GAUGES, METERS AND SERVICE REMINDER INDICATORS
78
W49W49
In the following cases, the above message appears,
the reminder light comes on and the warning tone
sounds.
When the headlight switch is turned to the first or
second clickstop with one or more of tail light bulbs
burned out.
 When the brake pedal is held down with one or more
of stop light bulbs burned out.
Have defective bulbs replaced as soon as possible.
W50W50
When the engine oil level is too low, the above
message appears, the reminder light comes on and
the warning tone sounds.
Add oil as soon as possible. (For instructions, see
ºChecking the engine oil levelº on page 405.)
NOTICE
Continued engine operation with low engine oil will damage the engine.

SECTION 6 ± 4
434
SERVICE PROCEDURES AND
SPECIFICATIONS
Electrical components
Specifications434
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking battery condition 443
. . . . . . . . . . . . . . . . . . . . .
Battery recharging precautions 451
. . . . . . . . . . . . . . . . .
Checking and replacing the blade type fuses 453 . . . . .
Checking the cartridge type fuses 457
. . . . . . . . . . . . . . .
Adding washer fluid 459
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the headlight aim 459
. . . . . . . . . . . . . . . . . . . . .
Replacing light bulbs 462
. . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
± FUSE LOCATIONS

ELECTRICAL COMPONENTS
463
CAUTION
Do not disassemble, repair or take apart the low beam
headlight bulbs, connector, power supply circuits
and rotated components. Or you may be injured by
electric shocks. Call your dealer when the headlights
fail to work or have to be replaced or disposed of.
 Halogen bulbs have pressurized gas inside and
require special handling. They can burst or shatter if
scratched or dropped. Hold a bulb only by its plastic
or metal case. Do not touch the glass part of a bulb
with bare hands.
NOTICE
Only use a bulb of the listed type.
LIGHT LOCATION
64L022-5

ELECTRICAL COMPONENTS
464Light Bulbs Bulb No. W T
ype
1 Headlights (High beam) HB3 60
A
2 Parking lights ±±± 5
D
3 Headlights (Low beam)
Discharge bulbs D2R 35
B
Halogen bulbs HB4 51
C
4 Front turn signal lights ±±± 21
D
5 Front side marker lights 194 3.8
D
6 Fog lights HB4 51
C
