PICTORIAL INDEX
viii
INSTRUMENT PANEL
00L001-4

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xi
Page
1 Engine coolant temperature gauge 59. . . . . . .
2 Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Turn signal indicator light 38
. . . . . . . . . . . . . . .
4 Headlight indicator light 35
. . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 38 . . . . . .
6 Automatic transmission indicator lights 281 .
7 Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Low fuel level warning light 68
. . . . . . . . . . . . . .
9 Cruise control indicator light 297
. . . . . . . . . . .
10 Height control indicator light 304
. . . . . . . . . . .
11 Power mode indicator light 295
. . . . . . . . . . . . .
12 Snow mode indicator light 295
. . . . . . . . . . . . . .
13 Anti±lock brake system warning light 67 . . . . . Page
14 Vehicle skid control system off
indicator light 304 . . . . . . . . . . . . . . . . . . . . . . . . .
15 Malfunction indicator lamp 67
. . . . . . . . . . . . . .
16 Slip indicator light 304
. . . . . . . . . . . . . . . . . . . . .
17 Multi information display 70
. . . . . . . . . . . . . . . .
18 Odometer and trip meter 61
. . . . . . . . . . . . . . . .
19 Brake system warning light 64
. . . . . . . . . . . . . .
20 SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . .
21 Open door warning light 68
. . . . . . . . . . . . . . . . .
22 Driver's seat belt reminder light 66
. . . . . . . . . .
23 Discharge warning light 67
. . . . . . . . . . . . . . . . .
24 Instrument panel light control 79
. . . . . . . . . . . .
25 ODO/TRIP RESET button 61
. . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xiii
Page
1 Engine coolant temperature gauge 59. . . . . . .
2 Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Turn signal indicator light 38
. . . . . . . . . . . . . . .
4 Tail light indicator light 35
. . . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 38 . . . . . .
6 Automatic transmission indicator lights 281 .
7 Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Low fuel level warning light 68
. . . . . . . . . . . . . .
9 Cruise control indicator light 297
. . . . . . . . . . .
10 Power mode indicator light 295
. . . . . . . . . . . . .
11 Snow mode indicator light 295
. . . . . . . . . . . . . .
12 Anti±lock brake system warning light 67 . . . . . Page
13 Vehicle skid control system
off indicator light 304 . . . . . . . . . . . . . . . . . . . . . .
14 Malfunction indicator lamp 67
. . . . . . . . . . . . . .
15 Slip indicator light 304
. . . . . . . . . . . . . . . . . . . . .
16 Multi information display 70
. . . . . . . . . . . . . . . .
17 Odometer and trip meter 61
. . . . . . . . . . . . . . . .
18 Brake system warning light 64
. . . . . . . . . . . . . .
19 SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . .
20 Open door warning light 68
. . . . . . . . . . . . . . . . .
21 Driver's seat belt reminder light 66
. . . . . . . . . .
22 Discharge warning light 67
. . . . . . . . . . . . . . . . .
23 Instrument panel light control 79
. . . . . . . . . . . .
24 ODO/TRIP RESET button 79
. . . . . . . . . . . . . . . .

00L013
00L013
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on
at full intensity.
Automatic light control Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on.
Automatic light control
00L014
00L015
Right or left turn
Lane change
(Right or left) High beam
Headlight flasher
BASIC OPERATION ± QUICK REFERENCE
7
4. HEADLIGHT AND TURN
SIGNAL
SWITCH

HEADLIGHT SWITCH
With the ignition OFF
With the engine started and parking
brake released

TURN SIGNAL SWITCH

SWITCHES
36To turn the lights on, twist the knob on the end of the
lever.
FIRST CLICKSTOP: Only the parking, tail, license
plate, side marker and instrument panel lights turn on.
SECOND CLICKSTOP: Headlights also turn on.
THIRD CLICKSTOP (ºAUTOº): The headlights and all
other lights automatically turn on depending on the
darkness of the surroundings.*
Vehicles sold in U.S.A.:
When the headlights are on,
the headlight indicator lights up in the instrument cluster.
Vehicles sold in Canada: When the tail lights are on,
the tail light indicator lights up in the instrument cluster.
Manually twist the knob to the second clickstop to
turn on the headlights if they are needed
immediately when entering a dark tunnel, parking
structure, etc.
12L002a

SWITCHES
37
The automatic light control sensor is on top of the
driver's side instrument panel.
Do not place anything on the instrument panel, and/or do
not affix anything on the windshield to block this sensor.
When the headlights come on, the lights automatically
turn off about 30 seconds after any of the doors is
opened and closed with the ignition key turned to the
ºACCº or ºL
OCKº position.** To turn them on again, turn
the ignition key to the ºONº position, or turn the headlight
switch off and then twist the knob until the first or second
clickstop. If you are going to park for over one week,
make sure the headlight switch is off.
When the headlight switch is on with all the doors locked,
pushing the ºLOCKº button on the wireless remote
control key turns off the headlights.
NOTE: *The operating condition or sensitivity can be changed. **The time before turning off the lights can
be changed. Ask your Lexus dealer for details.
Daytime Running Light System
The headlights turn on at reduced intensity when the
parking brake is released with the engine started, even
with the light switch in the ºOFFº position. They will not
go off until the ignition switch is turned off.
To turn on the other exterior lights and instrument panel
lights, twist the knob to the first clickstop.
Twist the knob to the second clickstop to turn on the
headlights to full intensity for driving at night.
When setting the knob to the third clickstop (ºAUTOº),
the headlights will automatically adjust to full intensity
and/or turn on the other lights depending on the
darkness of the surroundings. Likewise, as the
surroundings become brighter, the headlights will turn to
reduced intensity, ultimately turning off the other lights.
NOTICE
To prevent the battery from being discharged, do not leave the lights on longer than necessarywhen the engine is not running.

SECTION 1 ± 3
57
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder
indicators
Fuel gauge57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 59
. . . . . . . . . . . . . . .
Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 62 . . .
Multi information display 70
. . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 79
. . . . . . . . . . . . . . . . . . . .
FUEL GAUGE
13L001±1

GAUGES, METERS AND SERVICE REMINDER INDICATORS
79
W51W51
When the fluid level in the tank becomes nearly
empty, the above message appears, the reminder
light comes on and the warning tone sounds.
Fill the tank as soon as possible.
W53W53
When there is a problem somewhere in the
automatic headlight leveling system, the above
message appears, the reminder light comes on and
the warning tone sounds.
If this message appears, have your vehicle checked by
your Lexus dealer.INSTRUMENT PANEL LIGHTCONTROL
13L005
To adjust the brightness of the instrument panel
lights, turn the knob.

INTERIOR EQUIPMENT
103
LUGGAGE STOWAGEPRECAUTIONS
When stowing luggage or cargo in the vehicle,
observe the following:
Put luggage or cargo in the trunk when at all possible.
Be sure all items are secured in place.
 Be careful to keep the vehicle level. Placing the
weight as far forward as possible helps maintain
vehicle balance.
 For better fuel economy, do not carry unnecessary
weight.
CAUTION
Do not place anything on the filler panel behind the
rear seatback. Such items may be thrown about and
possibly injure people in the vehicle during sudden
braking or an accident.
 Do not drive with objects left on top of the instrument
panel. They may interfere with the driver's field of
view. Or they may move during sharp vehicle
acceleration or turning, and impair the driver's
control of the vehicle. In an accident they may injure
the vehicle occupants.

SECTION 1 ± 5
105
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood105
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Trunk lid 107 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Fuel tank cap 110 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon roof 113 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HOOD
15L001
To open the hood, pull the hood lock release lever
under the instrument panel. The hood will spring up
slightly.
