SECTION 3 1
154
STARTING AND DRIVING
Starting and driving
Threeway catalytic converter 155. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust caution 156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine 157. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch with steering lock 157. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake 158. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 159. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 160. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronic throttle control system 167. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control 168. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronically modulated air suspension 171. . . . . . . . . . . . . . . . . . . . . . .
Traction control system 173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle skid control system 174. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 176. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires 179. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

STARTING AND DRIVING
176
CAUTION
Do not rely excessively on the vehicle skid control system.
Even if the vehicle skid control system is operating, it is not
that your vehicle is absolutely safe. Reckless driving will
result in an unexpected accident. Always keep safety
driving in mind. If the slip indicator light flashes, sounding
an alarm, special care should be taken while driving.
Only use tires of specified size. The size, manufacturer,
brand and tread pattern for all 4 tires should be the same.
If you use the tires other than specified, or different type or
size, the vehicle skid control system may not function
correctly. When replacing the tires or wheels, contact your
Lexus dealer.
BRAKE SYSTEM
The tandem master cylinder brake system is a hydraulic system with
two separate subsystems. If either subsystem should fail, the other
will still work. However, the pedal will be harder to press, and your
stopping distance will be longer. Also, the brake system warning
light may come on.
CAUTION
Do not drive your vehicle with only a single brake system.
Have your brakes fixed immediately.
Brake booster
The brake booster uses engine vacuum to powerassist the brakes.
If the engine should quit while you are driving, you can bring the
vehicle to a stop with normal pedal pressure. There is enough
reserve vacuum for one or two stops but no more!
CAUTION
Do not pump the brake pedal if the engine stalls. Each push
on the pedal uses up your vacuum reserve.
Even if the power assist is completely lost, the brakes will
still work. But you will have to push the pedal hard much
harder than normal. And your braking distance will be
longer.

STARTING AND DRIVING
179
TYPES OF TIRES
Determine what kind of tires your vehicle is originally equipped
with.
1. Summer tires
Summer tires are highspeed capability tires best suited to highway
driving under dry conditions.
Since summer tires do not have the same traction performance as
snow tires, summer tires are inadequate for driving on
snowcovered or icy roads. For driving on snowcovered or icy
roads, we recommend using snow tires. If installing snow tires, be
sure to replace all four tires.
2. All season tires
All season tires are designed to provide better traction in snow and
to be adequate for driving in most winter conditions, as well as for
use all year round.
All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow.
Also, all season tires fall short in acceleration and handling
performance compared with summer tires in highway driving.
CAUTION
Do not mix summer and all season tires on your vehicle as
this can cause dangerous handling characteristics,
resulting in loss of control.
Do not use tires other than the manufacturer’s designated
tires, and never mix tires or wheels of the sizes different
from the originals.

DRIVING TIPS
182Do not rest your foot on the brake pedal while driving. It
can cause dangerous overheating, needless wear, and poor
fuel economy.
To drive down a long or steep hill, reduce your speed and
downshift. Remember, if you ride the brakes excessively,
they may overheat and not work properly. See page 163.
Be careful when accelerating, upshifting, downshifting or
braking on a slippery surface. The abrupt change in engine
speed, such as sudden acceleration or engine braking, could
cause the vehicle to spin or skid.
Do not drive in excess of the speed limit. Even if the legal
speed limit permits it, do not drive over 140 km/h (85 mph)
unless your vehicle has highspeed capability tires.
Driving over 140 km/h (85 mph) may result in tire failure,
loss of control and possible injury. Be sure to consult a tire
dealer to determine whether the tires on your vehicle are
highspeed capability tires or not before driving at such
speeds.
Do not continue normal driving when the brakes are wet.
If they are wet, your vehicle will require a longer stopping
distance, and it may pull to one side when the brakes are
applied. Also, the parking brake will not hold the vehicle
securely.
WINTER DRIVING TIPS
Make sure you have ethyleneglycol antifreeze in the radiator.
NOTICE
Do not use alcohol type antifreeze.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it must be
in top shape to provide enough power for winter starting. Page 253
tells you how to visually inspect the battery. Your Lexus dealer and
most service stations will be pleased to check the battery charge
level.
Make sure the engine oil viscosity is suitable for the cold weather.
See page 232 for recommended viscosity. Leaving a heavy summer
oil in your vehicle during winter months may cause harder starting.
If you are not sure about which oil to use, call your Lexus dealer
they will be pleased to help.
Check the electronic ignition system for loose connections or
obvious damage.
Keep the door locks from freezing.
Squirt lock deicer or glycerine into the locks to keep them from
freezing.

DRIVING TIPS
186
Tires
Ensure that your vehicle’s tires are properly inflated. Adjust the
tire pressure to the recommended cold tire pressure indicated
below:
Tire pressure, kPa (kgf/cm
2 or bar, psi)
Front 220 (2.2, 32)
Rear 220 (2.2, 32)
The trailer tires should be inflated to the pressure recommended
by the trailer manufacturer in respect to the total trailer weight.
Trailer lights
Trailer lights must comply with federal, state/provincial and local
regulations. See your local recreational vehicle dealer or rental
agency for the correct type of wiring and relays for your trailer.
Check for correct operation of the turn signals and stop lights
each time you hitch up. Direct splicing may damage your
vehicle’s electrical system and cause a malfunction of your lights.
Breakin schedule
Lexus recommends that you do not tow a trailer with a new
vehicle or a vehicle with any new power train component (engine,
transmission, differential, wheel bearing, etc.) for the first 800 km
(500 miles) of driving.
Maintenance
If you tow a trailer, your vehicle will require more frequent
maintenance due to the additional load. For this information,
please refer to the scheduled maintenance information in the
”Owner ’s Manual Supplement/ Maintenance Schedule”.
Retighten all fixing bolts of the towing ball and bracket after
approximately 1000 km (600 miles) of trailer driving.
Pretowing safety check
Check that your vehicle remains level when a loaded or unloaded
trailer is hitched. Do not drive if the vehicle has an abnormal
noseup or nosedown condition, and check for improper tongue
load, overload, worn suspension or other possible causes.
Make sure the trailer cargo is securely loaded so that it cannot
shift.
Check that your rear view mirrors conform to any federal,
state/provincial or local regulation. If they do not, install required
rear view mirrors appropriate for towing purposes.

CHASSIS
245
Tire selection
When replacing a tire, use only the same size and construction
as originally installed and with the same or greater load capacity.
Using any other size or type of tire may seriously affect handling,
ride, speedometer/odometer calibration, ground clearance, and
clearance between the body and tires or snow chains.
Do not mix radial, belted, or conventional tires on your vehicle.
Do not use tires or wheels other than the manufacturer’s
recommended size.
It can cause dangerous handling characteristics, resulting in loss of
control. If you need to change from conventional tires to radial tires
or vice versa, replace them as a set.
INSTALLING SNOW TIRES AND
CHAINS
When to use snow tires or chains
Snow tires or chains are recommended when driving on snow or
ice.
On wet or dry roads, conventional or radial tires provide better
traction than snow or studded tires.
Snow tire selection
If you need snow tires, select the same size, construction and load
capacity as the original tires on your Lexus.
Do not use tires other than stated above. Since your vehicle has
radial tires as original equipment, make sure your snow tires also
have radial construction. Do not install studded tires without first
checking local regulations for possible restrictions.
Snow tire installation
Snow tires should be installed on all wheels.
Installing snow tires on the rear wheels only can lead to an excessive
difference in road grip capability between the front and rear tires
which could cause loss of vehicle control.

CHASSIS
246
CAUTION
Do not drive with the snow tires incorrectly inflated.
Never drive over 120 km/h (75 mph) with any type of snow
tires.
Tire chain selection
Regulations regarding the use of tire chains vary according to
location or type of road. Always check the local regulations
before installing chains.
Use SAE Class ”S” type radial tire chains, with the exception of
radial cable chains or Vbar type chains.
Chain installation
Install the chains on the rear tires as tightly as possible. Do not
use tire chains on the front tires. Retighten chains after driving
0.5 1.0 km (1/4 1/2 mile).
When installing chains on your tires, carefully follow the
instructions of the chain manufacturer.
CAUTION
Do not exceed 50 km/h (30 mph) or the chain
manufacturer’s recommended speed limit, whichever is
lower.
Drive carefully avoiding bumps, holes, and sharp turns,
which may cause the vehicle to bounce.
Avoid sharp turns or lockedwheel braking, as use of
chains may adversely affect vehicle handling.

CHASSIS
247
REPLACING WHEELS
When to replace your wheels
If you have wheel damage such as bending, cracks or heavy
corrosion, the wheel should be replaced.
If you fail to replace damaged wheels, a tire may slip off a wheel or
they may cause loss of handling control.
Replacement with used wheels is not recommended as they may
have been subjected to rough treatment or high mileage and could
fail without warning. Also, bent wheels which have been
straightened may have hidden structural damage and therefore
should not be used. Never use an inner tube in a leaking wheel which
is designed for a tubeless tire.
Wheel selection
When replacing wheels, care should be taken to ensure that they
are equivalent to those removed in load capacity, diameter, rim
width, and offset.
Correct replacement wheels are available at your Lexus dealer.
A wheel of a different size or type may adversely affect handling,
wheel and bearing life, brake cooling, speedometer/odometer
calibration, stopping ability, headlight aim, bumper height, vehicle
ground clearance, and tire or snow chain clearance to the body and
chassis.
ALUMINUM WHEEL
PRECAUTIONS
After driving your vehicle the first 1600 km (1000 miles), check
that the wheel nuts are tight.
If you have rotated, repaired, or changed your tires, check that the
wheel nuts are still tight after driving 1600 km (1000 miles).
When using tire chains, be careful not to damage the aluminum
wheels.
Use only the Lexus wheel nuts and wrench designed for your
aluminum wheels.
When balancing your wheels, use only Lexus balance weights or
equivalent and a plastic or rubber hammer.
As with any wheel, periodically check your aluminum wheels for
damage. If damaged, replace immediately.
SUSPENSION AND CHASSIS
CAUTION
Do not modify the suspension/chassis with lift kits, spacers,
springs, etc. It can cause dangerous handling characteristics,
resulting in loss of control.

ELECTRICAL COMPONENTS
260
CHECKING THE CARTRIDGE TYPE
FUSES
64L016-3
1
Good 2
Melted
If the headlights or other electrical components do not work and
the blade type fuses are O.K., check the cartridge type fuses. If
any of the cartridge type fuses are blown, they must be replaced.
If there is an overload in the circuits from the battery, the fuses are
designed to blow before the entire wiring harness is damaged.
NOTICE
Before replacing the fuses, have the cause of electrical overload
determined and repaired by your Lexus dealer.
CAUTION
Always use a genuine Lexus fuse or equivalent for
replacement. Never install an ordinary wireeven for a
temporary fix. This may cause extensive damage and possibly
a fire.

INDEX (E G)
280
Checking the coolant level 233. . . . . . . . . . . .
Coolant 233. . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant temperature gauge 34. . . . . . . . . . . . .
Emission control device 155. . . . . . . . . . . . . .
Engine compartment 220 . . . . . . . . . . . . . . . . .
Exhaust gas caution 156. . . . . . . . . . . . . . . . . .
Hood release 62. . . . . . . . . . . . . . . . . . . . . . . .
Oil consumption 229. . . . . . . . . . . . . . . . . . . .
Oil level 230. . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 196. . . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 226. . . . . . . . . . . . . . . . . . . . . . . .
Starting procedure 159. . . . . . . . . . . . . . . . . . .
Threeway catalytic converter 155. . . . . . . . .
Engine coolant, Winter driving tips 182. . . . . . .
Engine immobiliser system 10. . . . . . . . . . . . . .
Engine oil, Winter driving tips 182. . . . . . . . . . .
Engine coolant temperature gauge 34. . . . . . . . .
Exhaust gas caution 156. . . . . . . . . . . . . . . . . . . F
Facts about engine oil consumption 229. . . . . . .
Flasher, Headlight 5, 24. . . . . . . . . . . . . . . . . . .
Flat tire
After changing wheels 204. . . . . . . . . . . . . . . .
Changing tires 202. . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 197 . . . . . . . . . . . . . . . . .
Jack point 201. . . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 197. . . . . . . . . . . . . . . . . .
Jacking up 201. . . . . . . . . . . . . . . . . . . . . . . . .
Loosening wheel nuts 201 . . . . . . . . . . . . . . . . .
Lowering vehicle 203. . . . . . . . . . . . . . . . . . . .
Reinstalling wheel ornament 204. . . . . . . . . . .
Removing wheel ornament 200. . . . . . . . . . . .
Wheel block 200. . . . . . . . . . . . . . . . . . . . . . .
Wheel nuts 201. . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 58. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid level
Brake 239. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 233. . . . . . . . . . . . . . . . . . . . . .
Power steering 240. . . . . . . . . . . . . . . . . . . . . .
Washer fluid 261. . . . . . . . . . . . . . . . . . . . . . .
Fog light 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign countries, Operation in 181. . . . . . . . . . Front seat
Lumbar support 73. . . . . . . . . . . . . . . . . . . . . .
Position 71. . . . . . . . . .
Seat cushion angle and height 72. . . . . . . . . . .
Seatback angle 72. . . . . . . . . . . . . . . . . . . . . . .
Fuel
Filler door opener 65. . . . . . . . . . . . . . . . . . . .
Fuel economy 189. . . . . . . . . . . . . . . . . . . . . .
Fuel information 227. . . . . . . . . . . . . . . . . . . .
Gauge 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MTBE 228. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 181. . . . . . . . . .
Tank cap 65. . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse
Blade type fuses 258. . . . . . . . . . . . . . . . . . . .
Cartridge type fuses 260. . . . . . . . . . . . . . . . . .
Fuse locations 249. . . . . . . . . . . . . . . . . . . . . . . .
Fuse box 220. . . . . . . . . . . . . . . . . . . . . . . . . . . .
G
Garage door opener 54. . . . . . . . . . . . . . . . . . . .
Gas station information Inside back cover. . . . .
Gauge
Engine coolant temperature 34. . . . . . . . . . . . .
Fuel 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glovebox 54. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Good driving practice 166 . . . . . . . . . . . . . . . . . .
