . . . . . . . . . . . . . . .
Center vents 130. . . . . . . . . . . . . . . . . . . . . . . . .
Checking and replacing the
blade type fuses 258. . . . . . . . . . . . . . . . . . . . . .
Checking brake fluid 239. . . . . . . . . . . . . . . . . .
Checking the cartridge type fuses 260. . . . . . . .
Checking the engine oil level 230. . . . . . . . . . . .
Child restraint 98. . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint precautions 98. . . . . . . . . . . . . . .
Childprotector, Rear door 19. . . . . . . . . . . . . . .
Cigarette lighter and ashtray 52. . . . . . . . . . . . .
Cleaning the interior 273. . . . . . . . . . . . . . . . . . .
Clock 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather, Operation 182. . . . . . . . . . . . . . .
Compact disc player 143. . . . . . . . . . . . . . . . . . .
Converter, Threeway catalytic 155. . . . . . . . . .
