lexus LS400 1998 Engine / LEXUS 1998 LS400 OWNER'S MANUAL (OM50498U)

SECTION 1 7
116
INSTRUMENTS AND CONTROLS
Theft deterrent
Theft deterrent system 117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft prevention labels 119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

THEFT DETERRENT
117
THEFT DETERRENT SYSTEM
To deter theft of the vehicle, this system is designed to give an
alarm if any of the doors, trunk or hood is forcibly unlocked or
the battery terminal is disconnected and then reconnected while
the vehicle is locked.*
NOTE: *The system operating condition can be changed. Ask
your Lexus dealer for details.
The alarm blows the horn intermittently and flashes the headlights,
tail lights and other exterior lights.
17L001
Setting the system
1. Turn the ignition key to the ”LOCK” position and remove it.
2. Close and lock all the doors, trunk and hood using an ignition
key or wireless remote control.If you lock them with wireless remote control, the turn signals flash
once.* If you do not want to make them flash, consult with your
Lexus dealer.
NOTE: *The turn signals can be set not to flash. Ask your Lexus
dealer for details.
The indicator light will come on when all the doors, trunk and hood
are closed and locked.
3. After 30 seconds, the indicator flashes and the system is set.
Cancelling the system
When you unlock any door or trunk using an ignition key or
wireless remote control, the system is cancelled.
If you unlock any door or trunk with wireless remote control, the turn
signals flash twice.* If you do not want to make them flash, consult
with your Lexus dealer.
NOTE: *The turn signals can be set not to flash. Ask your Lexus
dealer for details.
Activating the system
The alarm sounds for 60 seconds if any of the following are operated:
Unlocking any door or trunk without using an ignition key or
wireless remote control.
Opening the hood forcibly.
Reconnecting the battery.

THEFT DETERRENT
118If any door is unlocked and the ignition key is not in the ignition
switch during the alarm sounding, its door is automatically locked.
To stop the alarm: Use either of the following methods.
Unlock the door or trunk using an ignition key or wireless remote
control.
Turn the ignition switch on.
Testing the system
1. Open all the windows.
2. Set the system as described above.
The front doors should be locked with the ignition key or wireless
remote control. Be sure to wait until the indicator light starts
flashing.
3. Unlock one of the doors from the inside.
The system should activate the alarm.
4. Unlock any of the doors with a key or the wireless remote
control to cancel the system.
5. Repeat this operation for the other doors and hood.
When testing the hood, also check that the system is activated when
the battery terminal is disconnected and then reconnected.
If the system does not work properly, have it checked by your Lexus
dealer.
NOTICE
Disconnecting the battery may result in the erasure of
information you have set in the computer memory. After
reconnecting the battery, check that the memorized data has
been retained. If it has been erased, input it into the computer
once more.

THEFT DETERRENT
119
THEFT PREVENTION LABELS
(U.S.A.ONLY)
17L002
Your new vehicle carries theft prevention labels which are
approximately 56 mm (2.20 in.) by 16 mm (0.63 in.).
The purpose of these labels is to reduce the incidence of vehicle
thefts by facilitating the tracing and recovery of parts from stolen
vehicles. The label is designed so that once it is applied to a surface,
any attempt to remove it will result in destroying the integrity of the
label. Transferring these labels intact from one part to another will
be impossible.
NOTICE
You should not attempt to remove the theft prevention labels as
it may violate certain state or federal laws.

SECTION 2
120
AIR CONDITIONING AND AUDIO
Automatic air conditioning controls 121. . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio system 132. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For vehicles equipped with Navigation System, please refer to
the separate ”Owner’s Manual for Navigation System”.

AIR CONDITIONING AND AUDIO
121
AUTOMATIC AIR CONDITIONING CONTROLS
21L001-5
The automatic air conditioning automatically maintains the set
temperature.
This air conditioning features automatic fan speed and air flow
control which automatically selects the most suitable fan speed
and air flow to control the temperature. The ignition key must be
in the ”ON” position.NOTICE
To prevent the battery from being discharged, do not leave the air
conditioning on longer than necessary when the engine is not
running.

AIR CONDITIONING AND AUDIO
122
1
Driver side temperature control button
2
Front windshield button
3
Driver side temperature display (in degrees Fahrenheit or
Centigrade)
4
Fan speed display
5
Air intake control button
6
Air flow display
7
Air conditioning onoff button
8
Passenger side temperature control button
9
Passenger side temperature display (in degrees Fahrenheit
or Centigrade)
10Separate/dual control button
11Air flow control button
12Fan speed control button
13OFF button
14Automatic control button

AIR CONDITIONING AND AUDIO
123
21L002-6
Air flow selection

AIR CONDITIONING AND AUDIO
124
(a) Climate control
SETTING OPERATION automatic control
21L003-3
1. Push the ”AUTO” button.
Air flow quantity, switching of the diffusers, onoff of the air
conditioning, and switching of the air intake between
RECIRCULATED AIR and OUTSIDE AIR are automatically
adjusted. The operation status is shown by each indicator.
When one of the manual control buttons is depressed while operating
in automatic mode, the operation corresponding to the button
depressed is set. Other conditions continue to be adjusted
automatically.
Push the ”OFF” button to turn the air conditioning off.
21L0401
2. Use the ”TEMP” or ”PASSENGER TEMP” button to set the
desired temperature.
The ”TEMP” or ”PASSENGER TEMP” button is used to set the
desired temperature. The temperature will be controlled on the
driver and passenger sides simultaneously or individually.
”TEMP” button Changes the temperature on the driver and
passenger sides simultaneously or the driver side only.
”PASSENGER TEMP” button Changes the temperature on the
passenger side only.
”DUAL” button Changes the mode of the temperature setting.
The indicator on the ”DUAL” button has two modes:
With the indicator on For individual temperature setting
With the indicator off For simultaneous temperature setting

AIR CONDITIONING AND AUDIO
125
21L005-2
Driver side setting
Passenger side setting
Mixed settingSETTING OPERATION manual control
If manual air flow selection is desired
21L006-3
The outlets from which air is delivered can be selected manually by
pushing the button. The function of each mode is as follows:
1
Panel Air flows mainly from the instrument panel vents.
2
Bilevel Air flows from both the floor vents and the
instrument panel vents.
3
Floor Air flows mainly from the floor vents.
4
Floor/Windshield Air flows mainly from the floor vents and
windshield vents.
