GAUGES, METERS AND SERVICE REMINDER INDICATORS
71
(a) Cruise information
13L049±1
The following information is shown with the ignition
switch turned on. Each time you push the ºMODEº
button, the displayed information is changed.
Available driving distance
 Average fuel consumption
 Current fuel consumption
 Average fuel consumption after being refueled
 Driving distance after being refueled
 Elapsed time
 Average vehicle speed
The displayed values of cruise information indicate the
general driving condition, so those may not show
precise and actual condition. Available driving distance

GAUGES, METERS AND SERVICE REMINDER INDICATORS
72
W24

When the fuel gauge indicates around ºFº
W25W25

When the fuel gauge indicates around middle
W26

When the fuel gauge indicates around ºEº
Available driving distance with the remaining fuel is
calculated and displayed depending on the amount
of remaining fuel.
Average fuel consumption
W27W27
The average fuel consumption is calculated and
displayed based on the total driving distance and
the total fuel consumption with the engine running.
The value is updated every 10 seconds.
To calculate from the beginning, push the ºRESETº
button.Current fuel consumption
W28W28

GAUGES, METERS AND SERVICE REMINDER INDICATORS
73
The current fuel consumption is calculated and
displayed
based on the driving distance and the fuel
consumption for 2 seconds with the engine running.
The value is updated every 2 seconds.
If you are driving at low speeds just before stopping, the
accurate figure may not be shown.
 Average fuel consumption after being
refueled
W29W29
The average fuel consumption after being refueled
is calculated and displayed based on the total
driving distance and the total fuel consumption after
being refueled.
The value is updated every 10 seconds.
To calculate from the beginning, push the ºRESETº
button.
 Driving distance after being refueled
W30W30
The driving distance after being refueled is
displayed.Elapsed time
W31W31

GAUGES, METERS AND SERVICE REMINDER INDICATORS
74The total time during the engine running is
displayed.
When the engine is started again after the ignition is off,
the driving time is added to the previous value. Up to 99
hours 59 minutes can be displayed. When the driving
time exceeds 99 hours 59 minutes, the display returns
to 0 and recounting starts.
To count from the beginning, push the ºRESETº button.

Average vehicle speed
W32W32
The average vehicle speed is calculated and
displayed based on the total driving distance and
the total driving time with the engine running.
The displayed value is updated every 10 seconds.
To calculate from the beginning, push the ºRESETº
button.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
75
(b) Warning messages
13L052

Reminder light
W40W40
When the engine oil pressure becomes too low, the
above message appears, the reminder light flashes
and the warning tone sounds.
If this message appears while you are driving, pull off the
road to a safe place and stop the engine immediately.
Call a Lexus dealer or qualified repair shop for
assistance.
The message may appear when the oil level is extremely
low. It is not designed to indicate low oil level, and the
oil level must be checked using the oil level dipstick.NOTICE
Do not drive the vehicle with the warning messagedisplayed ± even for one block. It may ruin theengine.
W41W41

SECTION 1 ± 4
80
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Outside temperature display 88
. . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 89
. . . . . . . . . . . . . . . . . . . . .
Power outlet 91
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Garage door opener 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coin box 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Penlight 100
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Floor mat 100
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions 103
. . . . . . . . . . . . . . . . . .
VANITY MIRRORS

INTERIOR EQUIPMENT
87
CLOCK
14L46
To reset the hour, press the ºHº button. To reset the
minutes, press the ºMº button. To adjust the time to
the nearest hour, press the º:00º button.
For example, if the º:00º button is pressed when the time
is between 9:30 ± 9:59 or between 10:01 ± 10:29, the
time will change to 10:00.
If the electrical power source has been disconnected
from the clock, the time display will automatically be set
to 1:00 (one o'clock).
For vehicles equipped with Navigation System, refer
to the separate ºOwner's Manual for Navigation
Systemº.

INTERIOR EQUIPMENT
88
OUTSIDE TEMPERATUREDISPLAY
14L026-4
This display shows the outside temperature when
the ignition switch is on.
The displayed temperature ranges from ±30 C (±22F)
up to 50C (122F). If the temperature does not appear
on the display or it shows º± ± ±º, take your vehicle to
your Lexus dealer.

AIR CONDITIONING AND AUDIO
216
1Driver side temperature control button
2Front windshield button
3Driver side temperature display (in degreesFahrenheit or Centigrade)
4Fan speed display
5Air intake control button
6Air flow display
7Air conditioning on±off button
8Passenger side temperature control button
9Passenger side temperature display (indegrees Fahrenheit or Centigrade)
10Separate/dual control button
11Air flow control button
12Fan speed control button
13OFF button
14Automatic control button

AIR CONDITIONING AND AUDIO
223
21L006-3
The outlets from which air is delivered can be selected
manually by pushing the button. The function of each
mode is as follows:
1Panel ± Air flows mainly from the instrument panel
vents.
2 Bi±level ± Air flows from both the floor vents and
the instrument panel vents.
3 Floor ± Air flows mainly from the floor vents.
4Floor/Windshield ± Air flows mainly from the floor
vents and windshield vents. If quick heating or cooling is desired ±
Push the ºTEMPº or ºPASSENGER TEMPº button on
either
side and hold it until ºMAX. HOTº or ºMAX. COLDº
appears on the display.
If manual fan speed control is desired ±
