low oil pressure lexus LS400 1999 Electrical Components / LEXUS 1999 LS400 OWNER'S MANUAL (OM50514U)

GAUGES, METERS AND SERVICE REMINDER INDICATORS
75
(b) Warning messages
13L052

Reminder light
W40W40
When the engine oil pressure becomes too low, the
above message appears, the reminder light flashes
and the warning tone sounds.
If this message appears while you are driving, pull off the
road to a safe place and stop the engine immediately.
Call a Lexus dealer or qualified repair shop for
assistance.
The message may appear when the oil level is extremely
low. It is not designed to indicate low oil level, and the
oil level must be checked using the oil level dipstick.NOTICE
Do not drive the vehicle with the warning messagedisplayed ± even for one block. It may ruin theengine.
W41W41

MAINTENANCE
381
GENERAL MAINTENANCE
Listed below are the general maintenance items that
should be performed at the intervals specified. It is
recommended that any problem you notice be brought
to the attention of your Lexus dealer or qualified service
shop for their advice.
CAUTION
Make these checks only where adequate ventilation can
be obtained if you run the engine.
Vehicle exterior
Items listed below should be performed from time to
time, unless otherwise specified.
Tire pressure
Check the pressure with a gauge every two weeks, or at
least once a month and adjust as shown on the tire
pressure label. See page 421 for additional information.
Tire surface
Check the tires carefully for cuts, damage or excessive
wear. See page 425 for additional information.
Wheel nuts
When checking the tires, make sure to check the nuts for
looseness. Tighten them if necessary. Tire rotation
Rotate
the tires every 12000 km (7500 miles). See page
423 for additional information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other
fluid after the vehicle has been parked for a while. If you
smell fuel fumes or notice any leak, have the cause
found and corrected immediately.
Doors and engine hood
Check that all doors, including trunk lid, operate
smoothly and all latches lock securely. Make sure the
engine hood secondary latch secures the hood when the
primary latch is released.

ENGINE
402
Gasolines quality
In a very few cases, you may experience driveability
problems caused by the particular gasoline that you are
using. If you continue to have unacceptable driveability,
try changing gasoline brands. If that does not rectify
your problem, then consult your Lexus dealer.
NOTICE
Do not use gasohol other than stated above. It will cause fuel system damage or vehicleperformance problems.
If drivability problems are encountered (poorhot starting, vaporizing, engine knock, etc.),discontinue its use.
Take care not to spill gasohol during refueling.Gasohol may cause paint damage.
Fuel tank capacity
85 L (22.5 gal., 18.7 lmp.gal.)
FACTS ABOUT ENGINE OIL CONSUMPTION
Functions of engine oil
Engine oil has the primary function of lubricating and
cooling the inside of the engine, and plays a major role
in maintaining the engine in proper working order.
Engine oil consumption
It is normal that an engine should consume some
engine oil during normal engine operation. The
causes of oil consumption in a normal engine are as
follows.
Oil is used to lubricate pistons, piston rings and
cylinders. A thin film of oil is left on the cylinder wall
when a piston moves downwards in the cylinder.
High negative pressure generated when the vehicle
is decelerating sucks some of this oil into the
combustion chamber. This oil as well as some part of
the oil film left on the cylinder wall is burned by the
high temperature combustion gases during the
combustion process.
 Oil is also used to lubricate the stems of the intake
valves. Some of this oil is sucked into the combustion
chamber together with the intake air and is burned
along with the fuel. High temperature exhaust gases
also burn the oil used to lubricate the exhaust valve
stems.

CHASSIS
415
SPECIFICATIONS
± AUTOMATIC TRANSMISSIONFluid capacity Drain and refill
Fluid type
1.9 L (2.0 qt., 1.7 lmp.qt.)
Automatic transmission fluid Type T ± IV or
equivalent
± DIFFERENTIAL
Oil capacity
Oil type
Oil viscosity
1.3 L (1.4 qt., 1.1 lmp.qt.)
Hypoid gear oil API GL±5
Above ±18 C (0F): SAE 90
Below ±18 C (0F): SAE 80W or SAE 80W±90
± BRAKES
Pedal clearance
Pedal freeplay
Brake pad wear limit
Parking brake lining wear limit
Parking brake adjustment
Fluid type
70 mm (2.8 in.) Min. *1
1 ± 6 mm (0.04 ± 0.24 in.)
1.0 mm (0.04 in.)
1.0 mm (0.04 in.)
5 ± 7 clicks *
2
SAE J1703 or FMVSS No. 116 DOT 3
*1: Minimum pedal clearance when depressed with the pressure of 490 N (50 k\
gf, 110 lbf.) with the engine running
*
2: Parking brake adjustment when depressed with the pressure of 294 N (30 \
kgf, 66.1 lbf.)
